- Page 1 GG-R REFRIGERANT SENSOR Installation and Operation Manual...
- Page 2 GG-R Warning Use this product only in the manner described in this manual. If the equipment is used in a manner not specified by Calibration Technologies, the protection provided by the equipment may be impaired. This equipment should be installed by qualified personnel.
-
Page 3: Table Of Contents
GG-R Table of Contents General description . . . . . . . . . . . . . . . . . . . . . 4 Installation . -
Page 4: General Description
GG-R General Description Installation Locating the sensor The GG-R sensor is a +24 VDC, three-wire, 4/20 mA sensor for HFC, CFC and HCFC refrigerants which One of the most important considerations when utilizes proven IR (infrared) sensor technology for installing GG-R sensors is that they must be easily very accurate and reliable leak detection. -
Page 5: Installation Guidelines
GG-R Installation Guidelines: • Always mount the sensor vertically. • Must be easily accessible for calibration and 6.5" maintenance. 2.0" • Mount the sensor close to the potential leak source. • For optimum leak detection, mount sensor 1’ – 2’... -
Page 6: Wiring
GG-R Wiring Electrical wiring must comply with all applicable codes. Electrical Power: 24 VDC regulated, 300 mA. Output: Linear 4/20 mA output. Monitoring equipment may have a maximum input impedance of 700 ohms. Cable Recommendation: 18/3 shielded, stranded cable with drain wire (General Cable C2535A or equivalent). -
Page 7: Operation
• Apply span gas at 0.5 to 0.8 L/min. Calibration • Sensor should react to gas within 20 seconds. The GG-R Sensor comes factory calibrated and should • Once the output signal has peaked (or 3 minutes require only minimal adjustments after installation. -
Page 8: Zero-Filter Mode
• Adjust the 4mA pot until the control panel reads Zero adjustment zero. Zero-filter mode (deadband mode) The default operation mode of the GG-R Sensor has Calibration an active deadband to eliminate the display of signals gas port within the zero noise of the sensor. To change or view the zero-filter mode, follow the procedure below: •... -
Page 9: Maintenance
GG-R Sensor Life Maintenance Expected sensor life of the GG-R is seven to ten years. The GG-R was designed for long life and minimal Failure of the infrared sensor happens normally when maintenance. For proper operation it is essential the infrared optics reach the end of their useful life. If that the test and calibration schedule be adhered to. -
Page 10: Specifications
GG-R Specifications Wiring Connections: 3-conductor, shielded, stranded cable with drain wire: Temperatures down to -10°F (max cable run): Input Power: +24 VDC, 300mA 1500 ft:18AWG cable (General Cable C2535A or equal) Detection Principle: Infrared Temperatures down to -40°F (max cable run):... -
Page 11: Warranty
No goods shall be returned to CTI until receipt by the buyer of shipping instructions from CTI; and c) the right of CTI to require that the buyer provide proof of purchase such as the original invoice, bill of sale or packing slip to establish that the product is within the warranty period. - Page 12 GG-R-DOC1-1 20190208 ctiengineering.com | 866-394-5861...
