Page 2 Safety Guidelines WARNING! Read and understand all sections in this guide before installing or operating this product. WARNING! Connect this product to an AC power source whose voltage is within the range specified on the product’s nameplate. Operating this product outside the nameplate voltage range may result in electric shock, fire, personal injury and death.
Page 3 Safety Instructions 1. Installation of this product should only be performed by a person who has knowledge and experience with electric power. 2. Make sure the line cord is disconnected from power before physically mounting or moving the location of this product. 3.
Page 4 Raritan, Inc. © Copyright 2010 Raritan, Inc. All third-party software and hardware mentioned in this document are registered trademarks or trademarks of and are the property of their respective holders.
Page 5: Table Of Contents
Contents Safety Guidelines Safety Instructions Applicable Models Chapter 1 Introduction Product Models ..........................1 Product Features ........................... 1 Package Contents.......................... 2 Zero U Products........................2 1U Products ......................... 3 2U Products ......................... 3 Chapter 2 Rack-Mounting the PDU Rackmount Safety Guidelines ....................... 4 Mounting Zero U Models Using Two Rear Buttons ...............5 Mounting Zero U Models Using L-Brackets and Buttons...............
Page 6 Contents Connecting Environmental Sensors (Optional) ................15 Chapter 4 Using the PDU Panel Components ........................17 Power Cord........................17 Outlets ..........................17 Connection Ports .......................18 LED Display ........................20 Reset Button ........................23 Circuit Breakers ........................... 23 Resetting the Button-Type Circuit Breaker................24 Resetting the Handle-Type Circuit Breaker...............24 Beeper ............................
Page 7 Contents Access Security Control....................... 59 Forcing HTTPS Encryption....................59 Configuring the Firewall.....................60 Setting Up an SSL Certificate ...................... 64 Certificate Signing Request ....................64 Creating a Self-Signed Certificate ..................66 Installing Existing Key and Certificate Files...............68 Downloading Key and Certificate Files................68 Setting Up LDAP Authentication....................69 Gathering the LDAP Information ..................69 Adding the LDAP Server Settings ..................70 Sorting the LDAP Access Order ..................72...
Page 8 Contents Viewing the Communication Log ....................99 Firmware Upgrade ........................100 Updating the Firmware ....................100 Full Disaster Recovery ....................102 Accessing the Help ........................102 Retrieving Software Packages Information ..............102 Browsing through the Online Help...................102 Chapter 6 Using SNMP Enabling SNMP..........................104 Configuring Users for Encrypted SNMP v3 ................105 Configuring SNMP Traps......................106 SNMP Gets and Sets.........................107 The Dominion PX MIB .....................107...
Page 9 Contents Sensor Configuration Commands ...................137 Multi-Command Syntax ....................158 Querying Available Parameters for a Command.............159 Quitting the Configuration Mode..................160 Resetting Dominion PX......................160 Restarting the PDU......................160 Resetting to Factory Defaults ..................161 Network Troubleshooting......................161 Entering the Diagnostic Mode ..................161 Diagnostic Commands ....................161 Quitting the Diagnostic Mode ..................164 Retrieving Previous Commands ....................164 Automatically Completing a Command..................164 Logging out of CLI........................165...
Page 10 Applicable Models This user guide is applicable to the PX-1000 series models only, whose model name follows the PX2-1nnn format, such as PX2-1724, PX2-1493, PX2-1180 and so on.
Page 11: Chapter 1 Introduction
Chapter 1 Dominion PX is an intelligent power distribution unit (PDU). The intended use of the Raritan Dominion PX is distribution of power to information technology equipment such as computers and communication equipment where such equipment is typically mounted in an equipment rack located in an information technology equipment room.
Page 12: Package Contents
Zero U Products • Dominion PX device • Screws, brackets and/or buttons for Zero U • A null-modem cable with DB9 connectors on both ends (Raritan number: 254-01-0006-00) (optional) • Cable retention clips for outlets or the inlet (for PX-1000 series only)
Page 13: 1U Products
1U bracket pack and screws • A null-modem cable with DB9 connectors on both ends (Raritan number: 254-01-0006-00) (optional) • Cable retention clips for outlets or the inlet (for PX-1000 series only) 2U Products • Dominion PX device • 2U bracket pack and screws •...
Page 14: Chapter 2 Rack-Mounting The Pdu
Rack-Mounting the PDU Chapter 2 This chapter describes how to rackmount a Zero U Dominion PX device. To mount a PX-1000 series PDU, you can use either two buttons or L-brackets that Raritan provided. In This Chapter Rackmount Safety Guidelines ..............4 Mounting Zero U Models Using Two Rear Buttons........5...
Page 15: Mounting Zero U Models Using Two Rear Buttons
Chapter 2: Rack-Mounting the PDU Mounting Zero U Models Using Two Rear Buttons This section describes how to mount a PX-1000 series PDU using two buttons only. To mount Zero U models using two buttons: 1. Turn to the rear of the PDU.
Page 16: Mounting Zero U Models Using L-Brackets And Buttons
Dominion PX device in place and completes the installation. Mounting Zero U Models Using L-Brackets and Buttons This section describes how to mount a PX-1000 series PDU using L-brackets and two buttons. To mount Zero U models using L-brackets and two buttons: 1.
Page 17 Chapter 2: Rack-Mounting the PDU 2. Screw the L-bracket to the PDU and ensure the bracket is fastened securely. 3. Repeat Steps 1 to 2 to screw another L-bracket to the bottom of the PDU. 4. After both L-brackets are installed on the PDU, you can choose either of the following ways to mount the PDU in the rack.
Page 18: Chapter 3 Installation And Configuration
Preparing the Installation Site 1. Make sure the installation area is clean and free of extreme temperatures and humidity. Note: If necessary, contact Raritan Technical Support for the maximum operating temperature for your model. See Maximum Ambient Operating Temperature (on page 166).
