Save and activate the configuration on firewall A.
5. Firewall B - Addresses
Go to Objects -> Address book -> InterfaceAddresses.
Edit the following items:
Change lan_ip to 192.168.2.1
Change lannet to 192.168.2.0/24
Change wan1_ip to 192.168.110.2
Change wan1net to 192.168.110.0/24
Go to Objects -> Address book.
Add a new Address Folder
In the new folder, add a new
Name: fwA-remotenet
IP Address: 192.168.1.0/24
Click Ok
In the same folder, add a new
Name: fwA-remotegw
IP Address: 192.168.110.1
Click Ok
6. Firewall B – Pre-shared keys
Go to Objects -> Authentication Objects.
Add a new Pre-Shared
General:
Name: fwA-psk
Shared secret:
Select Passphrase and enter a shared secret
Click Ok.
called RemoteHosts.
IP4 address:
IP4 address:
Key.
