- Page 1 User Manual RC1882-RIIM-DK Development Kit...
-
Page 2: Table Of Contents
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT RC1882-RIIM-DK Development Kit Table of contents RC1882-RIIM-DK DEVELOPMENT KIT ......................2 TABLE OF CONTENTS ............................2 RIIM OVERVIEW ..............................3 FIGURE 1. RIIM NETWORK – SYSTEM AND DOCUMENTATION OVERVIEW ..........3 DEVELOPMENT KIT INTRODUCTION ....................... 4 QUICK START .............................. -
Page 3: Riim Overview
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT RIIM overview The RIIM network consists of these key elements The IPM module The IPM module can be configured as root (border router), mesh router or leaf node. As a root node it acts as the base of the mesh network. It can connect to an external network via ethernet or custom user application on other interfaces such as UART ... -
Page 4: Development Kit Introduction
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Development Kit Introduction The Development Kit (DK) is designed to make it easy for the user to evaluate the RIIM network and to run preloaded application or to make a user specific application with minimal time and effort. -
Page 5: Quick Start
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Quick Start The development kit is programmed with an out-of-the box application that allow the user to make wireless connection and see data coming through the network. The example code pre-loaded on the development kit is also included in the RIIM SDK. -
Page 6: Further Development
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Figure 3. Log from Border Router Board startup and packet reception(YAT) Further development Start making your own custom application Read a different sensor Use other channels or output power level Add new timer events Make events based on button... -
Page 7: Border Router Board Introduction
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Border Router Board Introduction The border router board contains an Ethernet (RJ45) connector, USB connector, USB to serial converter, LEDs, voltage regulator, power switch and programming/debug connector. All I/O signals are routed to holes at the edge suitable for 2.54 mm pitch pin headers. -
Page 8: Block Diagram
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Block Diagram P5-P6: 2*10 pins I/O connection, pitch 2.54mm LEDs Ethernet RJ45 ethernet MAC/PHY Power LED 3V3OUT LDO 1 A power UART Radiocrafts Module USB to UART Button: RESET FUNCTIONAL P8: JTAG Programming Connector Figure 5. Block schematic RC1882CEF-IPM-BR Page 8 of 27 2019 Radiocrafts AS... -
Page 9: I/O Connection
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT I/O connection All pins to the module are available through standard pin rows using a pitch distance of 100 mil (2.54 mm). These pins are connected to 2 x 10 pins holes named P5 to P6. The table below gives an overview of the edge connectors and their logical signals. - Page 10 USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Page 10 of 27 2019 Radiocrafts AS User Manual RC1882-RIIM-DK Development Kit Rev. 1.00...
-
Page 11: Development Board Introduction
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Development Board Introduction The development board contains an USB connector, USB to serial converter, LEDs, voltage regulator, power switch and programming/debug connector. All I/O signals are routed to holes at the edge suitable for 2.54 mm pitch pin headers. -
Page 12: Block Diagram
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Block Diagram P4-P7: 4*10 pins I/O connection, pitch 2.54mm LEDs Power LEDs switch 3V3OUT VBUS (5V/100mA) Regulator 3.3V / 50 mA UART Radiocrafts USB to UA Module Buttons: RESET P8: JTAG Programming Connector Figure 7. Block schematic RC1882CEF-IPM-DB Page 12 of 27 2019 Radiocrafts AS... -
Page 13: I/O Connection
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT I/O connection All pins to the module are available through standard pin rows using a pitch distance of 100 mil (2.54 mm). These pins are connected to 4 x 10 pins holes named P4 to P7. The table below gives an overview of the edge connectors and their logical signals. -
Page 14: Sensor Board Introduction
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Sensor Board Introduction The Sensor Board includes the module to be evaluated. In addition it contains other circuitry needed for powering and communication to the module. All I/O signals are routed to holes at the edge suitable for 2.54 mm pitch pin headers for easy monitoring and control externally. -
Page 15: Block Diagram Sensor Board
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Block Diagram Sensor Board P4-P7: 4*10 pins I/O connection, pitch 2.54mm P1 USB LIS3DE HALL Power Sensor POWER Power Selector 3V3OUT VBUS (5V/100mA) Regulator RF Sub 3.3V / 50 mA 1GHz UART Radiocrafts USB to UA... -
Page 16: Powering The Sensor Board
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Powering the Sensor Board The sensor board can be power in several different ways, thus giving flexibility and ease of use. Power source Jumper position/RED Comment USB power 1A Make sure to use a USB power source capable of 1 A. -
Page 17: I/O Connection
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT I/O Connection All pins to the module are available through standard pin rows using a pitch distance of 100 mils (2.54 mm). These pins are connected to 4 x 10 pins holes named P4 to P7. The table below gives an overview of the edge connectors and their logical signals. -
Page 18: I/O Silkscreen (Revision 1.0)
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT I/O Silkscreen (revision 1.0) On revision 1.0 of the sensor board there are some inaccuracies in the silkscreen print. GPIO numbering is wrong and ADC1 marking is missing. Marking of RXD/TXD are offset. See below... -
Page 19: Sht35 Temperature And Humidity Sensor
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT SHT35 Temperature and Humidity Sensor SHT35 is the next generation of Sensirion’s temperature and humidity sensors. It has a typical accuracy of ± 1.5 %RH and ± 0.1 °C. It connected to sensor module by I2C and is setup with I2C address 0x44. -
Page 20: Sl353Lt Hall Detector
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT SL353LT Hall Detector The SL353LT is a state-of-the art hall detector that enable magnetic detection. It has a very low power consumption of 1.8 uA in average for 2.8V operation. The output of the hall detector is connected to GPIO-3 on the sensor module. -
Page 21: Prototyping With The Sensor Board
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Prototyping with the Sensor Board The sensor board is well suited for prototyping/bread boarding. With all I/O pins easily accessible at the edge, connection to external boards can be made through board stacking with standard pin headers or cabled with standard 2.54 mm pitch cable. -
Page 22: Sensor Board Pcb And Assembly Layout
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Sensor Board PCB and Assembly Layout The PCB is a simple 4-layer board where Layer 2 is used as ground plane. The laminate used is standard FR- 4 board material. The PCB is 1.6mm thick. Full resolution layout and assembly drawing are found in [8]. - Page 23 USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Figure 12: RC1882CEF-IPM-SB Circuit diagram, page 1 Page 23 of 27 2019 Radiocrafts AS User Manual RC1882-RIIM-DK Development Kit Rev. 1.00...
- Page 24 USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Figure 13: RC1882CEF-SPM-SB Circuit diagram, page 2 Page 24 of 27 2019 Radiocrafts AS User Manual RC1882-RIIM-DK Development Kit Rev. 1.00...
-
Page 25: Sensor Board Bill Of Materials
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT Sensor Board Bill of Materials The circuit diagram includes all components of RC1882CEF-IPM-SB, but the Bill of Material describes which components are mounted. Details are listed in the following table. Components not mounted are marked DNM (Do Not Mount) in the ‘Quantity/# column. - Page 26 USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT R6-10; R15; R17; R19; R24;R29-31; R40-42 R_0_0402 Resistor, 0402 R22-23 R_0_0603 Resistor, 0603 R_10K_0402_G Resistor, 0402 R1-2 R_330_0402_G Resistor, 0402 R_6K2_0402_G Resistor, 0402 SHT35 Temp and humidity sensor SMA_SMD Surface-mount SMA, straight T_ALS-PT-315C Phototransistor, ambient light, SMT...
-
Page 27: References
Radiocrafts AS customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Radiocrafts AS for any damages resulting from any improper use or sale.
