Intersil ISL6539 Application Note

®
Introduction
The ISL6539 is capable of providing a complete solution for
the power requirements of DDRI, DDRII or DDRIII memory
systems. The ISL6539 can be configured to operate as a
dual switching regulator or as a DDR regulator. This
application note will focus on the ISL6539 configured as a
DDR regulator. For information on the ISL6539 configured
as a dual switching regulator, refer to either the datasheet[1]
or to application note AN1278.
As a DDR regulator, the ISL6539 provides control and
protection for both the V
DDQ
providing V for the DDR system. Both V
REF
are provided through synchronous buck regulation. V
provided via a low current buffer.
The switching frequency is fixed at 300kHz for both the
V and V regulators. The two channels can be phase
DDQ TT
shifted 90° in order to minimize interaction. The ISL6539
incorporates voltage-feed-forward ramp modulation, current
mode control, and internal feedback compensation, which
provides fast response to input voltage and output load
transients.
Protection features include undervoltage and overvoltage
protection as well as a programmable overcurrent protection
feature that utilizes the r
DS(ON)
more complete description of the ISL6539 can be found in
the datasheet.
Quick Start Evaluation
The ISL6539EVAL1 board is shipped 'ready to use' right
from the box. The box includes this application note, the
ISL6539 datasheet, and the evaluation board.
The evaluation board supports testing with laboratory power
supplies. Both regulated outputs can be exercised through
external loads. There are posts available on the two
regulated output rails for drawing a load and/or monitoring
the voltages. An LED indicates the status of the PGOOD
signal. There are also three scope probe points that allow for
in depth analysis and two posts available to monitor the
enable signals for either channel. Four jumpers have also
been provided for control and monitoring purposes.
Recommended Test Equipment
To test the full functionality of the ISL6539, the following
equipment is recommended:
• Two laboratory power supplies
• Two Electronic Loads
• Four-channel Oscilloscope with probes
• Precision Digital Multimeters
DDR Power Solution Using the ISL6539
Application Note
and V rails while also
TT
and V
DDQ TT
REF
of the lower MOSFET. A
1
1-888-INTERSIL or 1-888-468-3774
October 30, 2006
CIRCUIT SETUP
Refer to Figure 1 for locations of the jumpers, connectors
and components described in the following sections.
JUMPER SETTINGS
There are four jumpers on the board. Shunting jumper JP3
pulls the EN1 pin to VCC and is used to enable Channel 1,
which is the V
DDQ
Channel 2, which is the V
the input rail for the V
V rail is to be disabled and the V
DDQ
the V rail must be energized from an external power
DDQ
supply and a 0.01µF capacitor should be installed in location
is
C21 for the V
TT
capacitor for the V
Jumper JP1 can be used to monitor the ISL6539 bias current
by connecting an ammeter to the two jumper pins. If the bias
current is not being monitored, this jumper must be shunted.
Jumper JP5 is used to set the phase angle between the two
switching regulators. Refer to Figure 1 for the jumper
positions relating to the desired phase angle. Table 1 also
provides a detailed description of the jumper descriptions
and positions.
JUMPER POSITION
JP1 Shunted
Shunted
JP3
Removed
Shunted
JP4
Removed
Toward
VINPRG
JP5
Away from
VINPRG
TABLE 1. DETAILED DESCRIPTION OF THE JUMPER
SETTINGS
CONNECTING LOADS
Loads should only be connected to the V
Loading V : Connect the positive terminal of an
DDQ
electronic load to the VDDQ post (J5). Connect the return
terminal of the same load to the adjacent GND post (J7).
Loading V - Sourcing Current: To test V
TT
regulator sources current, connect the positive terminal of an
electronic load to the VTT post (J6). Connect the return
terminal of the same load to the adjacent GND post (J9).
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
All other trademarks mentioned are the property of their respective owners.
Author: Douglas Mattingly
regulator. Shunting jumper JP4 enables
regulator. It should be noted that
TT
regulator is the V
TT DDQ
rail enabled, then
TT
rail to soft-start properly. C21 is the soft-start
rail, as shown in the schematic.
TT
FUNCTION
An AmpMeter may be connected across
these pins to measure IC and GATE Drive
current
CH1 enabled
CH1 disabled
CH2 enabled
CH2 disabled
This will tie VIN pin to the input voltage for
feed forward. It will also program CH2
PWM to phase lag CH1 by 90°
This will tie VIN pin to GND, disabling
input voltage feed forward, and will also
program in phase PWM for CH1 and CH2
DDQ
TT
Copyright Intersil Americas Inc. 2006. All Rights Reserved
AN1278.0
rail. If the
and V rails.
TT
while the
