Denial of Login

Violation Code Reason for Login Denial
1 Not currently authorized.
I.D. Systems, Inc. One University Plaza, Hackensack, NJ 07601
Tel: 201-996-9000; Fax 201-996-9144; email:
Driver Type(optional)
The type of driver access is displayed on the top line once
authorized, indicating, for example, whether the current
user is a standard, authorized user (shown), a master user,
an administrative user, etc. The displayed options are:
•
Authorized User: Standard user
•
Master User
•
Temp User: User assigned temporarily by a Master
User
•
MAINT User: Logged in using system-configured
maintenance ID and PIN
•
ADMIN User: Logged in using system-configured
maintenance ID and PIN
•
MAINT (H) User: Logged in using default
maintenance ID and PIN (only available on new
VACs prior to first database synchronization)
•
ADMIN (H) User: Logged in using default
administrative ID and PIN (only available on new
VACs prior to first database synchronization)
•
All Users: System is in bypass mode, allowing any ID
to start the vehicle (Security LED will be flashing)
•
All Trained: System is in bypass mode, allowing any
valid driver ID to start the vehicle (Security LED will
be flashing)
Login Denial Screen
Violation Code: Number in parenthesis indicates the
reason for denial. See explanations in table below.
In all cases, operator should press the ENTER key to
restart the login process.
Explanation
Driver is not authorized for that time period on
that vehicle (set using Console's System
Admin Tool), but would otherwise be
support@id-systems.com
Installation
000-0144-01
Page 21 of 41
