RainSoft EC5 Series Installation & Service Manual

Water treatment system
Hide thumbs Also See for EC5 Series:

Advertisement

Table of Contents

Rainsoft Division of Aquion, Inc
101 S. Gary Ave
Roselle, Illinois 60172
1.847.437.9400 or 1.800.860.7638
www.rainsoft.com
EC5 SERIES
WATER TREATMENT SYSTEM
™
Part No.:16843
Rev: B
03/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EC5 Series and is the answer not in the manual?

Questions and answers

Roberto
April 5, 2025

How do I cycle my system?

0
1 comments:
Mr. Anderson
April 5, 2025

To cycle the RainSoft EC5 Series system, follow these steps:

1. From the home screen, press any key to access the main menu.
2. Select "START REGENERATION."
3. Press ENTER or the RIGHT button to enter the manual regeneration menu.
4. Choose one of the two options:
- "Regen Now": Highlight this option and press ENTER.
- Confirm "REGEN NOW" by pressing ENTER again when “YES” is highlighted.
5. The system will begin a 10-second countdown before starting regeneration.
6. The system enters Cycle 1 (Brine Refill), with the piston rod indicator aligned with position number 1.

The EC5 system will then proceed through the regeneration cycles automatically.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for RainSoft EC5 Series

Summary of Contents for RainSoft EC5 Series

  • Page 1 Rainsoft Division of Aquion, Inc 101 S. Gary Ave Roselle, Illinois 60172 1.847.437.9400 or 1.800.860.7638 www.rainsoft.com EC5 SERIES WATER TREATMENT SYSTEM ™ Part No.:16843 Rev: B 03/17...

  • Page 2: Table Of Contents

    Table of Contents Application Limitations................3 Operational Specifications ................3 Installation Instructions ................4–8 System Start Up ..................8–10 Sanitize The Conditioner ................10 System Selectable Settings ................11 Customer Menu, Service Menu and Hidden Keys Flow chart ..12-16 Incoming Water Conditions ( Hardness Settings/Iron Settings) ..

  • Page 3: Application Limitations

    Application Limitations On hardness levels of 60 grains and higher, the system may not achieve a hardness of less than 1 grain, due to high Total Dissolved Solids; some bleed through is possible. Bleed through is also caused by sodium levels higher than 1000 parts per million. In either case, the system can be programmed to minimize these effects.

  • Page 4: Installation Instructions

    Installation Instructions 1. Safety Precautions Important Note: For Massachusetts Residents Only: The Commonwealth of • To prevent accidents and/or injuries, do not hoist the equipment Massachusetts Plumbing Code 248 CMR shall be adhered to. A licensed plumber over your shoulder; use a hand truck to transport the equipment. shall be used for this installation.
  • Page 5 • Align the upper basket with the riser pipe and slowly lower the control valve onto the riser pipe, using a twisting motion. • Align the control valve with the tank. Push down on the control valve and continue to turn it clockwise until the valve O-ring seals against the tank.
  • Page 6 • Ensure that the bypass valve is in Bypass position.. The valve handles should be perpendicular to the pipes ( see Figure 4 Figure 4 9. Install the Drain Line and Air Gap ( Air Gap Not Supplied) 1 /2 •...
  • Page 7 10. Install the Brine Safety Float Important Note: Not Applicable for EC5- CAB models. • Insert the brine well into the brine tank ( see figure 7.1) • Attach the brine well to the brine tank with the overflow elbow. ( see figure 7.2) •...

  • Page 8: System Start Up

    12. Install the Brine Overflow Line (indoors) 1 /2 • Run a inch I.D. brine overflow line from the overflow elbow on the side of the brine tank to an approved drain. 13 Attached the Electrical Connection • Insert the barrel plug from the DC power supply into the mating jack in the back of the control box.
  • Page 9 Salt used for melting ice, such as rock salt, is RainSoft Water conditioners use water softener Block Salt, Bag typically high in impurities and should not Salt (Pellet), or Potassium Chloride. Go to the Main Menu, >...

  • Page 10: Sanitize The Conditioner

    STACK IN G BLOCK SALT - 25 lbs B LOCK S COR R ECT STACKING I NCOR R ECT STACKING 6" Incorrect Stacking Using Correct Stacking Using 8" - 25 lb Salt Blocks - 25 lb Salt Blocks Standard Block Dims Standard Block Dims - 8 x 6 x 8.5 - 8 x 6 x 8.5...

  • Page 11: System Selectable Settings

    SYSTEM SELECTABLE SETTINGS EC5 SYSTEM MODEL SETTINGS & DEFAULTS Model Type _ [EC5-75-CV} Capacity Info Default Settings Max Setting Salt Levels Salt Lbs Used Maximum Unit Size MEDIA TYPES Actual RESIN Backwash Flow Max Salt Level Minum Salting Salting Dose Model (Name) Selectable...

