  • Page 1 HIP-Series HDMI over IP Extender User Manual www.agneovo.com...

  • Page 2: Table Of Contents

    HIP-Series HDMI over IP Extenders TABLE OF CONTENTS Getting Started Important Safeguards Safety Instructions Product Description Package Content Panel Descriptions Making Connections and Operations Applications Setup HIP-TA and HIP-RA Choosing a Network Switch Specifications Features Specifications Appendix Maintenance Product Service...

  • Page 3: Getting Started

    Please keep this manual for future reference. Notice: AG Neovo reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice.

  • Page 4: Important Safeguards

    HIP-Series HDMI over IP Extenders Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover • Any product, on which the serial number has been defaced, modified or removed.

  • Page 5: Safety Instructions

    HIP-Series HDMI over IP Extenders Safety Instructions The HIP-Series, HDMI Extender has been tested for conformity to safety regulations and requirements, and has been certified for international use. However, like all electronic equipment’s, the HIP-Series should be used with care. Read the following safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.

  • Page 6: Product Description

    HIP-Series HDMI over IP Extenders Product Description Packing Contents 1) Main Unit. Transmitter or Receiver 2) Power adapter DC 5V/1A 3) IR-TX cable & IR-RX cable 4) User Manual Panel Descriptions Transmitter panel Receiver panel Reset bu�on Status indicator light...

  • Page 7: Making Connections And Operations

    HIP-Series HDMI over IP Extenders Making Connections and Operations 1) Connect the HDMI signal source (Such as DVD, STB etc) to HDMI Transmitter. 2) Connect a Cat5e/6 cable to both the LAN of the transmitter and LAN port of the Receiver.
  • Page 8 HIP-Series HDMI over IP Extenders HDMI Source Point-to-Multipoint HDMI Cable IR Emitter HDMI over IP Extender Transmitter Cat5e Cable Gigabit Switch HDMI over IP Extender HDMI over IP Extender HDMI over IP Extender HDMI over IP Extender Receiver 1 Receiver 2...
  • Page 9 HIP-Series HDMI over IP Extenders Multipoint-to-Multipoint HDMI Source HDMI Source HDMI Source HDMI Cable HDMI Cable IR Emitter IR Emitter HDMI Cable IR Emitter HDMI over IP Extender HDMI over IP Extender HDMI over IP Extender Transmitter 2 Transmitter 3...

  • Page 10: Setup Hip-Ta And Hip-Ra

    HIP-Series HDMI over IP Extenders Setup HIP-TA and HIP-RA An HTTP server is embedded into every HIP-TA and HIP-RA, you can setup the IP address for each unit via web browser. The default IP address of the TX is 192.168.168.55, MAC address is: 00:0b:78:00:60:01.
  • Page 11 HIP-Series HDMI over IP Extenders Step 3: Ping the connected device through the sequence on computer: “Start”→ “Run”→ input “CMD”→ input “ping 192.168.168.55” for HIP-TA or input“ping 192.168.168.56” for HIP-RA, you will receive the reply if the connection is established.

  • Page 12: Choosing A Network Switch

    This section provides various general and specific recommendations for switches to use with HIP-Series. However, there is no substitute for testing in real world situations. If you are in doubt about which network switch to use, the safest approach is to select one from the list of recommended switches below.
  • Page 13 Layer 2 or Layer 3 Switches You will need to determine whether you need a layer 2 or a layer 3 switch for your HIP-Series network. Layer 3 switches cost more than layer 2 switches because they are more complex and handle more network traffic.
  • Page 14 Further Considerations Number of ports: Choose a switch that has enough ports to match the number of HIP-Series devices you will be installing. Switches typically come in 5, 8, 10, 16, 24, 28, 48, and 52-port configurations.
  • Page 15 HIP-Series HDMI over IP Extenders Features - Extends 1080p HDMI signals up to 120 m (400 ft) over a single Cat5e/6 cable - HDMI compliant - HDCP compliant - Supports up to 1080p resolutions - Supports IR transmission for remote control...

  • Page 16: Specifications

    HIP-Series HDMI over IP Extenders Specifications Units HIP-TA HIP-RA Unit Description HDMI over IP Transmitter HDMI over IP Receiver HDMI Compliance HDMI 1.2 HDCP Compliance Cat5e/6: 100 m (330 ft) up to 1080p / Cat5e/6: 120 m (400 ft) when...
  • Page 17 HIP-Series HDMI over IP Extenders Relative Humidity 5% to 90% RH (non-condensation) Package Contents HIP-TA: HIP Transmitter x 1 / Power Adapter x 1 / IR-TX Cable x 1 / User Manual x 1 HIP-RA: HIP Receiver x 1 / Power Adapter x 1 / IR-RX Cable x 1 / User Manual x 1 Note1: Specifications are subject to change without notice.

  • Page 18: Appendix

    HIP-Series HDMI over IP Extenders Appendix Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean this unit. Product Service Europe service.nl@agneovo.com North and South America service.us@agneovo.com Asia and Rest of the World...

This manual is also suitable for:

Hip-taHip-ra
