Attention:
Carefully read through the instal-
lation and operating instructions
and safety information before
installing and putting the unit into
service.
These Instructions must always
be issued to the owner/user.
Installation and Operating
Instructions
JUDO BIOSTAT-COMBIMAT
Water Treatment Device
Model BST-CA
Valid for: Canada
BST-CA
Advertisement
Table of Contents
Related Manuals for Judo BIOSTAT-COMBIMAT BST-CA
Summary of Contents for Judo BIOSTAT-COMBIMAT BST-CA
- Page 1 Installation and Operating Instructions JUDO BIOSTAT-COMBIMAT Water Treatment Device Model BST-CA Valid for: Canada Attention: Carefully read through the instal- lation and operating instructions and safety information before installing and putting the unit into service. These Instructions must always be issued to the owner/user.
- Page 2 Germany Trademarks: Trademarks used in this document are protected and registered trademarks of the respective holder. © JUDO Wasseraufbereitung GmbH D-71364 Winnenden All rights reserved. Reprints – even of extracts – is only permitted with special written approval. JUDO BIOSTAT-COMBIMAT...
- Page 3 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept interference received, including interference that may cause undesired operation. JUDO BIOSTAT-COMBIMAT...
-
Page 4: Table Of Contents
5.4 Cleaning - Flushing....18 5.5 Warning message "Battery low" 18 5.6 Mounting of the panelling ..18 5.7 Replacing the batteries....18 5.8 Modifications / changes / spare parts........... 19 5.9 Stoppages ......... 20 6. Fault..........21 JUDO BIOSTAT-COMBIMAT... -
Page 5: About This Operating Instructions
Apart from the instruction manual and the laws governing health & safety applicable in the country and place of use, the recognised technical regulations for safe and proper work must also be observed. Fig. 1: Built-in rotary flange JUDO BIOSTAT-COMBIMAT... -
Page 6: Safety Information And Dangers Due To Non-Compliance
Units (SI = System International), the follo- wing units are used: Units Conversion °F °F = 9/5 °C + 32 kPa = 0.001 N/mm² 1 m³/h = 4.4 gpm ¾" DN 20 1" DN 25 1½" DN 40 JUDO BIOSTAT-COMBIMAT... -
Page 7: Intended Use
The water treatment devices are only to be used in a technically perfect condition, for their intended use, safely and aware of the dangers and with full observance of the instruction manual! Have any malfunctions corrected imme- diately! JUDO BIOSTAT-COMBIMAT... -
Page 8: Water Pressure
1 = Pressure reducer Fig. 2: Pressure reducer upstream of the water treatment device. For a water pressure of 73 psi (500 kPa) to 116 psi (800 kPa) we recommend the installation of a pressure reducer. JUDO BIOSTAT-COMBIMAT... -
Page 9: Product Information
When installing the water treatment devices Consumer Health Protection and Veterinary in the feed-pipe to the water heater, ensure Medicine). that the safety valve of the water heater is located after the water treatment device in the direction of flow. JUDO BIOSTAT-COMBIMAT... -
Page 10: Requirements For The Place Of Installation
It is suitable for both, -horizontally and verti- cally mounted pipes. The built-in rotary flange must be installed in the direction of flow. This is marked by a cast in arrow (see Fig. 1). If these instructions aren't respected, the water treatment device doesn't work. JUDO BIOSTAT-COMBIMAT... - Page 11 Depending on conditions on site, installation < 12 Inch (300 mm) Wall support Fig. 4: Wall support without bypass valve JUDO BIOSTAT-COMBIMAT...
-
Page 12: Discharging The Flushing Water
, the wastewater hose can be routed because of the bayonet connection! over the water treatment device. Lift up the water treatment devices and swivel it approx. 30° in an anti-clockwise direction. Position it on the built-in rotary JUDO BIOSTAT-COMBIMAT... - Page 13 Flushing water discharge options > 1 Inch > 6 Inch (20 mm) (150 mm) ø 50 mm Fig. 8: Flushing water discharge options JUDO BIOSTAT-COMBIMAT...
