Summary of Contents for Ropox 25-20526
-
Page 1: User Manual
All-in-One Walking Trainer User Manual 25-20035, 25-20526 May-19 Pdf 6006... -
Page 2: Table Of Contents
Brakes Lift using the walking trainer General Lift from wheelchair/chair Walking training General Placing in wheelchair/chair Mounting instructions 25-20035, 25-20526, 25-20135 Mounting of steering device Technical information Maintenance Daily check Cleaning Monthly maintenance Annual inspection Trouble shooting Declaration of conformity... -
Page 3: General On The Walking Trainer
Therefore, in order to obtain optimum safety this Manual must be read carefully before use. Ropox A/S shall only be responsible for the safety, reliability and performance of the walking trainer if the following instructions are observed: •... -
Page 4: Charging The Battery
Operation General 1. Check that the emergency stop has been released, If not, turn the button clockwise until release. 2. The walking trainer is operated by means of the hand control unit. The two upper buttons control the lifting/lowering movement, whereas the two lower buttons control the leg spreading facility. -
Page 5: Safety Function, Lifting Motor
Operation Safety function, lifting motor The lifting motor is provided with a safety device protecting against jamming. If the lifting arm meets with resistance during lowering, the movement of the arm will stop automatically. Thus, a person cannot get jammed between the lifting arm and the bed/chair. -
Page 6: Lift Using The Walking Trainer General
Lift using the walking trainer General • Before lifting a person it is important to be familiar with the walking trainer and that it works satisfactorily. • Also, it is important to choose the right size of sling for the lifting operation to be performed. - Page 7 Walking training General The carer may walk in front of or beside walking trainer, instructing supporting the client. Raising or lowering the sling frame will relieve the client depending on the phase of walking training. Use the hand support to begin with in order to give the client something to hold on to and to use for pushing/steering.
- Page 8 Height adjustment of hand support Press red button, afterwards pull locking tap. Hand support can now be pulled upwards or pushed downwards for adjustment of correct height for user.
- Page 9 Mounting Instructions Assembly of: 25-20035 Walking Trainer 150kg 25-20526 Walking Trainer 200kg 25-20135 Walking trainer unit Note! Assembly of 150kg and 200kg Walking Trainers is identical. The only difference is Screws the undercarriage. • Place the lifting mast in the mast holder on the undercarriage.
- Page 10 Mounting Instructions Dismounting • Brake the rear wheels. • Loosen the tightening handle. • Note! Do not unscrew it completely. • Lift the hand support off the mast holder. • Note! It may be stuck owing to the clamping plates. •...
-
Page 11: Technical Information
Technical information Frame Material: St.37 Surface: Powder-coated in the colours RAL 4006 traffic purple, RAL 4007 purple violet and PHM 7812/CWS black. Wheels Front: Diameter Ø75 mm double-wheels with directional stabilisation. Rear: Diameter Ø100 mm with brake. Motors Lifting motor Leg spreading motor Type designation LA34.4... - Page 12 Technical information Control unit Type designation CBJ2, (150/200kg) Mains voltage 100-240V Output voltage 24V DC Max. output current 10,8A Protection IP65 Note! The control units of the 150kg and 200kg walking trainers are not identical. Therefore serial number of the product must be stated when ordering...
- Page 13 Technical information Dimensions 25-20035 25-20526 150kg 200kg Lifting capacity 150 kg 200 kg Min. lifting height, lifting hook 150 cm 150 cm Max. lifting height, lifting hook 190 cm 190 cm Lifting travel 40 cm 40 cm Min. height of handle...
-
Page 14: Cleaning
Maintenance Always make sure that the mechanical and electrical systems of the walking trainer operate satisfactorily. In case of malfunction stop the walking trainer and check or repair it, as required. Malfunction may be a symptom of defects that may get worse and jeopardise the safety in critical situations. -
Page 15: Trouble Shooting
Trouble shooting If the walking trainer does not operate satisfactorily, check and test the following functions before contacting an authorised distributor. 1. Has the battery been charged? 2. Has the emergency stop been released? 3. Have all plugs been inserted correctly? 4. -
Page 16: Declaration Of Conformity
Declaration of conformity EU – Declaration of conformity The undersigned hereby declares that the following All-in-One products: 25-20035 All-in-One, 150kg, Walking Trainer, convertible 25-20526 All-in-One, 200kg, Walking Trainer, convertible with the following accessories: 25-20135 Walking trainer unit for All-in-One 25-29950... -
Page 17: Claims Deadline And Service
The right to complain shall not apply if the product is not subjected to service inspection at least once a year according to the procedures described in the ”Service Manual”. Remedy of defects must always be carried out by an authorised Ropox distributor. Service Always make sure that the mechanical and electrical systems of the walking trainer operate satisfactorily.
