Johnson Controls S1-TTSCC01 User's Information Manual page 12

542937-UUM-A-1010
B. Deleting an Existing Program Schedule
Delete?
Delete this schedule?
No
C. Viewing an Existing Program Schedule
Schedule Viewer
View
(Active in Calendar)
Schedule 3
Mo Tu We Th Fr
Awake Day Return
73° 70° 73° 70° 70° 65°
6:00am 8:00am 5:00pm
D. Importing / Exporting Program Schedules
Step 1 - Select Import or Export functionality.
For Import
Step 2 - Insert the USB into the bottom of the thermostat when prompted.
Step 3 - When prompted that import is complete, remove USB from drive.
Step 4 - Select OK after import is complete.
For Export
Step 1 -
Step 2 - Insert the USB into the bottom of the thermostat when prompted.
Step 3 - When prompted that export is complete, remove USB from drive.
Step 4 - Select OK after export is complete.
E. Assigning Program Schedules to Calendar
Schedule
Select Schedule: Assign to Calendar
Energy Saver
Winter
Schedule 1
Dec Jan Feb Mar
Schedule 2
Schedule 3
June July Aug Sep Oct Nov
Summer
Cancel
12
Step 1 - Press Yes.
Yes
Step 1 - Select Schedule to view by pressing left or
right arrows.
Step 2 - Select Day to view.
Sa Su
Step 3 - Press Close.
Sleep
73° 70°
10:00pm
Close
Step 1 - Select Schedule to assign to calendar by
pressing up or down arrows.
Step 2 - Select individual months, Seasons, or All
Spring
Year.
Apr May
Step 3 - Repeat steps 1-2 for each schedule's cal-
endar assignment.
Step 4 - Press Done.
Fall
NOTE: In order to run a program schedule, it must
Done
be assigned to the calendar.
Johnson Controls Unitary Products