Page 19: Filling Out The Equipment Setup Worksheet
You must connect the Dominion PX device to a computer to configure it, using a serial connection between Dominion PX and the computer. The computer must have a communications program such as HyperTerminal or PuTTY. In addition, you need a null-modem cable with DB9 connectors on both ends (Raritan part number: 254-01-0006-00).
Page 20: Installing Cable Retention Clips (Optional)
Chapter 3: Installation and Configuration Installing Cable Retention Clips (Optional) If your Dominion PX device is designed to use a cable retention clip, install the clip before connecting a power cord. A cable retention clip prevents the connected power cord from coming loose or falling off. To install and use a cable retention clip: 1.
Page 21: Connecting The Pdu To A Computer
Chapter 3: Installation and Configuration 2. Connect each Dominion PX device to an appropriately rated branch circuit. See the label or nameplate affixed to your Dominion PX device for appropriate input ratings or range. 3. When a Dominion PX device powers up, it proceeds with the power-on self test and software loading for a few moments.
Page 22: Initial Network Configuration
At the Username prompt, type admin and press Enter. b. At the Password prompt, type raritan and press Enter. 5. You are prompted to change the password if this is the first time you log in to the Dominion PX device. Follow the onscreen instructions to type your new password.
Page 23 Chapter 3: Installation and Configuration 7. Type config and press Enter. The config:# prompt appears, indicating that you have entered the configuration mode. 8. To configure network settings, type appropriate commands, and press Enter. All commands are case sensitive so make sure you capitalize them correctly.
Page 24 Chapter 3: Installation and Configuration To set Use this command Primary DNS network primaryDNSServer <ip server address> where <ip address> is the IP address of the primary DNS server. Secondary network secondaryDNSServer DNS server <ip address> (optional) where <ip address> is the IP address of the secondary DNS server.
Page 25: Connecting Environmental Sensors (Optional)
To connect environmental sensors via the sensor hubs: 1. Connect a sensor hub to the Dominion PX device. a. Plug one end of the Raritan-provided phone cable (4-wire, 6-pin) into the IN port (Port 1) of the hub. b. Plug the other end into the SENSOR port on the Dominion PX device.
Page 26 Chapter 3: Installation and Configuration Dominion PX device Raritan-provided phone cable Sensor hub Environmental sensors...
Page 27: Chapter 4 Using The Pdu
• Reset button Power Cord Most of Raritan PDUs come with an installed power cord, which is ready to be plugged into an appropriate receptacle for receiving electricity. Such devices cannot be rewired by the user. Connect each Dominion PX device to an appropriately rated branch circuit.
Page 28: Connection Ports
Port Used for... USB-B Establishing a USB connection between a computer and the Dominion PX device. This port is reserved for future release. USB-A Connecting a USB device. FEATURE Connection to some Raritan access products (such as Dominion KX II)
Page 29 This is a standard DTE RS-232 port. You can use a null-modem cable with two DB9 connectors on both ends to connect Dominion PX to the computer. SENSOR Connection to Raritan's environmental sensors. For Zero U products, a sensor hub is required if you want to connect more than one environmental sensor.
Page 30: Led Display
Chapter 4: Using the PDU LED Display The LED display is located on the side where outlets are available. The following picture shows the LED display. The diagram shows the LED display on Zero U models. The diagram shows the LED display on 1U models. The LED display consists of: •...
Page 31 Chapter 4: Using the PDU • The text “FuP,” which indicates that the firmware upgrade is being performed • The text "CbE," which indicates the selected circuit breaker has tripped LEDs for Measurement Units The measurement units vary according to the readings that appear in the three-digit row.
Page 32 Chapter 4: Using the PDU • AP: This indicates the inlet's active power on a single-inlet PDU. During the frimware upgarde, some Dominion PX models may show bx in the two-digit row to indicate the relay or meter board numbered x is being updated.
Page 33: Reset Button
Chapter 4: Using the PDU Note: The LED display returns to the Automatic Mode after 10 seconds elapse since the last time any button was pressed. Note: A few Dominion PX models may show some current being drawn or power consumption while no loads are physically attached to the PDU. For details, see Non-Zero Readings While No Loads Attached (on page...
Page 34: Resetting The Button-Type Circuit Breaker
Chapter 4: Using the PDU Resetting the Button-Type Circuit Breaker Your button-type circuit breakers may look slightly different from the images shown in this section, but the reset procedure remains the same. To reset the button-type breakers: 1. Locate the breaker whose ON button is up, indicating the breaker has tripped.
Page 35: Beeper
Chapter 4: Using the PDU 3. Examine your Dominion PX device and the connected equipment to remove or resolve the cause that results in the overload or short circuit. This step is required, or you cannot proceed with the next step. 4.
Page 36: Chapter 5 Using The Web Interface
To log in to the web interface, you must enter a user name and password. The first time you log in to Dominion PX, use the default user name (admin) and password (raritan). You are then prompted to change the password for security purposes.
Page 37: Login
Chapter 5: Using the Web Interface Login The web interface allows a maximum of 16 users to log in simultaneously. You must enable Java script in the web browser for proper operation. To log in to the web interface: 1. Open a browser, such as Microsoft Internet Explorer or Mozilla Firefox, and type this URL: http(s)://<ip address>...
Page 38: Changing Your Password
Chapter 5: Using the Web Interface Note: Depending on your model, elements shown on the Dominion PX page may appear slightly different from this image. Changing Your Password Normal users can change their own passwords if they have the Change Password permission.