  • Page 12: Customer Menu, Service Menu And Hidden Keys Flow Chart

    FLOW CHART CUSTOMER MENU EC5 FLOW CHART; CUSTOMER MENU MAIN CUSTOMER MENU Program RS VER - 1.2 – 1.4 SALT LEVEL Adjust Salt Level using the SALT LEVEL: 5.0 Up & Down Arrow Buttons. EC5 Home Screen Press ENTER TO SAVE & SALT TYPE: LEFT Arrow TO EXIT SODIUM...
  • Page 13 Daylight Savings TIME ZONE – Correct DEALER INFO On / Off UTC Time setting is DEALER Set Time Zone RainSoft (or Custom) important for Wi-Fi UTC # PHONE Settings to ensure info is 800-724-6763 (or Custom) transmitted correctly. Email Address Remind@rainsoft.com (or...
  • Page 14 (R/L ) MTR1 Targ et: 6 50 EC5 Home Screen ADC V ALUE: 645 DEALER INFO {Pre ss Enter B utton to E xit} DEALER RainSoft PHONE DEALER INFO 800-724-6763 The Phone Number can be Email Address edited in the EC5 by the EC5 Remind@rainsoft.com...
  • Page 15 CONFIGURE SYSTEM MENU Additional Systems Menu FILTER LINK AUX ILIARY SETTINGS SYS TE M SETUP SYS TE M OVE RRIDE S Filte r Mode l Acti vate Aux 1 Units 90% Exha usted Regn Off / EC5-FLT OFF / 1 / 2 / 3 English / Met ric Immediate / Dela yed Filte r S ize...
  • Page 16 FLOW CHART HIDDEN KEYS EC5 FLOW CHART; EC5 SERVICE MENU Screen EC5 HIDDEN KEYS SERVICE MENU Program RS VER - 1.2 – 1.4 >Configure System >System Info >System Testing >Dealer Info >Wi-Fi Settings Press UP ARROW 2x Additional Systems Enter Authorize Code: <...

  • Page 17: Incoming Water Conditions ( Hardness Settings/Iron Settings)

    Incoming Water Conditions (Hardness Settings/ Iron Settings) Hardness setting is adjustable to match incoming water hardness in grains/gallon. Range is 2 – 200 grains per gallon gpg), in increments of 1, with a default of 10. Iron level is adjustable to match incoming iron level in parts per million (ppm).

  • Page 18: Troubleshooting Guide

    Troubleshooting Guide Symptom Cause Solution 1. The system is not regenerating often enough. 1. System is running out of capacity because the 1. Hard water/ Hard water hardness or capacity setting is incorrect. Test bleed-through the raw water, verify model, and reset if necessary.
  • Page 19 Troubleshooting Guide Symptom Cause Solution 6. No brine draw, poor brine 1. Low water pressure. 1. The water pressure must be above 20 psi. draw, or loss of vacuum 2. Plugged injector or plugged injector screen. 2. Inspect the injector and injector screen for If the injector is completely plugged, there will be debris;...

  • Page 20: Exploded Views And Parts Lists

    Valve Exploded View 27 ABCD 20 AB 26 ABCDE 31 AB...
  • Page 21 Valve Parts List Item Quantity Part Number Description 17863 COMPOSITE VALVE BODY 17864 SPACER END 17865 INTERNAL SPACER 17866 INTERNAL SEAL 18160 RETAINER & DOWN FLOW PISTON 13328 O-RING - 017 17869 END PLUG ASSEMBLY 17870 10-24 X .812 SCREW HEX WASHER HEAD 17871 PISTON ROD 17887...
  • Page 22 Control Exploded View...
  • Page 23 Control Parts List Item Quantity Part Number Description 51920 GEN 5-REAR HOUSING ASSEMBLY 51921 RPS MOTOR GEAR DRIVE ASSEMBLY 17501 BRINE GEAR/CAM 51918 SCREW 1/4-20X 1in PAN HEAD PHIL SS 51902 GEN 5-REAR COVER 52106 EC5-FRONT HOUSING ASSEMBLY 51904 GEN5-DOOR EC5 51919 SCREW #4-20x0.25in, PHIL PAB SS 51927...

  • Page 24: Control Wiring Diagram

    POWER CABLE 2-PIN MOTOR CABLE 5-PIN CONNECTOR CONNECTOR FLOW METER 3-PIN REAR HOUSING ASY FRONT HOUSING ASY CONNECTOR FRONT VIEW FRONT VIEW CONNECT POWER CABLE CONNECT MOTOR CABLE TO "24V" TERMINAL J1 TO "MTR1" TERMINAL J4 FRONT HOUSING ASY BACK VIEW EC5 PC BOARD MOUNTED INTO THE FRONT HOUSING CONNECT LED CABLE...

