Turning Technologies QT2 Quick Start

QT2
quick start presentation mode
Channel
Indicator
OK
Channel
Symbols
CHANGING THE CHANNEL
Use the steps below to manually set the channel or
use the Find Channels function to find a receiver
within range.
WARNING: If the lock symbol appears next to the
channel number, the channel cannot be changed.
1. Press the Channel button.
2. Use the number pad to enter the new channel
number.
3. Once the channel number has been entered,
press OK.
FIND CHANNELS
Use the steps below to find a receiver within range.
1. Press the Channel button.
2. Press the middle function key below
The QT2 scans for receiver(s) within range.
3. Use the arrows to scroll through available
channels.
4. Press OK to select the channel.
The QT2 is an audience response device used when a
presenter wants to gather immediate feedback from
the audience.
Battery
Indicator
Function
Keys
Up, Down,
Left, Right
Toolbox
Number
Pad
RESPONDING
During the presentation, the QT2 prompts you to enter
the proper response type. An indicator appears in the
top left side of the screen for special question types.
Numeric Response question
123..
Multiple Response question with
3,1,2..
numeric answer values
Multiple Response question with alpha
C,A,B..
answer values
Short Answer and Essay
question
When sending a response or when a response is
successfully received, an icon appears at the bottom
center of the screen. The following are graphic
representations of these icons:
The response is being sent.
The response was sent successfully.
866.746.3015
THE TOOLBOX
Send Message - Send a message to the presenter. The presenter is
unable to respond via the same method.
NOTE: The presenter may have this feature disabled in the software.
If disabled, you will see "Not Open" when trying to send a message.
Your ID - Assigns an alphanumeric identification to device.
Settings - Press the function key below OK to open the settings and use
the arrow keys to scroll through the options. The settings contain:
• Device Info - Displays the Device ID.
• Contrast - Press the left/right arrows to adjust the contrast
of the objects. Press OK to save.
• Brightness - Press the left/right arrows to adjust the backlight
luminosity of the LCD display and the keypad on the QT2.
Press OK to save.
EXAMPLE SCREENS
TURNINGTECHNOLOGIES.COM
Single Response - Single Response
questions are multiple choice
questions, where only one answer
is selected. Once the selection has
been made, the response is sent to
the presenter.
Multiple Response - Multiple
Response questions have more
than one possible answer. Use the
number pad to enter your answer
choices and then press OK to
transmit your answer choices. Your
response may be alpha or numeric.
Numeric Response - Numeric
Response questions require a numeric
value to be entered. Use the number
pad to enter your answer and press
OK to submit your answer choice.
Essay and Short Answer - Essay and
Short Answer questions require a text
response. Once the text has been
entered, press OK to transmit your
answer.choice.
Invalid Response - If you see this
screen after sending a response,
it means that the response was
invalid. For example, answer
options are A - D, and you
submitted E as your answer choice.
Incorrect Channel - This screen
is to alert you that the QT2 is not
on the correct channel or that the
device is unable to communicate
with the receiver.
Polling Closed - This screen
indicates that polling is closed and
answers are not being accepted.
