SITEM RF Remote Controls/Clickers
2.1.31.
Clickers shall communicate with remote controls on 2.4 GHz frequency.
2.1.32.
Clickers shall be able to communicate with base station remotes within a
range of 75 ft.
2.1.33.
Clicker shall support the ability bind to a specific base station.
2.1.34.
Clicker shall provide participant feedback by using green led to indicate
that message was received by the Base Station.
2.1.35.
Clicker shall provide participant feedback by using an Answer LED.
2.1.36.
The answer LED light will remain Off while there is no questions to be
answered, meaning the base station is not receiving answers
2.1.37.
The answer LED light will turn on solid red, when the base station is
enabled to start receiving answers.
2.1.38.
The answer LED light will remain On but change color to Green when
answer is received by the base station.
2.1.39.
The answer LED light will flash red if remote fails to send an answer to
the base station.
2.1.40.
During the remote-base station Simple MAC binding process:
2.1.40.1. The answer LED light shall turned green after a remote
successfully binds to its base station.
2.1.40.2. If the remote is unable to bind then the answer LED light will
flash red. This should only happen if a remote is having difficulties
communicating with the base station. For example the base station
power is off.
2.1.41.
The power LED will be Off when Remote is not in used.
2.1.42.
The power LED will be On solid blue when Remote is powered up.
2.1.43.
The Battery level indicator shall be implemented by using an LED battery
level indicator..
2.1.44.
Clicker shall not have a dedicated power switch.
2.1.45.
Clicker shall be able to power on by pressing any of the 7 keys on the
keypad.
2.1.46.
Clicker shall power off by pressing down and holding any key for 10 sec.
2.1.47.
Clicker shall power off after 60 minutes of inactivity.
2.1.48.
Clicker shall support 6 buttons that will be used for multiple choices
answers.
Request for Information
Alchemy Systems L.P.
RFI: Radio Frequency Remotes
