Quick Start
simple commissioning of the MX530/880 for remote access to a connected terminal device
MX530|MX880
with mdex
This is a supplement to the
by using the preconfigured mdex
mdex
fixed.IP+
mdex
public.IP
OpenVPN
OpenVPN-Device
Release: 2019-02-27 (v.1.0)
MX530/MX880
Setup Manual and describes the
fixed.IP+
/
public.IP
OpenVPN-Device.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX530 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mdex MX530

Summary of Contents for Mdex MX530

  • Page 1 MX530|MX880 with mdex OpenVPN-Device Release: 2019-02-27 (v.1.0) This is a supplement to the MX530/MX880 Setup Manual and describes the simple commissioning of the MX530/880 for remote access to a connected terminal device by using the preconfigured mdex fixed.IP+ public.IP OpenVPN-Device.

  • Page 2: Table Of Contents

    The information and data contained in this document are subject to change without notice. Copyright notice: This document is copyrighted by mdex GmbH and may only be reproduced for internal use. All other reproductions, in whole or in part, are not permitted without the prior written consent of mdex GmbH.

  • Page 3: Preconfiguration

    192.168.0.100 MX530 / MX880 Remote access to router web interface Whether remote access to the MX530/ MX880 web interface is enabled or disabled in the preconfiguration can be found on the MX880 additional lable: Remote: Disabled ➔ Remote access to the router is disabled and must be enabled if necessary.

  • Page 4: Quick Start

    (preferably SIM 1). SIM 1 SIM 2 mdexSIM mdexSIM Vodafone Telekom 3. Secure the back cover with the four screws. 4. The MX530/MX880's mobile settings must be adjusted to use your SIM card(s), as described at Step Seite 4...

  • Page 5: Step 2: Connect Mobile Antenna(S)

    Connect the power supply Step 3 Plug the router connector of the plug-in power supply into the PWR socket on the router. MX880 MX530 To use your own power supply, refer to the MX530/880 Setup Guide in Chapter 2.4 "Power Supply". Seite 5...

  • Page 6: Step 4: Local Access To Router Web Interface

    Step 4 1. Set the network card of your PC to 'Obtain an IP address automatically' (DHCP). The MX530/MX880 is preconfigured for a dynamic assignment of IP addresses and automatically assigns the IP address 192.168.0.100 to the connected PC. By default, the MX530/MX880 assigns only one IP address (192.168.0.100) to a connected network device! •...

  • Page 7: Step 5: Setup Mobile Settings

    Setup mobile settings Step 5 The mobile settings in the MX530/MX880 must be set under Network → Mobile (SIM) for the operation of your SIM card(s). A detailed description of the mobile settings can be found in the MX530/MX880 Setup Guide in Chapter "3.5 SIM Mobile Phone Settings".

  • Page 8: Step 8

    Step 8 Step 8 Remote access to router web interface For a remote access to the MX530/MX880 router web interface, the remote access must be enabled in the router. The remote preconfiguration of the MX530/MX880 is printed on the additional label: Remote: Disabled ➔...

  • Page 9: Step Connecting A Terminal Via 'Host Forwarding

    / public.IP over all ports and protocols. The entered ports in 'Port Forwarding' according to Step 9b and the own ports of the MX530/MX880 (e.g. for remote access) are not forwarded via 'host forwarding'.

  • Page 10: Step 9 Connecting Terminals Via 'Port Forwarding

    Set the IP address, Gateway and DNS server in the network settings of the terminal device(s): IP addess: 192.168.0.xxx | Gateway: 192.168.0.1 | DNS-Server: 192.168.0.1 Please note that the MX530/880 DHCP server automatically assigns the IP address 192.168.0.100 to a connected terminal device by default.

  • Page 11: Appendix

    3 Appendix 3.1 Further functions / adaptations For further functions and adaptations of the MX530/MX880 (e.g. change LAN IP address, adapt DHCP server, activate WLAN, etc.), please refer to the enclosed MX530/MX880 Setup Guide or our support page https://wiki.mdex.de.

  • Page 12: Deviations From Standard Configuration

    (Username: admin | Password: admin01). 4. Adjust the configuration of the MX530/MX880 according to chapter 3.3 Deviations from standard configuration. 5. Reboot the MX530/MX880. The router is now back in its default state for using the mdex fixed.IP+ / public.IP via OpenVPN. Seite 12...
