Table 1: VMA1615/1626/1628/1630 Feature Callout Numbers and Descriptions
Callout Physical Features: Description and References
1 24 VAC, Class 2 Supply Power Terminal Block (see
2 Device Address DIP Switch Block (see
3 Binary Outputs, 24 VAC Triacs (see
4 Configurable Outputs: Voltage Analog Output (0–10 VDC) and Binary Output (24 VAC Triac)
(VMA1630, 1626, and 1628 (see
5 Dual Port Fitting (see
6 Manual Override Button (see Mounting)
7 Coupler Bolt (see Mounting)
8 Controller Coupler (see Mounting)
9 Universal Input: Voltage Analog Input (0–10 VDC)
Resistive Analog Inputs (0–600k ohm) (see
0–2k Potentiometer
RTD: 1k Nickel, 1k Platinum, or A99B SI
NTC: 10K Type L (10K Johnson Controls Type II is equivalent to Type L) or 2.252K Type II
Dry Contact Binary Input
10 FC Bus Terminal Block. May also be used for N2 connections. See
N2 Protocol As
11 EOL (End-of-Line) Switch (see
12 SA Bus Terminal Block
13 Modular Port (FC Bus) RJ-12 6-Pin Modular Jack (see
14 Modular Port (SA Bus) RJ-12 6-Pin Modular Jack (see
15 Captive Spacer and Screw (see
16 LED Status Indicators (see
