Power Module; High - Positive Grid BIAS DISTORTION Product Manual

5. Post EQ (Low, Mid, High)
These controls respectively boost or
attenuate the bass, midrange and high
frequencies after the output stages.
6. Tone
This controls the high and low frequencies
with different distortion stages. You can
switch between Resonate and Tilt mode
using the switch to the left of the this knob.
7. Resonate
In Mode, higher values will boost
Resonate
more high frequencies and preserve
the most low frequencies.
8. Tilt
In Mode, higher values will reduce low
Tilt
frequencies and boost high frequencies. A
lower value will increase the bass and
reduce the highs.
9. Output
Adjusts the output gain for the clipping
stage.
10. Mix
Adjusts the signal balance between
clipping and output stages.
35

Power Module

The Power Module controls the output stage of the effect. You can switch among different power
supply options, selecting from 6V to 18V batteries.
1. Attack
Determines how quickly compression is
applied.
2. Release
Determines how quickly compression
ceases and the signal level recovers.
3. COMP
Adjusts the overall compression amount
sent to the selected battery module.
4. Output
Adjusts the output gain after compression.
5. Battery
Sets the input level (threshold) above
which compression begins. It is affected
by the level of the COMP control.
6V: -45dB~-30dB
9V: -35dB~-20dB
12V: -25dB~-10dB
18V: -15dB~0dB
36
