- Page 1 D-ALINP Instruction manual...
- Page 3 D-ALINP Instruction manual D-ALINP manual...
- Page 4 Thanks for purchasing our D-ALINP Local Input Panel. Affordable, versatile, but by no means a compromise on functionality – Typically Apart!
-
Page 5: Safety Precautions
D-ALINP Instruction manual Safety precautions • Keep this manual for future reference. • Take care of your connection wires, they should be free of damage. Damaged wires may result in poor performance or malfunctions and can cause damage to installations. -
Page 6: Features And Benefits
LOCAL INPUT CONTROLS damaged, please contact your dealer before opening it. • Take notice that this unit must be protected from moisture and is meant for indoor use only. Features and benefits • Inconspicuous and elegant design • Fits in a standard 2 gang utility box •... - Page 7 D-ALINP Instruction manual needed • Line and microphone inputs • Separate volume control for line and microphone • Line and Microphone input are automatically mixed together. • Push lock volume buttons • Exceptional audio quality...
-
Page 8: Connecting And Installing The Unit
Connecting and installing the unit Please power off your master unit before connecting the D-ALINP. It is possible to use standard low voltage approved wires or cables such as standard CAT5 cables. The D-ALINP will be hardwired to a balanced line input of any suitable device with phantom power between 18V and 48V . - Page 9 D-ALINP Instruction manual...
- Page 10 LOCAL INPUT CONTROLS Do not connect more than one D-ALINP unit on the same cable. This will cause malfunction and possible damage to your main unit and/or D-ALINP. Avoid thick solid wires, these will cause mechanical stress connectors make installation difficult.
- Page 11 D-ALINP Instruction manual First, connect the wires to the 3-pole MSTB connector and install the main electronic frame in the in-wall box with the 4 provided screws. After installation of the electronic metal frame, place and fasten the faceplate with the 4 panel screws to finish the installation.
- Page 12 LOCAL INPUT CONTROLS Using D-ALINP To use the D-ALINP module please see that the balanced input is configured as mono and that a phantom voltage is present. The D-ALINP sums the RCA-cinch inputs to mono. The microphone and RCA-inputs have separate volume control.
-
Page 13: Specifications
D-ALINP Instruction manual Specifications Input sensitivity for nominal -15 dBV, 177 mVrms output (0 dBV) RCA input (@48 VDC phantom) Input sensitivity for nominal -33 dBV, 22.3 mVrms output (0 dBV) MIC input (@48 VDC phantom) Cable length Tested and full functional... - Page 14 LOCAL INPUT CONTROLS Rated input impedance 4 kohm balanced MIC Rated input impedance 8.5 kohm unbalanced line Dimensions (w x h x d) 116 x 115 x 50 mm 4.57 x 4.53 x 1.5 in Cut-out dimensions 102 x 102 mm 4.02 x 4.02 in Mounting depth minimally 45 mm...
- Page 15 D-ALINP Instruction manual Note: The D-ALINP module was designed for use with phantom voltages between 24 VDC and 48 VDC. The specifications in the table above were measured at the maximum phantom voltage of 48 VDC. Lowering this phantom voltage to lead to a lower input range.
- Page 16 Apart Audio nv Industriepark Brechtsebaan 8 bus 1 2900 Schoten - Belgium Company names, product names and trademarks are property of their respective owners. Apart-Audio specifications are subject to change without notice.
