FirsTime Gears Grandfather Clock Instruction Manual page 4

3. While facing the front of the BASE UNIT (G), fit SIDE PANEL B into the
grooves on the left side of the clock base and attach it from the inside with
SCREWS and the FLAT WASHERS using a Phillips head screwdriver. See
Figure 1. Repeat the process using SIDE PANEL C on the right side of the base.
4. Fit the BACK PANEL (D) into the grooves of the side panels at the back of the
cabinet and the base unit (Figure 2).
B
LEFT
SIDE PANEL
G
BASE
CABINET
FIGURE 1
SIDE PANEL
C
RIGHT
4
FIGURE 2
BACK PANEL
D
