- Page 1 ATT2 module Installation Guide for PQube® 3 ATT2 Installation Guide (Rev 1.0) Power Standards Lab. 980 Atlantic Ave, Alameda CA 94501, USA Tel ++1-510-522-4400 Fax ++1-510-522-4455 www.PowerStandards.com...
-
Page 2: Table Of Contents
Disconnect mains prior to servicing Install PM2 Power Supply module Apply 24VDC from PM2 module to to ATT2 Connect the ATT2 to the Analog inputs of your PQube® 3 Connect the cable to the 6-pin header on the ATT2 module Install the hall-effect sensor... -
Page 3: What Is The Att2 Module
PQube® 3 add-on module for high voltage DC monitoring The ATT2 module is an optional add-on to your PQube® 3. This module allows you to measure and record one DC voltage, one DC current, and DC power for your high voltage DC application. -
Page 4: Hardware Requirements
➢ one PM2 power manager module ➢ one ATT2 module ➢ a set of cables (connection of the ATT2 to power module, and connection to the current sensor, and connection to the DC voltage leads) 6-pin header to 4-pin/5-pin header cable... -
Page 5: How To Install Your Att2 Module
Attach PM2 to the right side of your PQube® 3, ensuring that the connector fits snugly. Apply 24VDC from PM2 module to to ATT2 Locate the cable with the 6-pin header. On the end opposite of the header, locate the and black wires with ferrule tips. -
Page 6: Connect The Att2 To The Analog Inputs Of Your Pqube® 3
Connect the ATT2 to the Analog inputs of your PQube® 3 On the same cable, connect the orange wire to A1, white wire to A2, and green/yellow wire to GROUND. The example shows a connection to PQube3 terminals AN1 -GND -AN2, but AN3-GND-AN4 can also be used the same way. -
Page 7: Install The Hall-Effect Sensor
Direction of current Connect the ATT2 to the hall-effect sensor Connect the 5-pin cable to its corresponding header on the ATT2 module. Connect the other end of the cable to the white 4-pin header on the hall-effect sensor. -
Page 8: Connect Instrument Power To The Pm2 Power Supply Module
Connect instrument power to the PM2 Power Supply module Connect the 100-240 VAC power source to the AC 100-240 VAC source IN terminals on the PM2 module Page 8 of 10 ATT 2 Module Installation guide (Rev 1.0) -
Page 9: Configuring Your Pqube® 3 For Use With The Att2 Module
ATT2 module Use the PQube3 Configuration editor to declare your ATT2 module Note1: the example below shows how to configure an ATT2 connected to AN1-AN2 analog channels. It is possible to do the same configuration with AN3-AN4 channels. - Page 10 Turn recording of the DC voltage and current ON Optionally, turn recording DC power ON Congratulations! Your PQube® 3 is now configured to measure high voltage DC voltage and current with the ATT2 module. Page 10 of 10 ATT 2 Module Installation guide (Rev 1.0)