Page 39: Logout
Chapter 5: Using the Web Interface 4. Click Ok to save the changes. Tip: If you have the Administrator Privileges, you can change other users' passwords. See Modifying a User Profile (on page 56). Logout After finishing your tasks with Dominion PX, you should log out to prevent others from accessing the web interface.
Page 40: Introduction To The Web Interface
Chapter 5: Using the Web Interface Introduction to the Web Interface The web interface provides two panes, a menu bar, a status bar, and a logout button throughout every page. Number Web interface element Menus Dominion PX Explorer pane Setup button* Status bar Logout button Data pane...
Page 41: Menus
Chapter 5: Using the Web Interface Menus There is a menu bar across the top of the page. You can click any menu to select the desired menu item from the drop-down list. Four menus are available for managing different tasks or showing information.
Page 42 Chapter 5: Using the Web Interface Expanding the Tree The icons representing all components implemented on or connected to the Dominion PX device are hidden by default. You may expand the tree to show all component icons. To expand the tree: 1.
Page 43: Setup Button
Chapter 5: Using the Web Interface The arrow then turns into a white arrow , and all items below the PDU folder disappear. To hide some tree items: 1. Click the black, gradient arrow prior to the component group folder that you want to collapse, or double-click the folder.
Page 44: Logout Button
Chapter 5: Using the Web Interface • Login name: It is the user name you used to log in to the web interface. • System date and time: Date, year, and time are displayed to the right of the bar. If hovering the mouse pointer on the system date and time, information of the time zone (enclosed in parentheses) and day is also displayed.
Page 45: More Information
Chapter 5: Using the Web Interface The following diagram shows a multi-tab example. 4. When multiple pages are opened, you can take these actions: To return to any previous data page, click the corresponding tab. When there are too many tabs to be all shown, two arrows appear at the left and right borders of the pane.
Page 46 Chapter 5: Using the Web Interface Changing the View of a List Some dialogs or data pages contain a list or table, such as the Manage Users dialog shown below. You may change displayed columns or sorting order of the list for better viewing the data. Note the column or sorting changes are not saved when quitting the dialog or data page.
Page 47 Chapter 5: Using the Web Interface 2. When the mouse pointer turns to a two-way arrow, drag the border horizontally to widen or shrink the column. Changing the Sorting By default, a list or table is sorted against the first column in the ascending order.
Page 48 Chapter 5: Using the Web Interface Browser-Defined Shortcut Menu A shortcut menu, which is built in the web browser, may appear when right-clicking anywhere in the Dominion PX web interface. The shortcut menu functions are defined by the browser. For example, the Back command on the Internet Explorer (IE) shortcut menu works the ®...
Page 49 Chapter 5: Using the Web Interface The Yellow- or Red-Highlighted Reading When a specific reading crosses any upper or lower threshold, the background color of the whole row turns to yellow or red for alerting users. If any circuit breaker trips, the circuit breaker's row is also highlighted in red.
Page 50: Viewing The Dashboard
Chapter 5: Using the Web Interface Viewing the Dashboard When you log in to the web interface, the Dashboard page is displayed by default. This page gives you an overview of the PDU status. The page is divided into various sections according to the component type, such as inlet and circuit breakers.
Page 51: Naming The Pdu
Note: For PX-1000 series, an outlet's operating voltage is derived from the inlet's rated voltage. The result of this calculation is rounded off mathematically to the nearest integer in volt. For example, if the calculation for the minimum voltage is 380/sqrt(3)=219.39 , the web...
Page 52: Modifying The Network Configuration
Chapter 5: Using the Web Interface Modifying the Network Configuration The network settings you can change via the web interface include IPv4 and wired settings. Modifying the Network Settings Dominion PX was configured for network connectivity during the installation and configuration process. See Installation and (on page 8).
Page 53 Chapter 5: Using the Web Interface Option Description Secondary DNS server (optional) DNS Suffix (optional) 4. Click Ok to save the changes. Role of a DNS Server As Internet communications are carried out on the basis of IP addresses, appropriate DNS server settings are required for mapping domain names (host names) to corresponding IP addresses, or Dominion PX may fail to connect to the given host.
Page 54: Modifying The Network Service Settings
Chapter 5: Using the Web Interface Auto: Dominion PX selects the optimum transmission mode through auto-negotiation. Full: Data is transmitted in both directions simultaneously. Half: Data is transmitted in one direction (to or from the Dominion PX device) at a time. 6.
Page 55 Chapter 5: Using the Web Interface Changing the SSH Settings You can enable or disable the SSH access to the command line interface, or change the default TCP port for the SSH service. To change the SSH service settings: 1. Choose Device Settings > Network Services > SSH. The SSH Settings dialog appears.
Page 56 Chapter 5: Using the Web Interface Configuring the SNMP Settings You can enable or disable SNMP communication between an SNMP manager and the Dominion PX device. Enabling SNMP communication allows Dominion PX to send SNMP trap events to the manager, as well as allows the manager to retrieve and control the power status of each outlet.
Page 57: Setting The Date And Time
Chapter 5: Using the Web Interface Important: You must download the SNMP MIB for your Dominion PX Downloading SNMP MIB to use with your SNMP manager. See page 107). Setting the Date and Time You can set the internal clock on the Dominion PX device manually, or link to a Network Time Protocol (NTP) server and let it set the date and time for Dominion PX.
Page 58 Chapter 5: Using the Web Interface How to Use the Calendar The calendar icon next to the Date field is a convenient tool to quickly change the year, month and date. To select a date using the calendar: 1. To change the year shown in the calendar: a.
Page 59: Setting Data Retrieval
Chapter 5: Using the Web Interface Click to show a list of years and months. Select the desired month from the list to the left and click OK. 3. To select a date, do either of the following: Click Today if you want to select today. Note: On the calendar, the date for today is marked with a red frame.