  • Page 25: Water Flow Diagrams

    Water Flow Diagrams When servicing water treatment equipment, it is important to study the operation and flow of the valve. Service The untreated water enters the valve and flows around the piston between the number 2 and 4 seals. The water flows down the side of the valve and down through the mineral tank where the water is treated.
  • Page 26 Brine Make Up Helpful Tip: In this cycle, the system is providing treated water to the outlet. The valve rests in the Service position for 2 hours, while the water dissolves the salt in the brine tank. Backwash The piston moves slightly down and away from the 4th seal. The water Helpful Tip: In this cycle, the system is on enters the valve and flows around the 4th seal and into the outlet port.
  • Page 27 through the resin, it flows up the riser and through the center of the piston. The water flows over the top of the piston past the number 1 seal and out through the drain. See Figure 13. Slow Rinse Helpful Tip: In this cycle, the system is on After all the brine solution is pulled from the brine tank, the air check internal bypass.

  • Page 28: Steps To Successful Service

    8 Steps to Successful Service The following procedure is a complete system check to help diagnose problems with the equipment. If the system fails to perform properly in any of the following steps, please refer to “Troubleshooting Guide for the 8 Steps to Successful Service” on pages 31-32. 1.
  • Page 29 • Disconnect the brine line from the brine float and use a container Important Note: The flow control size is to measure the brine refill rate. The brine refill rate should be close stamped on the side of the flow control. to the value shown in the table below based on your current settings.
  • Page 30 5. Make the Necessary Repairs • • If the system failed to perform properly in one or more of the cycles, make the necessary repairs. • If the system passed the function test by delivering soft water at the end of Step 4 and the water tested hard on arrival, the problem is related to a program or application error.

  • Page 31: Troubleshooting Guide For The 8 Steps To Successful Service

    Troubleshooting Guide for the 8 Steps to Successful Service 1. Understanding the Nature of the Service Call • If the customer reports that the system is producing hard water, the problem is either mechanical or programming in nature. • If the customer describes salty water, noisy operation, the system is using too much salt, or water running to the drain, the problem is not mechanical in nature.
  • Page 32 • If the system is still not counting gallons, disassemble the rotor assembly and check for any obstructions in the housing; remove any visible obstructions. For additional assistance with troubleshooting the “8 Steps to Successful Service”, please contact RainSoft Technical Support at 1- 800-860-7638.

  • Page 33: Disassembly Instructions

    Disassembly Instructions Removing the Control Head • Disconnect the power cord from the back of the control and place the system on bypass. • Remove the rear cover and depress the brine stem to relieve the water pressure ( see Figure 16 •...
  • Page 34 Replacing the Brine Stem • Remove the control head; see page 33. • Remove the screws and end plug assembly ( see Figure 19 • Pull the brine stem from the valve body ( see Figure 19 • Remove and inspect the O-ring at the bottom of the brine stem hole; replace if necessary.
  • Page 35 Replacing the Seals and Spacers • Remove the control head; see instructions page on 33. • Remove the screws and end plug assembly ( see Figure 21 • Remove the seals and spacers with your fingers ( ). If a see Figure 21 spacer is difficult to remove, use a spacer removal tool.
  • Page 36 Replacing the Brine Injector and Screen • Remove the control head; see page 33. • Remove the injector cap screws and injector cap ( see Figure 22 • With a small, flat screwdriver, pry out the injector ( . To see Figure 22 disassemble the injector, pry the throat away from the nozzle and inspect for debris;...
  • Page 37 Replacing the Meter Turbine and Sensor Assembly • Disconnect the power cord from the back of the control and place the system on bypass. • Remove the rear cover and depress the brine stem to relieve the water pressure ( see Figure 16 on page 33 •...
  • Page 38 • To remove the sensor cable, press on the barbed end of the cable with a small flat head screw driver ( see Figure 25 Figure 25 PRY THIS NOTCH TO REMOVE SENSOR CABLE • If it is necessary to remove the sensor cable from the computer board, see “Removing the Computer Board”...
  • Page 39 DISCONNECT MOTOR DISCONNECT POWER FROM THE PCB FROM THE PCB Figure 27 DISCONNECT FLOW METER FROM THE PCB • Remove the screws from the computer board and release the latches on the side of the board • Reverse the procedure for reassembly. Replacing the Drive Motor Before removing the drive motor, make sure the valve is in the Service position.
  • Page 40 Figure 29 FEMALE NOTCH ON BRINE CAM LOCATED AT 3 O'CLOCK POSITION MALE NOTCH ON DRIVE CAM LOCATED AT 9 O'CLOCK POSITION Servicing the Brine Valve Float Assembly EC5 units use two different types of brine valves ( s ee Figure 30A and 30 B Before servicing the brine valve float assembly, the valve must be in the Service position.
  • Page 41 Figure 30 A TUBING BRINE VALVE FLOAT ASSEMBLY RETAINER INSPECT SEALS AND AIR−CHECK Figure 30 B WELL CAP BRINE LINE NUT TUBING BRINE VALVE FLOAT ASSEMBLY WELL MOUNTING NUT BULK HEAD ASSEMBLY BRINE WELL...
  • Page 42 Notes...
  • Page 43 Notes...
  • Page 44 RainSoft Division of Aquion Inc 101 S. Gary Avenue Roselle, Illinois 60172 Main Switchboard: 1.847.437.9400 Customer Service: 1.800.860.7638 www.rainsoft.com...
