Geometrics MetalMapper 2x2 Operation Manual page 25

SQC Quality Control (static
IVS)
DQC Dynamic QC (IVS line)
SFT Function Test
DFT Function Test
SXM Miscellaneous
DXM Miscellaneous
4.6 Sample Project File
A project file is a .csv file with columns shown below. This will allow the Survey window to display the
measurement locations for static and dynamic locations.
#any line beginning with # or /is ignored
#first good line must be the project name
FortuneDr20160419
#UTM coordinates are meters, Zone is number and hemisphere (N or S)
#GeoID
G000
G000
G000
G000
G000
H000
# currently only dynamic lines are
#supported
I000
I000
I000
I000
GeoID is defined by the project and can be an alphanumeric string up to 8 characters long.
TargetID can be an alphanumeric string up to 8 characters long.
Static survey of emplaced IVS targets for QC purposes
Dynamic survey of an IVS used for QC purposes
A direct test of all sensor component responses to a
standard object placed at a precisely know location
(relative to the sensor).
A direct test of all sensor component responses to a
standard object placed at a precisely know location
(relative to the sensor).
Static all other
Dynamic all other
DataType TargetID
SBG AaBBBB0
SAM Aa000000
SAM Aa000001
SAM Aa000002
SAM Aa000003
SBG AaBBBB1
they must appear as a pair of points:
DAM I001
DAM I001
DAM I002
DAM I002
easting northing zone
598256 4139854 10N
598256 4139852 10N
598256 4139850 10N
598256 4139848 10N
598256 4139846 10N
598254 4139852 10N
598250.1 4139850 10N
598251.7 4139824 10N
598250.5 4139850 10N
598252.1 4139850 10N
