Light Limiting Ring Quickstart Guide Safety & Warranty Manual Important: Download the Holiday Party Smart app from the App Store. Support For the latest information about this product (documentation, technical specifications, system requirements, compatibility information, etc.) and product registration, visit ionaudio.com.
Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or if it has been dropped into water. Contact ION Audio to return the product to a service center for examination and repair.
Holiday Party Smart will automatically turn on when plugged in. Use the remote control or the Holiday Party Smart app on your smartphone to turn the unit on and off, or to set an automatic timer. Unplug when not in use.
Page 6
You can also select the speed of the light effects. If you are using multiple Holiday Party Smart units, you can select ALL at the top of the app to control all devices at once.
Page 7
Features Remote Control Sensor: Aim the remote control here to adjust the options. Thumbscrew: Loosen and tighten this at the angle you want the light to be projected. Note: Attach the included Light Limiting Ring to reduce the overall spread of the lights. Stake: Place this into the ground to secure Holiday Party Smart.
Remote Control Use the remote control to start/stop the motor, set the light timer, select individual colors, and power the unit on/off. Point the remote control at the front sensor on the dome light and press the button of the option you would like to select. See the diagram for button descriptions. Note: Before using the remote control for the first time, pull out the tab attached to the battery compartment.
Page 9
Still: When Holiday Party Smart is first turned on, it will default to Still. In this mode, all 6 colors are on, and the lights are static (no motion). At any time, a color can be selected to toggle that color on or off.
Anillo limitador de luz Guía de inicio rápido Manual sobre la seguridad y garantía Importante: Baje de la tienda de aplicaciones la Holiday Party Smart APP. Soporte Para obtener la información más reciente acerca de este producto (documentación, especificaciones técnicas, requisitos de sistema, información de compatibilidad, etc.) y registrarlo, visite ionaudio.com.
Nunca opere este producto si tiene un cable o enchufe dañado, si no está funcionando correctamente o si se ha caído o dañado, o si se lo ha dejado caer en el agua. Contáctese con ION Audio para retornar el producto un centro de servicio con fines de examinación y reparación.
Page 12
Esto brindará un área de cobertura de 24,4 m (80 pies) de ancho por 15,2 m (50 pies) de alto. Sujete la estaca para insertar la Holiday Party Smart en la tierra. Como alternativa, si utiliza el Holiday Party Smart en una superficie plana, afloje el tornillo de mariposa para quitar la estaca y sujete el soporte en su lugar.
Page 13
ALL en la parte superior de la aplicación para controlar todos los dispositivos a la vez. Si desea cambiar el nombre de sus unidades Holiday Party Smart, toque Edit botón en la parte superior de la aplicación e ingrese un nuevo nombre.
Page 14
Características Sensor control remoto: Apunte el control remoto hacia aquí ajustar las opciones. Tornillo de mariposa: Aflójelo y ajústelo según el ángulo en el que desea proyectar la luz. Nota: Coloque el anillo limitador de luz incluido para reducir el ángulo de dispersión de las luces. Estaca: Colóquela en el suelo para sujetar la Holiday Party Smart.
Page 15
Instrucciones del control remoto Utilice el control remoto para encender/apagar el motor, Ajuste el temporizador de la luz, seleccionar los colores individuales y encender/apagar la unidad. Apunte el control remoto al sensor delantero del domo de luces y pulse el botón de la opción que desea seleccionar. Consulte las descripciones de los botones en el diagrama.
Page 16
Estático: Cuando el Holiday Party Smart se enciende por primera vez, entrará por defecto al modo Estático. En este modo, los 6 colores se encienden y las luces permanecen estáticas (no se mueven).
Page 17
Parpadeo: Pues este botón para crear efectos de parpadeo a diversas velocidades. Pulse este botón varias veces para alternar entre las siguientes velocidades: • Parpadeo lento: Las luces parpadearán durante 3 segundos y luego cambiarán a una nueva combinación de colores abruptamente. En cualquier momento se pueden encender o apagar los colores individuales.
Specifications are subject to change without notice. Trademarks & Licenses ION Audio is a trademark of ION Audio, LLC, registered in the U.S. and other countries. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are registered trademarks of Google Inc.