-
Page 14: Operation
Plug the power supply into the socket. Electrical circuit 1 5 m³ 2 10 m³ 3 20 m³ 4 40 m³ 5 Ox 1 6 Ox 2 LEDs DIP switch Manual pushbutton Fig. 9: Electrical circuit JUDO BIOSTAT-COMBIMAT... -
Page 15: Description Of Its Function
3 Type Plate 4 Panelling As soon as water flows, the water treatment 5 Cleaning motor is indicated by the flashing of green LED 1 6 Flushing motor (see fig. 12). JUDO BIOSTAT-COMBIMAT... - Page 16 1.5 l/min. Together with a microprocessor-controlled electronics, optimal water treatment is ensured at all times from tiny flows up to the nominal capacity, and also depending on the water quality by adapting the electrical impulses. JUDO BIOSTAT-COMBIMAT...
-
Page 17: Control Lamps, Manual Pushbuttons
(see chapter but serves as a prophylatic measure to “Fault”). protect as far as possible against the danger Hand manual pushbutton of an increase of the germs. Triggers Cleaning - Flushing. JUDO BIOSTAT-COMBIMAT... -
Page 18: Cleaning - Flushing
– Refit the type plate in the blanks, of the panelling, situated above and below. – Push the panelling completely together. Plug the power supply into the socket! Replacing the batteries When a change of batteries is necessary (LED 4 flashes) the following procedure is adopted: JUDO BIOSTAT-COMBIMAT... -
Page 19: Modifications / Changes / Spare Parts
– Return run-down batteries to a distri- butor or to a properly- authorised local disposal return point. Only use 9 V alkaline type block batteries - see battery descrip- tion. JUDO BIOSTAT-COMBIMAT... -
Page 20: Stoppages
In addition, people near the water treat- ment device can be injured by breaking off water treatment device parts. – When restarting the water treatment device, follow the instructions for a new water treatment device. JUDO BIOSTAT-COMBIMAT... -
Page 21: Fault
Remove the ball-valve actuator with a sudden pull. Close the ball-valve with the included hand lever. LED 4 flashes red. Battery is Replace by a new battery (type alkaline). Return empty. run-down batteries to the collection points. JUDO BIOSTAT-COMBIMAT... -
Page 22: Maintenance
(spirits). by the specialist trade or the factory’s These substances can chemically attack the customer service department. plastic parts, which can lead to brittleness or even fractures. Such cleaners must therefore not be used. JUDO BIOSTAT-COMBIMAT... -
Page 23: Data Sheet
Data Sheet Data Sheet Technical specifications – Maximum ambient temperature and Type water temperature: 86 °F (30 °C). JUDO BIOSTAT-COMBIMAT – The water to be treated must possess Water Treatment Device quality of drinking water! Abbreviated name: BST-CA – Threaded... -
Page 24: Mounting Dimensions
A metering pump JUDO JULIA has to be mounted ion the water pipe after the water Fig. 12: Mounting Dimensions treatment device, in order to enrich propor- tionally the water with a mineral solution... -
Page 25: Spare Parts Biostat-Combimat
Spare Parts BIOSTAT-COMBIMAT Spare Parts BIOSTAT-COMBIMAT JUDO BIOSTAT-COMBIMAT... - Page 26 2210449 Basic unit complete 2210450 Hose clamp 1633344 Hose to drain 2633342 Covers 1140103 Spare parts set for flushing motor 2210445 Engine cowling 1140101 Electric circuit Type 15 2210325 Electric circuit Type 25 2210326 Guard Ring small 1120624 JUDO BIOSTAT-COMBIMAT...
- Page 27 (Recommended average replacement interval for wearing piece Order No. part [*]) Battery cable 2210286 E-block-battery 9V 1500261 Front foil 1701393 Guard Ring large 1120625 Brush drive complete 2210348 Replacement interval: ** = 2 years, *** = 3 years, **** = 4 years JUDO BIOSTAT-COMBIMAT...
-
Page 28: 11. Customer Service
Customer Service 11. Customer Service JUDO Water Treatment Inc. 240 Lesmill Road Toronto, ON M3B 2T5 phone: (866) 451-5836 (416) 451-1556 fax: (866) 761-3335 (416) 391-4275 e-mail: info@judo-online.com www.judo-online.com Installed by: All illustrations, dimensions and information for the different models are those valid on the date of prin- ting.
