OWNER'S MANUAL

SAFETY

Important safety instructions for using the INCRA Miter3000SE
Before using the INCRA Miter3000SE, read and follow all of the instructions and safety information in this owner's manual.
When using the INCRA Miter3000SE in conjunction with any other tool, first read and follow all instructions and safety information
°
in that tool's owner's manual.
Never let the saw blade come in contact with the aluminum or steel components of the INCRA Miter3000SE.
°
When using the INCRA Miter3000SE, always keep your hands clear of the saw blade and the line of cut.
°
Always turn off the power and make sure that the saw blade comes to a complete stop before changing the setting of any part of the
°
INCRA Miter3000SE.
Always securely tighten the large black clamping knob before starting any cut.
°
Wear safety glasses, hearing protection, and follow all normal shop safety practices.
°
After making any adjustments to the miter angle or fence position of your INCRA Miter3000SE, always verify safe clearance
°
between the blade and fence before turning on the saw.
After making any adjustments to the fence position on the INCRA Miter3000SE, always make sure that the two socket head screws
°
are securely tightened.
When using the INCRA Flip Shop Stop to position a piece for a cut, always hold or otherwise clamp the board between the stop
°
and the blade.
Manufactured by Taylor Design Group, Inc. P.O. BOX 810262 Dallas, TX 75381
w w w . i n c r a . c o m
by
Before using the INCRA
Miter3000SE, read and
follow all of the instructions
and safety information in
this owner's manual.
©2016 by Taylor Design Group, Inc. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Miter 3000 SE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Incra Miter 3000 SE

Summary of Contents for Incra Miter 3000 SE

  • Page 1 After making any adjustments to the fence position on the INCRA Miter3000SE, always make sure that the two socket head screws ° are securely tightened. When using the INCRA Flip Shop Stop to position a piece for a cut, always hold or otherwise clamp the board between the stop ° and the blade.
  • Page 2 INCRA MITER3000SE OWNER’S MANUAL ASSEMBLY AND CALIBRATION 1. Attach Clamping Knob and T-Clip Fig. 1 Attach Clamping Knob Remove the hex bolt that secures that protractor head and replace with the large threaded knob included in Threaded knob the hardware pack. The washer on the hex bolt must be used with the threaded knob, Fig.
  • Page 3 This one time calibration prepares your INCRA Mi- ter3000SE for work in either miter slot. Just remem- ber that the accuracy of the INCRA Miter3000SE at any subsequent setting is dependent upon the accura- cy of your initial 90° calibration. Verify this im- portant calibration with a test cut and fine tune as necessary.
  • Page 4 OPERATION – CHANGING ANGLE SETTINGS The dual actuator design of the INCRA Miter3000SE provides two levels of adjustment. The front actuator is used for coarse adjustments (5°), while the rear actuator is used for fine adjustments (1/2°). For most mitering work, you’ll have the left hand tooth of the rear actuator engaged at the 0°...
  • Page 5 Do not tighten the rear actuator thumbscrew. As with any mitering tool, odd angle adjustments may require a little trial and error. FLIP FENCE AND FLIP SHOP STOP - CALIBRATION AND OPERATION As you look at your new INCRA Flip Shop Stop and Fig. 15 Flip Shop Stop Flip Fence for the first time you will see an interesting detail.
  • Page 6 Slide Fence to Blade you’ll need to calibrate the extender bar scale. Clamp the INCRA Flip Shop Stop to the 4” fence extend- er. (Use the scale on the short section of fence as a reference for clamping the stop to the same position each time you use it.) Now loosen the 1/4-20 socket...
  • Page 7 INCRA MITER3000SE OWNER’S MANUAL Micro Adjusting Fig. 19 Micro Adjusting To micro adjust your Flip Shop Stop’s position, begin by Loosen (2) socket head screws loosening the (2) socket head screws located on the top of the stop body. Now turn the micro adjust socket head screw to fine tune the stop position, Fig.
  • Page 8 (gold component) of the stop body, Fig. 23. ADJUSTABLE FENCE MOUNTING BRACKET Your INCRA Miter3000SE Fence has been adjusted square to the table at the factory so no further adjustment should be required. If adding a wooden sub-fence, fine adjust- ments to the angle can be easily made as described below.
