ControlOMatic ChlorMaker IL Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
C
M
IL
hlor
aker
TM
O
PERATING
I
NSTRUCTIONS
ControlOMatic, Inc. 12659 Arbor Lane, Grass Valley, CA 95949
www.ControlOMatic.com Support@ControlOMatic.com 530-205-4520
Manual Version: 2/1/14 Made in the USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ChlorMaker IL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ControlOMatic ChlorMaker IL

Summary of Contents for ControlOMatic ChlorMaker IL

  • Page 1 PERATING NSTRUCTIONS ControlOMatic, Inc. 12659 Arbor Lane, Grass Valley, CA 95949 www.ControlOMatic.com Support@ControlOMatic.com 530-205-4520 Manual Version: 2/1/14 Made in the USA...

  • Page 2: Important Safety Instructions

    ChlorMaker IL is a semi-automated, salt water chlorine generation system specifically designed for portable spas up to 1000 Gallons. ChlorMaker IL generates chlorine from a small amount of ordinary salt (Sodium Chloride, NaCl) dissolved in the spa water. The amount of salt added is very small in relation to the volume of the water in the spa.
  • Page 3 ChlorMaker IL will significantly reduce the amount of spa maintenance required, but chemi- cal check-ups including chlorine levels and PH are recommended before each use. Proper water maintenance will prolong the life of ChlorMaker IL and the spa. The following table describes generally accepted optimum water chemistry for portable spas.
  • Page 4 SALT REQUIREMENT ChlorMaker IL can generate both Chlorine or Bromine. It all depends on which sanitizer the user prefers. Use So- dium Chloride Salt if you prefer Chlorine Generation and Sodium Bromide Salt if you prefer Bromine. Please Note: Each salt requires a different level of salinity for ChlorMaker IL to operate effectively. WARNING: SALT ONLY...

  • Page 5: Product Installation

    PRODUCT INSTALLATION ChlorMaker IL is equipped with a 110/220 VAC Auto-Sensing Power Supply allowing ChlorMaker IL to be installed on almost any spa with a 24 Hour Circulation Pump. Please follow the installation instructions below. Prepare Spa For Installation: Shut down main power to spa and drain water completely. Open access panel to the spa exposing the spas plumbing area.
  • Page 6 PRODUCT INSTALLATION CONTINUED Remove Top Cover To Control Panel: IMPORTANT: First make sure power supply is unplugged from power source. Then remove the top cover of the control panel by unfastening the 4 screws as shown in the picture below allowing the top cover to freely separate from the bottom section of the control panel. Unfasten Screws Unfasten Screws Watertight Cable Grips...
  • Page 7 The ChlorMaker IL cell should be installed on the OUTPUT side of the pump. The tube will need to be cut and reconnected to the ChlorMaker IL cell. Additional tubing may be needed if the existing tube is not long enough or is hard to access. Additional tubing is available at most hardware stores.

  • Page 8: Changing Power Levels

    CHANGING POWER LEVELS ChlorMaker IL is designed with 10 power level settings. ChlorMaker IL is set to power level 3 straight from the fac- tory. Please follow the steps below to increase or decrease the power levels from the factory default power level 3.

  • Page 9: Boost Mode

    Boost Mode is designed to replenish chlorine that was just used during the last spa use. Activating Boost Mode will take ChlorMaker IL out of regular production mode or standby mode and re-start the production of chlorine accord- ing to the following table. To activate Boost Mode simply press the Boost Mode Button. The Salt Light will begin flashing indicating that ChlorMaker IL is engaged in Boost Mode.

  • Page 10: Disassembly & Maintenance

    ChlorMaker IL is designed with an automatic self cleaning feature. However, there are some spa water conditions that are well beyond the control of ChlorMaker IL’s reverse polarity and self cleaning design. If a visible white or scaly substance builds up on the plates, please follow the simple disassembly and cleaning instructions below.

  • Page 11: Limited Warranty

    Models: This warranty applies to ChlorMaker IL models referenced as “System”. ControlOMatic, Inc. Warrants the system to be free of all defects in material and workmanship for one (1) year from the original purchase date. The system includes the power supply unit, cable, electronics, and electrolytic genera- tor for residential use only.

  • Page 12: Product Registration

    PRODUCT REGISTRATION Please fill out the information below and send to ControlOMatic to properly register your prod- uct. Or register your product on line at www.ControlOMatic.com. First Name: Last Name: Address: City: State / Province: Postal Code: Phone: E-Mail: Please copy this section and forward a copy to ControlOMatic, Inc.
