Summary of Contents for Living Images Slimline

  • Page 1 HD Motion Sensor Digital Picture Frame Installation and User Guide...
  • Page 2: Table Of Contents

      Contents Introduction…..........................  2  Features………..........................  2  Package Contents........................  2  Diagrams…………………….......................  3  Remote Control..........................  4  Getting Started…………........................  5  Main Menu………………........................  5  Viewing Your Photo........................  10  Viewing Your Video........................  11  Listening To Your Music......................  12  Delete ……………………….......................  13  Settings............................  14  Set UP……………………………………………………………………………………………………………………………………………… 15  Motion Sensor…………………………………………………………………………………………………………………………………. 16   ...
  • Page 3: Introduction

      Introduction Before operating the unit, please read this manual carefully, and retain it for future reference. This manual will help you use the many exciting and useful features that will make your photo frame viewing more enjoyable. It includes a step by step guide to the basics on photo frame operation including instructions on uploading and playing photos, music or video.
  • Page 4: Diagrams

      Diagrams Rear Overview: Side view:  ...
  • Page 5: Remote Control

      Remote Control     Power  Switch on/off the frame  Setup  Go to setting menu  VOL ‐  Decrease volume  VOL +  Increase Volume  Menu  Go to the menu of the frame  OSD  Open menu for changing OSD  Back to the last step    Combo/ music and photo    Play music    Chang the ratio of display    Arrows  Navigate on screen  Increase the size of the photo     Note: 1) Please remove the plastic tab between the Remote Control Battery Door and the Battery 2) Please point the Remote Control toward the Remote Sensor, which is located on the front right side of the frame’s panel, 10 cm up from the right corner.
  • Page 6: Getting Started

      Getting Started 1) To set up your Digital Photo Frame, you first need to attach the stand. 2) Place the frame horizontally on a flat surface. 3) Insert the power lead into the Digital Photo Frame’s socket marked DC 4) Turn on the Digital Photo Frame by either pressing the POWER button on the back of the unit or pressing the ON/OFF button on the Remote control.
  • Page 7   1.2 Picture Mode/Delete Function    Highlight Photo from the main menu, Press OK to Select the Raid,USB 2.0 or Memory Card which you want to play , then press OK again to access thumbnail mode, press to select the picture you want to play and press ENTER to confirm  ...
  • Page 8   Delete function: In thumbnail mode , Use to select the picture you want to delete , press TOOLBAR to enter into Delete interface and then press ENTER to confirm When the single picture is playing, press SETUP to enter information Bar, and select following items by : Play, Preview, Next, Stop, R_All(means Repeat play all files), Music, Playlist, Info, Rotate, Zoom, Move, than press OK to confirm.
  • Page 9     1.3 Music Mode/Delete Function  Music Play    Highlight Music from the main menu, Press OK to Select the RAID, USB 2.0 or Memory Card which you want to play, then press OK again to access the thumbnail mode, press to select the music you want to play and press ENTER to confirm  ...
  • Page 10   Delete Function : In thumbnail mode , Use to select the Music you want to delete, press TOOLBAR to enter into Delete interface and then press OK to confirm   1.4 Video Mode /Delete Function  Video Play   ...
  • Page 11: Viewing Your Photo

        Highlight Video from the main menu, Press ENTER to Select the RAID, USB 2.0 or Memory Card which you want to play , then press ENTER again to access the thumbnail mode, press to select the video you want to play and press ENTER to confirm Delete Function  ...
  • Page 12: Viewing Your Video

      1.5 Copy function for picture/music/video files When the video is playing, press TOOLBAR to enter video, and select following items by : Pause, FB(fast backward), FF(fast forward), Prev, Next, Stop, R_ALL(repeat play all files), Set A(set a part you want to play), Playlist, Info, Slow F(slow forward), Step F(play part by part), Go to Time, Zoom, Move and then press ENTER to confirm.
  • Page 13: Listening To Your Music

      1.6. Scroll Subtitle function         It supports Scroll Subtitle function when playing Photo, Music and video. The setting steps of Scroll Subtitle as following:   a) Create a TXT file b) Then Save as the TXT file with the code format “Unicode” and named “SCROLL.TXT”...
  • Page 14: Delete

      1.7 Calendar   ...
  • Page 15: Set Up

      1.8. HDMI‐IN Function    Connect the HDMI-out device with the HDMI-IN interface of the frames .Press SOURCE to choose to select input Source “HDMI” HDMI  1.9. Setup Menu        ...
  • Page 16   11.1 Language: German, English, French, Italian 11.2 Slideshow Time: 3S/5S/10S/30S/60S 11.3 Slideshow Mode : Off/On 11.4 Repeat Mode : All /One/Off 11.5 Display Mode: Auto, Fit, Panorama , 11.6 Time: Press ENTER to enter, and then press to adjust the time you want to set: Date, Month, Year, Hour, Minute, Sec 11.7 11.8 Contrast: Use...
  • Page 17: Motion Sensor

      2.0. Motion Sensor  Motion Sensors: Motion Sensor turns frame ON/OFF automatically when it senses movement nearby. 1) Power on the frame 2) Motion Sensor can be operated via Remote Control 3) Go to SET UP menu 4) You can choose Motion Sensor ON/OFF as your requirements 5) You also can choose Motion Sensor Interval times(30s, 1min, 2mins, 5mins, off) 6) Motion Sensor frame will turn ON/OFF automatically when it senses movement nearby.