Page 60 After data retrieval is enabled, an external manager or application (such as Raritan's Power IQ) can access the stored data using SNMP. Download the Dominion PX MIB file to assist you in configuring third-party managers to retrieve data.
Page 61: Configuring The Smtp Settings
Chapter 5: Using the Web Interface - Environmental sensors • For each sensor, the following data is available: - Whether data is available for this sensor during this measurement period Note: If it is possible to retrieve at least one sensor reading during the measurement period, then logxxxxxxSensorDataAvailable = TRUE;...
Page 62: Rebooting The Dominion Px Device
Chapter 5: Using the Web Interface a. Select the Server Requires Authentication checkbox. b. Type a user name in the User Name field. c. Type a password in the Password field. 8. Now that you have set the SMTP settings, you can test it to ensure it work properly.
Page 63: User Management
Chapter 5: Using the Web Interface User Management Dominion PX is shipped with one built-in user profile: admin, which is used for initial login and configuration. This profile has full system and outlet permissions, and should be reserved for the system administrator. It cannot be deleted and its permissions are not user-configurable.
Page 64 Chapter 5: Using the Web Interface Field Type this... The email can be up to 32 characters long. It is case sensitive. 4. Select the Enabled checkbox. If not, the user CANNOT log in to the Dominion PX device. 5. Select the "Force password change on next login" checkbox if you prefer a password change by the user when the user logs in for the first time after the password change function is applied.
Page 65 Chapter 5: Using the Web Interface Field Description Phrase Use Authentication This checkbox is configurable only if AuthPriv is Pass Phrase as selected. Privacy Pass When the checkbox is selected, the privacy pass Phrase phrase is identical to the authentication pass phrase.
Page 66: Modifying A User Profile
Chapter 5: Using the Web Interface Modifying a User Profile You can change any user profile's information except for the user name. To modify a user profile: 1. Choose User Management > Users. The Manage Users dialog appears. 2. Select the user by clicking on it. 3.
Page 67: Setting Up Roles
Chapter 5: Using the Web Interface Setting Up Roles A role defines the operations and functions a user is permitted to perform or access. Every user must be assigned at least a role. Dominion PX is shipped with two built-in roles: Admin and Operator. •...
Page 68: Modifying A Role
Chapter 5: Using the Web Interface 6. Click Ok to save the changes. Now you can assign the new role to any users. See Creating a User (on page 53) or (on page 56). Profile Modifying a User Profile Modifying a Role You can change an existing role's settings except for the name.
Page 69: Deleting A Role
Chapter 5: Using the Web Interface Note: If the permission you selected does not contain any arguments, the Edit button is disabled. c. Select the argument you want. To make multiple selections, press Ctrl+click or Shift+click to highlight multiple ones. d.
Page 70: Configuring The Firewall
Chapter 5: Using the Web Interface 3. Choose Device Settings > Security to verify the Force HTTPS for Web Access checkbox is selected as shown in the diagram. If the checkbox is not selected, repeat these steps. After enabling the HTTPS protocol, all access attempts using HTTP are redirected to HTTPS automatically.
Page 71 Chapter 5: Using the Web Interface Changing the Default Policy After enabling the firewall, the default policy is to accept traffic from all IP addresses. This means only IP addresses dropped by a specific rule will NOT be permitted to access Dominion PX. You can change the default policy to DROP, in which case traffic from all IP addresses is dropped except the IP addresses accepted by a specific rule.
Page 72 Chapter 5: Using the Web Interface 2. Ensure the Enable IP Access Control checkbox is selected. 3. Create specific rules. See the table for different operations. Action Procedure Add a rule to the end of Click Append. The "Append new rule" dialog appears. the rules list Type an IP address and subnet mask in the IP/Mask field.
Page 73 Chapter 5: Using the Web Interface 4. When finished, the rules appear in the Configure IP Access Control Settings dialog. 5. Click Ok to save the changes. The rules are applied. Sorting Firewall Rules The rule order determines which one of the rules matching the same IP address is performed so you should change the order only when necessary.
Page 74: Setting Up An Ssl Certificate
Chapter 5: Using the Web Interface Deleting Firewall Rules When any firewall rules become obsolete or unnecessary, you should remove them from the rules list. To delete a firewall rule: 1. Choose Device Settings > Security > IP Access Control. The Configure IP Access Control Settings dialog appears.
Page 75 Chapter 5: Using the Web Interface Creating a Certificate Signing Request Follow this procedure to create the CSR for your Dominion PX device. To create a CSR: 1. Choose Device Setting > Security > SSL Certificate. The Manage SSL Certificate dialog appears. 2.
Page 76: Creating A Self-Signed Certificate
Chapter 5: Using the Web Interface 4. Click Create New SSL Key to create both the CSR and private key. This may take several minutes to complete. 5. To download the newly-created CSR to your computer, click Download Certificate Signing Request. a.
Page 77 Chapter 5: Using the Web Interface 3. Provide the information requested. Field Information Country (ISO code) The country where your company is located. Use the standard ISO country code. For a list of ISO codes, visit the ISO website (http://www.iso.org/iso/country_codes/iso_3166_code_lists.htm). State or Province The full name of the state or province where your company is located.
Page 78: Installing Existing Key And Certificate Files
Chapter 5: Using the Web Interface Installing Existing Key and Certificate Files If the SSL certificate and private key file are already available, you can install them directly without going through the process of creating a CSR or a self-signed certificate. To install the existing key and certificate files: 1.
Page 79: Setting Up Ldap Authentication
Chapter 5: Using the Web Interface Setting Up LDAP Authentication For security purposes, users attempting to log in to Dominion PX must be authenticated. Dominion PX supports the access using one of the following authentication mechanisms: • Local database of user profiles on the Dominion PX device •...
