  • Page 1 User Manual RIIoT Development Kit...
  • Page 2: Table Of Contents

    USER MANUAL RIIOT DEVELOPMENT KIT RIIoT Development Kit Table of contents RIIOT DEVELOPMENT KIT ..........................2 TABLE OF CONTENTS ............................2 RIIOT NETWORK ..............................3 DEVELOPMENT KIT INTRODUCTION ....................... 4 QUICK START ..............................5 FURTHER DEVELOPMENT ..........................5 DEVELOPMENT BOARD INTRODUCTION ......................6 Block Diagram ..............................
  • Page 3: Riiot Network

    RIIoT Net Controller Socket API Reference SPR SDK SPR SDK User Manual SPR SDK Quick Start Guide SPR SDK API reference Figure 1. RIIoT network – system and documentation overview Page 3 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 4: Development Kit Introduction

    RIIOT DEVELOPMENT KIT Development Kit Introduction The Development Kit (DK) is designed to make it easy for the user to evaluate the RIIoT network and to run preloaded application or to make a user specific application with minimal time and effort.
  • Page 5: Quick Start

    When setting up the development kit, the main task is setting up the gateway. With the development kit the quickest way to do this is to use a PC as the gateway and use the RIIoT Net Controller on Linux-PC or Linux on a VirtualBox.
  • Page 6: Development Board Introduction

    Module article number USB power LED Antenna connector sub 1GHz P1: USB micro PIFA PCB Antenna connector 2.4 GHz RESET button Figure 3: RC188x Development Board Page 6 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 7: Block Diagram

    Regulator 3.3V / 50 mA UART Radiocrafts USB to UA Module PIFA antenna RC1885DB only Buttons: RESET P8: JTAG Programming Connector Figure 4. Block schematic RC188xDB Page 7 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 8: I/O Connection

    DIO_24 TMSC TCKC DIO_16/TDO DIO_17/TDI DIO_25 DIO_26 DIO_27 DIO_28 Not connected for RC1885. Module pin 19-21 are RF port for 2.4 GHz. DIO_29 DIO_30 Not connected Page 8 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 9: Sensor Board Introduction

    Power LED Antenna connector sub 1GHz P1: USB TO PC PIFA PCB Antenna 2.4 GHz (not used) LED/GPIO RESET BUTTON Connector holes P6/P7 Figure 5: Sensor Board Page 9 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 10: Block Diagram Sensor Board

    3.3V / 50 mA 1GHz UART Radiocrafts USB to UA Module LEDs SHT35 Light Buttons: sensor RESET HDC2010 BME680 P14 :Programming Connector Figure 6. Block schematic Sensor board Page 10 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 11: Powering The Sensor Board

    There is also a config button on the board to easily put the module in configuration mode. See datasheets [6] and user manual for details on communication via UART. Page 11 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 12: I/O Connection

    Via EMI bead to module ADC0 (LIGHT_OUT_ANALOG) ADC1 TMSC JTAG programming interface. Do not use. TCKC SENS_1 Reserved for future use. SENS_2 SENS_3 PA_CTR PA_CTR PA_CTR Page 12 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 13: I/O Silkscreen

    On revision 1.0 of the sensor board there are some inaccuracies in the silkscreen print. GPIO numbering is wrong and ADC1 marking is missing. Marking of RXD/TXD are offset. See below ADC1 ADC0 Page 13 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 14: Sht35 Temperature And Humidity Sensor

    The ALS-PT-315C is light sensor that gives an analogue output based on the illuminance (Lux). The output is connected to the analogue input of the sensor module. On the sensor board this sensor is always on. Page 14 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 15: Sl353Lt Hall Detector

    There is a blue LED on the board (D2) that is connected to GPIO-1 of the sensor module. This is used to demonstrate the GPIO output control capabilities of the sensor module. Page 15 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 16: Prototyping With The Sensor Board

    The sensor board is built to fit a commercially off the shelf enclosure named Router Cube from New Age Enclosure. Available at Mouser. The sensor board is not delivered with enclosure. Machining for connectors/antenna is required. Figure 7 Optional enclosure from New Age Enclosures Page 16 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 17: Sensor Board Pcb And Assembly Layout

    Figure 8. Sensor Board PCB component placement, top side Sensor Board Circuit Diagram The circuit diagram of RC1xxx-xSM-SB is in figure 6. For better quality please see PDF in [8]. Page 17 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 18 USER MANUAL RIIOT DEVELOPMENT KIT Figure 9: RC1xxx-xSM-SB Circuit diagram, page 1 Page 18 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 19 USER MANUAL RIIOT DEVELOPMENT KIT Figure 10: RC1xxx-xSM-SB Circuit diagram, page 2 Page 19 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 20: Sensor Board Bill Of Materials

    PUSH_BUTTON_SMALL_ELEVATED Push button, SMD RF module, depend on variant of board RC1682-SSM RC1692HP-SSM RC1180-MSM RC1701HP-MSM Sensor module R3-5 ;R11-14 ;R16;R18;R20; R25-27; R32; R_0402 Resistor, 0402, general Page 20 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 21 R1-2 R_330_0402_G Resistor, 0402 R_6K2_0402_G Resistor, 0402 SHT35 Temp and humidity sensor SMA_SMD Surface-mount SMA, straight T_ALS-PT-315C Phototransistor, ambient light, SMT P15-16 UFL_CONNECTOR U.FL compatible connector Page 21 of 22 2018 Radiocrafts AS User Manual RIIoT Development Kit Rev. 1.00...
  • Page 22: References

    Radiocrafts AS customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Radiocrafts AS for any damages resulting from any improper use or sale.
