2.1.49. Clicker shall support a 7
This key will display a (
2.1.50.
2.1.51. Clickers buttons shall be color coded as:
2.1.51.1. Green - 1
2.1.51.2. Red – 2
2.1.51.3. Purple – 3
2.1.51.4. Blue – 4
2.1.51.5. Yellow – 5
2.1.51.6. Orange – 6
2.1.51.7. Teal – (
NOTE: use same colors as the current IR remote controls.
2.1.52. Clickers' buttons shall be labeled:
2.1.52.1. Number 1 on the button with "/" and a check mark √. ( 1 / √) .
2.1.52.2. Number 2 on the button with "/" and an X. ( 2 / X)
2.1.52.3. Number 3 on the button.
2.1.52.4. Number 4 on the button
2.1.52.5. Number 5 on the button
2.1.52.6. Number 6 on the button
2.1.52.7. Symbol "
2.1.53. Clickers buttons positions should be equally distributed on the key pad
area in the following order:
( 1/√ ) ---- ( 2/X )
( 3 ) ---- ( 4 )
( 5 ) ---- ( 6 )
( )
Request for Information
th
button to be used for remote binding purposes.
) symbol on it.
)
" on binding button.