Page 80: Adding The Ldap Server Settings
Chapter 5: Using the Web Interface If using a Microsoft Active Directory server, consult your AD administrator for the name of the Active Directory Domain. • The Base DN of the server (used for searching for users) • The login name attribute (or AuthorizationString) •...
Page 81 LDAP/LDAPS (up to 31 characters), and where in the database to begin searching for the specified Base DN. An example Base Search value might be: cn=Users,dc=raritan,dc=com. Consult your authentication server administrator for the appropriate values to enter into these fields.
Page 82: Sorting The Ldap Access Order
Chapter 5: Using the Web Interface Note: If the Dominion PX clock and the LDAP server clock are out of sync, the certificates are considered expired and users are unable to authenticate using LDAP. To ensure proper synchronization, administrators should configure Dominion PX and the LDAP server to use the same NTP server.
Page 83: Editing The Ldap Server Settings
Chapter 5: Using the Web Interface Editing the LDAP Server Settings If the configuration on any LDAP/LDAPS server has been changed, such as the port number, bind DN and password, you must modify the LDAP/LDAPS settings on the Dominion PX device accordingly, or the authentication fails.
Page 84: Enabling Ldap And Local Authentication Services
Chapter 5: Using the Web Interface Enabling LDAP and Local Authentication Services To make authentication function properly all the time -- even when external authentication is not available, you can enable both the local and remote authentication services. When both authentication services are enabled, Dominion PX follows these rules for authentication: •...
Page 85: Checking Associated Circuit Breakers
Chapter 5: Using the Web Interface 5. Type a name in the Outlet Name field. 6. Click Ok to save the changes. Checking Associated Circuit Breakers To find out each outlet is protected by which circuit breaker, you can check the Outlets page.
Page 86: Naming Circuit Breakers
Chapter 5: Using the Web Interface 2. Click Inlet I1 in the Dominion PX Explorer pane, and the Inlet I1 page opens in the right pane. 3. Click Setup. The Inlet Setup dialog appears. 4. Type a new name in the Name field. 5.
Page 87: Monitoring Circuit Breakers
Chapter 5: Using the Web Interface Note: If a sensor reading row is colored, it means the sensor reading already crosses one of the thresholds, or the circuit breaker has tripped. The Yellow- or Red-Highlighted Reading (on page 39). There are two ways to access the inlet information. To get the overview of the inlet status: 1.
Page 88 Chapter 5: Using the Web Interface Note: If a sensor reading row is colored, it means the sensor reading already crosses one of the thresholds, or the circuit breaker has tripped. The Yellow- or Red-Highlighted Reading (on page 39). You can view the summary of all circuit breakers at a time or the status of individual circuit breakers.
Page 89: Setting Power Thresholds
Chapter 5: Using the Web Interface Setting Power Thresholds Setting and enabling the thresholds causes Dominion PX to generate alert notifications when it detects that any component's power state crosses the thresholds. Usually there are four thresholds for each sensor: Lower Critical, Lower Warning, Upper Warning and Upper Critical.
Page 90: Setting Circuit Breaker Thresholds
Chapter 5: Using the Web Interface 8. Click Ok in the threshold setup dialog to retain the changes. 9. To set the thresholds for other sensors, repeat Steps 4 to 8. 10. Click Ok to save the changes. Important: The final step is required or the threshold changes are not saved.
Page 91 Chapter 5: Using the Web Interface Upper Warning Threshold Hysteresis Upper Warning Reset Lower Warning Reset Hysteresis Lower Warning Threshold Lower Critical Reset Hysteresis Lower Critical Threshold The hysteresis values define a reset threshold. For upper thresholds, the measurement must fall past this reset threshold before a deassertion event is generated.
Page 92: Configuring Event Rules
Chapter 5: Using the Web Interface Example: When to Disable Hysteresis This is an example of when you want to disable hysteresis for the inlet -- that is, set the hysteresis to zero. The upper warning threshold for current in the inlet is set to 15A. In normal usage, the inlet draws 14.6A of current.
Page 93: Creating An Event Rule
Switch outlet: This option turns on, off or power cycles a specific outlet (not applicable to PX-1000 series). 6. Complete further settings for the selected action if necesssary. Send SMTP message: This option requires you to specify the email address(es) of the recipient(s), and determine which SMTP server settings to apply.
Page 94 Chapter 5: Using the Web Interface In the "Recipients email addresses" field, specify the email address(es). Use a comma to separate multiple email addresses. To use the SMTP server specified in the SMTP Server Settings dialog, select the Use Default SMTP Server checkbox.
Page 95 Chapter 5: Using the Web Interface Creating Rules When necessary actions are available, you can create event rules to determine what actions are taken to respond to specific events. By default, Dominion PX provides two built-in event rules -- System Event Log Rule and System SNMP Trap Rule.
Page 96: Sample Event Rules
Chapter 5: Using the Web Interface 10. Click Save to save the new event rule. 11. Repeat Steps 2 to 10 to create additional event rules. 12. Click Close to quit the dialog. Sample Event Rules Sample PDU-Level Event Rule In this example, we want Dominion PX to record the firmware upgrade failure in the internal log when it happens.
Page 97 Chapter 5: Using the Web Interface 4. Select "Any sub-event" because we want to specify all events related to all types of outlet sensors and thresholds, such as current, voltage, upper critical threshold, upper warning threshold, lower critical threshold, lower warning threshold, and so on. 5.
Page 98: Modifying An Event Rule
Chapter 5: Using the Web Interface Modifying an Event Rule You can change an event rule's event, action, trigger condition and other settings, if any. Exception: Events and actions selected in the built-in event rules are not chageable, including System Event Log Rule and System SNMP Trap Rule.
