Summary of Contents for AG Neovo HIP-T
- Page 1 HIP-Series (HIP-T + HIP-R) Installation Manual HDMI Unlimited LAN Extender...
-
Page 2: Table Of Contents
2.1 PACKAGE CONTENTS........................4 2.2 BEFORE INSTALLATION ........................4 2.3 DEVICE DESCRIPTION & LAYOUT ....................7 2.3.1 Front Panel & Rear Panel (Transmitter, HIP-T) ............... 7 2.3.2 Front Panel & Rear Panel (Receiver, HIP-R) ................7 Chapter 3: INSTALLATION ........................8 Chapter 4: GENERAL TROUBLESHOOTING ................8... -
Page 3: Chapter 1: Getting Started
GETTING STARTED 1.1 IMPORTANT SAFEGUARDS Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover • Any product, on which the serial number has been defaced, modified or removed. •... -
Page 4: Regulatory Notices Federal Communications Commission (Fcc)
GETTING STARTED 1.3 Regulatory Notices Federal Communications Commission (FCC) This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Any changes or modifications made to this equipment may void the user’s authority to operate this equipment. -
Page 5: Chapter 2: Introduction
INTRODUCTION The HIP-Series, HDMI extender set is designed to extend your HD display with the resolutions of 1080p/60Hz up to 330 feet (100 meters) away from your HDMI or DVI-D source. Thanks to the use of the TCP/IP protocol, you can transfer your high-definition video over an existing TCP/IP network. See below three examples: A: The Tx and Rx units can extend 100 meters over a single CAT5/6 cable connection point to point. -
Page 6: Package Contents
Before you start the installation of HIP-Series, please check the A. STANDARD package contents. HDMI TRANSMITTER X 1 HDMI RECEIVER X 1 2 POWER ADAPTER (5VDC) X 2 HIP-Series (HIP-T + HIP-R) 3 USER’S MANUAL X 1 Installation Manual HDMI Unlimited LAN Extender 2.2 BEFORE INSTALLATION... -
Page 7: Application Diagram
INTRODUCTION Application Diagram 1 POINT TO POINT HIP-R HDMI Display HIP-R At Remote Location HIP-T HDMI Source HDMI Sou Cable Index Input / Output HDMI CAT-5e/6... - Page 8 Application Diagram 2 ROUTER CONNECTION HDMI Display HDMI Display HDMI Display HDMI Display HIP-R HIP-R HIP-R HIP-R Managed Gb Switch with VLAN / IGMP To max 150 outputs At Remote Location HIP-T HDMI Source Cable Index Input / Output HDMI CAT-5e/6...
-
Page 9: Device Description & Layout
2.3 Device Description & Layout This product is composed of a Transmitter and a Receiver. 2.3.1 Front Panel & Rear Panel (Transmitter, HIP-T) 1 CAT5E/6: Plug in a Cat-5E/6 cable that 3 +5V DC: Connect to 5V DC power supply. -
Page 10: Chapter 3: Installation
4. Make sure CAT-5E/6 LAN cable is tightly connected and not loose. 5. Plug in 5V DC power cord to the power jack of the transmitting unit HIP-T 6. Plug in 5V DC power cord to the power jack of the receiving unit HIP-R. -
Page 11: Chapter 5: Specifications
SPECIFICATIONS ITEM DESCRIPTION UNITS HIP-T HIP-R UNIT DESCRIPTION HDMI Transmitter HDMI Receiver HDMI COMPLIANCE Full HD HDCP COMPLIANCE M-JPEG technology to process image compressing GIGABIT VIDEO BANDWIDTH (10/1000) OVER LAN 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, SUPPORTED RESOLUTIONS 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz RESOLUTION AND DISTANCE... -
Page 12: Chapter 6: Pin & Wiring Standard Definition
PIN & WIRING STANDARD DEFINITION Type A (Receptacle ) HDMI Pin 1 TMDS Data2+ Pin 11 TMDS Clock Shield Pin 2 TMDS Data2 Shield Pin 12 TMDS Clock– Pin 3 TMDS Data2– Pin 13 Pin 4 TMDS Data1+ Pin 14 Reserved (N.C.