Page 99: Deleting An Event Rule Or Action
Chapter 5: Using the Web Interface 3. Select the action that you want to modify from the left list. 4. Make necessary changes to the information to the right. 5. Click Save to save the changes. 6. Click Close to quit the dialog. Deleting an Event Rule or Action If any event rule or action is obsolete, simply remove it.
Page 100: Clearing Event Entries
Chapter 5: Using the Web Interface Each event entry in the local log consists of: Date and time of the event Type of the event A description of the event 2. The dialog shows the last page by default. You can: Switch between different pages by doing one of the following: - Click to go to the first or last page.
Page 101: Identifying Environmental Sensors
Chapter 5: Using the Web Interface 2. Log in to the Dominion PX web interface. The PDU should have detected the connected sensors, and display them in the web interface. 3. Identify each sensor through the sensor's serial number. See (on page 91).
Page 102: Managing Environmental Sensors
Chapter 5: Using the Web Interface Managing Environmental Sensors Dominion PX starts to retrieve an environmental sensor's reading and/or state and records the state transitions after the environmental sensor is managed. The PDU can manage a maximum of 16 environmental sensors. When there are less than 16 managed sensors, Dominion PX automatically brings detected environmental sensors under management.
Page 103: Configuring Environmental Sensors
Chapter 5: Using the Web Interface Configuring Environmental Sensors You may change the default name for easily identifying the managed sensor, and describe its location with X, Y and Z coordinates. To configure environmental sensors: 1. If the PDU folder is not expanded, expand it to show all components and component groups.
Page 104 Chapter 5: Using the Web Interface 2. Click Setup. The Pdu Setup dialog appears. 3. In the "External sensors Z coordinate" field, click the drop-down arrow and select an option from the list. Rack Units: The height of the Z coordinate is measured in standard rack units.
Page 105: Viewing Sensor Data
Chapter 5: Using the Web Interface Viewing Sensor Data Readings of the environmental sensors will display in the web interface after these sensors are properly connected and managed. The Dashboard page shows the information for managed environmental sensors only, while the External Sensors page shows the information for both of managed and unmanaged ones.
Page 106: Sensor Measurement Accuracy
Chapter 5: Using the Web Interface Sensor Measurement Accuracy Raritan environmental sensors are with the following factory specifications. Calibration is not required for environmental sensors. • Temperature: +/-2% • Humidity: +/-5% Unmanaging Environmental Sensors When it is unnecessary to monitor a particular environmental factor, you can unmanage or release the corresponding environmental sensor so that the PDU stops retrieving the sensor's reading and/or state.
Page 107: Copying Configurations With Bulk Configuration
Chapter 5: Using the Web Interface Copying Configurations with Bulk Configuration The Bulk Configuration feature lets you save the settings of a configured Dominion PX device to your PC. This file can be used to copy that configuration to other Dominion PX devices of the same model or to restore the settings to previous configuration on the same Dominion PX device.
Page 108: Saving A Dominion Px Configuration
Chapter 5: Using the Web Interface Saving a Dominion PX Configuration A source device is an already configured Dominion PX device that is used to create a configuration file containing the settings that can be shared between Dominion PX devices. These settings include user and role configurations, thresholds, event rules, security settings, and so on.
Page 109: Copying A Dominion Px Configuration
Chapter 5: Using the Web Interface Copying a Dominion PX Configuration A target device is a Dominion PX device that loads another Dominion PX device's configuration file. Copying a Dominion PX configuration to a target device adjusts that Dominion PX device's settings to match those of the source Dominion PX device.
Page 110: Firmware Upgrade
You must be the system administrator or log in to the user profile with the Firmware Update permission to update the PDU's firmware. After downloading the latest firmware file from the Raritan website, you can start performing the upgrade. To update the firmware: 1.
Page 111 PDU's firmware upgrade time. The time indicated in this note is for web-interface-based upgrades. Upgrades through other management systems, such as Raritan's Power IQ, may take additional time beyond the control of the PDU itself. This note does not address the upgrades using other management systems.
Page 112: Full Disaster Recovery
PDU to Raritan. Contact Raritan Technical Support for the recovery utility, which works in Windows XP/Vista/7 and Linux. In addition, an appropriate Dominion PX firmware file is required in the recovery procedure.
Page 113 "Email this page" icon in the toolbar. 9. To email your comments or suggestions regarding the user guide to Raritan, click the "Send feedback" icon 10. To print the currently selected topic, click the "Print this page" icon...
Page 114: Chapter 6 Using Snmp
Using SNMP Chapter 6 This SNMP section helps you set up Dominion PX for use with an SNMP manager. Dominion PX can be configured to send traps to an SNMP manager, as well as receive GET and SET commands in order to retrieve status and configure some basic settings.
Page 115: Configuring Users For Encrypted Snmp V3
Chapter 6: Using SNMP Type the SNMP read-only community string in the Read Community String field. Type the read/write community string in the Write Community String field. 3. Select the SNMP v3 checkbox to enable communication with an SNMP manager using SNMP v3 protocol. Tip: You can permit or disallow a user to access Dominion PX via the SNMP v3 protocol.
Page 116: Configuring Snmp Traps
Chapter 6: Using SNMP Configuring SNMP Traps Dominion PX automatically keeps an internal log of events that occur. See (on page 82). These events can also be used Configuring Event Rules to send SNMP traps to a third party manager. To configure Dominion PX to send SNMP traps: 1.
Page 117: Snmp Gets And Sets
Chapter 6: Using SNMP Note: You should update the MIB used by your SNMP manager when updating to a new Dominion PX release. This ensures your SNMP manager has the correct MIB for the release you are using. See Downloading SNMP MIB (on page 107).
Page 118 Chapter 6: Using SNMP Layout Opening the MIB reveals the custom objects that describe the Dominion PX system at the unit level as well as at the individual-outlet level. As standard, these objects are first presented at the beginning of the file, listed under their parent group.
Page 119: A Note About Enabling Thresholds
Chapter 6: Using SNMP A Note about Enabling Thresholds When enabling previously disabled thresholds via SNMP, make sure to set a correct value for all thresholds that are supposed to be enabled prior to actually enabling them. Otherwise, you may get an error message.
Page 120: Chapter 7 Using The Command Line Interface
Using the Command Line Interface Chapter 7 This section explains how to use the command line interface (CLI) to administer a Dominion PX device. In This Chapter About the Interface ................110 Logging in to CLI ...................110 Help Command..................113 Showing Information................114 Configuring the PDU and Network ............124 Resetting Dominion PX .................160 Network Troubleshooting...............161...
Page 121: With Hyperterminal
Chapter 7: Using the Command Line Interface With HyperTerminal You can use any terminal emulation programs for local access to the command line interface. This section illustrates HyperTerminal, which is part of Windows operating systems prior to Windows Vista. To log in using HyperTerminal: 1.
Page 122: With Ssh Or Telnet
Chapter 7: Using the Command Line Interface With SSH or Telnet You can remotely log in to the command line interface using an SSH or Telnet client, such as PuTTY. Note: PuTTY is a free program you can download from the Internet. See PuTTY's documentation for details on configuration.
Page 123: Different Cli Modes And Prompts
Chapter 7: Using the Command Line Interface Different CLI Modes and Prompts Depending on the login name you use and the mode you enter, the system prompt in the CLI varies. • User Mode: When you log in as a normal user, who does not have full permissions to configure the PDU, the >...
Page 124: Showing Information
Chapter 7: Using the Command Line Interface Showing Information You can use the show commands to view current settings or status of the Dominion PX device or part of it, such as the IP address, networking mode, firmware version, circuit breaker state, inlet ratings, and so on. Many show commands have two formats: one with the parameter "details"...
Page 125: Showing The Networking Mode
Chapter 7: Using the Command Line Interface Showing the Networking Mode This command shows whether the current networking mode is wired or wireless. Currently Dominion PX supports the wired networking mode only. show networkingMode Showing Network Service Settings This command shows the network service settings, including the TCP ports for HTTP and HTTPS services.
Page 126: Showing The Inlet Information
Chapter 7: Using the Command Line Interface Showing the Inlet Information This command syntax shows the inlet information. show inlets <n> To show detailed information, add the parameter "details" to the end of the command. show inlets <n> details Variables: •...
Page 127: Showing The Circuit Breaker Information
Chapter 7: Using the Command Line Interface Showing the Circuit Breaker Information This command syntax shows the circuit breaker information. show ocp <n> To show detailed information, add the parameter "details" to the end of the command. show ocp <n> details Variables: •...
Page 128: Showing The External Sensor Information
Chapter 7: Using the Command Line Interface Showing the External Sensor Information This command syntax shows the environmental sensor's information. show externalsensors <n> To show detailed information, add the parameter "details" to the end of the command. show externalsensors <n> details Variables: •...
Page 129: Showing Inlet Sensors
Chapter 7: Using the Command Line Interface Showing Inlet Sensors This command syntax shows the inlet sensor information. show sensor inlet <n> <sensor type> To show detailed information, add the parameter "details" to the end of the command. show sensor inlet <n> <sensor type> details Variables: •...
Page 130: Showing Inlet Pole Sensors
Chapter 7: Using the Command Line Interface Showing Inlet Pole Sensors This command syntax shows the inlet pole sensor information. show sensor inletpole <n> <p> <sensor type> To show detailed information, add the parameter "details" to the end of the command.
Page 131: Showing Circuit Breaker Sensors
Chapter 7: Using the Command Line Interface Showing Circuit Breaker Sensors This command syntax shows circuit breaker sensor information. show sensor ocp <n> <sensor type> To show detailed information, add the parameter "details" to the end of the command. show sensor ocp <n> <sensor type> details Variables: •...
Page 132: Showing Environmental Sensors
Chapter 7: Using the Command Line Interface Showing Environmental Sensors This command syntax shows sensor information associated with an environmental sensor. show sensor externalsensor <n> To show detailed information, add the parameter "details" to the end of the command. show sensor externalsensor <n> details Variables: •...
Page 133 Chapter 7: Using the Command Line Interface Example 1 - Basic Network Information The diagram shows the output of the show network command. Example 2 - In-Depth Network Information More information is displayed when typing the show network details command. Example 3 - Basic PDU Information The diagram shows the output of the show pdu command.
Page 134: Configuring The Pdu And Network
Chapter 7: Using the Command Line Interface Example 4 - In-Depth PDU Information More information is displayed when typing the show pdu details command. Configuring the PDU and Network To configure the Dominion PX device or network settings through the CLI, you must log in as the administrator.
Page 135: Pdu Configuration Commands
Chapter 7: Using the Command Line Interface PDU Configuration Commands A PDU configuration command begins with pdu. You can use the PDU configuration commands to change the settings that apply to the whole Dominion PX device. The commands are case sensitive so ensure you capitalize them correctly.
Page 136 Chapter 7: Using the Command Line Interface Example The following command enables the data retrieval feature. config:# pdu dataRetrieval enable Setting the Data Retrieval Sample Period This command syntax defines the number of samples (readings) taken for internal sensors per log entry. For environmental sensors, the log entry will use the number of measurements that occur within the period corresponding to the sampling period for internal sensors.
Page 137: Networking Configuration Commands
Chapter 7: Using the Command Line Interface Setting the Z Coordinate Format for Environmental Sensors This command syntax enables or disables the use of rack units for specifying the height (Z coordinate) of environmental sensors. config:# pdu externalSensorsZCoordinateFormat <option> Variables: •...
Page 138 Chapter 7: Using the Command Line Interface Setting the IP Configuration Mode This command syntax selects the IP configuration mode. config:# network ipConfigurationMode <mode> Variables: • <mode> is one of the modes: dhcp or static. Mode Description dhcp The IP configuration mode is set to DHCP. static The IP configuration mode is set to static IP address.
Page 139 Chapter 7: Using the Command Line Interface Example The following command makes the PDU determine the optimal LAN interface speed through auto-negotiation. config:# network LANInterfaceSpeed auto Changing the LAN Duplex Mode This command syntax determines the LAN interface duplex mode. config:# network LANInterfaceDuplexMode <mode>...
Page 140 Chapter 7: Using the Command Line Interface Cannot contain more than 63 characters Cannot contain punctuation marks, spaces, and other symbols Example The following command sets the preferred host name to "my-host." config:# network preferredHostName my-host Setting the IP Address After selecting the static IP configuration mode, you can use this command syntax to assign a permanent IP address to the PDU.
Page 141 Chapter 7: Using the Command Line Interface Setting the Gateway After selecting the static IP configuration mode, you can use this command syntax to specify the gateway. config:# network gateway <ip address> Variables: • <ip address> is the IP address of the gateway. The value ranges from 0.0.0.0 to 255.255.255.255.
Page 142 Chapter 7: Using the Command Line Interface Example The following command determines that the secondary DNS server is 192.168.84.33. config:# network secondaryDNSServer 192.168.84.33 Setting the Network Service Parameters A network service command begins with networkservices. Changing the HTTP Port This command syntax changes the HTTP port. config:# networkservices httpPort <n>...
Page 143: Security Configuration Commands
Chapter 7: Using the Command Line Interface Security Configuration Commands A security configuration command begins with security. The following command determines whether the IP access control feature is enabled. config:# security ipAccessControl <option> Variables: • <option> is one of the options: enable or disable. Option Description enable...
Page 144: Inlet Configuration Commands
Chapter 7: Using the Command Line Interface Example The following command assigns the name "Win XP" to outlet 8. config:# outlet 8 name "Win XP" Inlet Configuration Commands An inlet configuration command begins with inlet. You can configure an inlet by using the inlet configuration command. Changing the Inlet Name This command syntax names an inlet.
Page 145: Environmental Sensor Configuration Commands
Chapter 7: Using the Command Line Interface Changing the Circuit Breaker Name This command syntax names a circuit breaker. config:# ocp <n> name "<name>" Variables: • <n> is the number of the circuit breaker that you want to configure. The value is an integer between 1 and 50. •...
Page 146 Chapter 7: Using the Command Line Interface Example The following command assigns the name "Cabinet humidity" to the environmental sensor with the ID number 4. config:# externalsensor 4 name "Cabinet humidity" Setting the X Coordinate This command syntax specifies the X coordinate of an environmental sensor.
Page 147: Sensor Configuration Commands
Chapter 7: Using the Command Line Interface Example The following command sets the value "The 4th row" to the Y coordinate of the environmental sensor with the ID number 4. config:# externalsensor 4 ylabel "The 4th row" Setting the Z Coordinate This command syntax specifies the Z coordinate of an environmental sensor.
Page 148 Chapter 7: Using the Command Line Interface Commands for Inlet Sensors A sensor configuration command for inlets begins with sensor inlet. Setting the Inlet's Upper Critical Threshold This command syntax configures the Upper Critical threshold of an inlet. config:# sensor inlet <n> <sensor type> upperCritical <option> Variables: •...
Page 149 Chapter 7: Using the Command Line Interface Example The following command enables the Upper Critical threshold for the inlet 1 RMS current. config:# sensor inlet 1 current upperCritical enable Setting the Inlet's Upper Warning Threshold This command syntax configures the Upper Warning threshold of an inlet. config:# sensor inlet <n>...
Page 150 Chapter 7: Using the Command Line Interface Example The following command sets the Upper Warning threshold for the inlet 1 RMS current to 27A. config:# sensor inlet 1 current upperWarning 27 Setting the Inlet's Lower Critical Threshold This command syntax configures the Lower Critical threshold of an inlet. config:# sensor inlet <n>...
Page 151 Chapter 7: Using the Command Line Interface Example The following command disables the Lower Critical threshold for the inlet 1 RMS current. config:# sensor inlet 1 current lowerCritical disable Setting the Inlet's Lower Warning Threshold This command syntax configures the Lower Warning threshold of an inlet. config:# sensor inlet <n>...
Page 152 Chapter 7: Using the Command Line Interface Example The following command sets the Lower Warning threshold for the inlet 1 RMS current to 20A. config:# sensor inlet 1 current lowerWarning 20 Setting the Inlet's Deassertion Hysteresis This command syntax configures the deassertion hysteresis value of an inlet.
Page 153 Chapter 7: Using the Command Line Interface Commands for Inlet Pole Sensors A sensor configuration command for inlet poles begins with sensor inletpole. Setting the Upper Critical Threshold for an Inlet Pole This command syntax configures the Upper Critical threshold of an inlet pole.
Page 154 Chapter 7: Using the Command Line Interface Option Description disable Disables the upper critical threshold for the specified inlet pole sensor. A numeric value Sets a value for the upper critical threshold of the specified inlet pole sensor without enabling or disabling the threshold.
Page 155 Chapter 7: Using the Command Line Interface Sensor type Description activeEnergy Active energy sensor unbalancedCurrent Unbalanced current sensor Note: If the requested sensor type is not supported, the message "Not Available" is displayed. • <option> is one of the options: enable, disable or a numeric value. Option Description enable...
Page 156 Chapter 7: Using the Command Line Interface • <sensor type> is one of the following sensor types: Sensor type Description current Current sensor voltage Voltage sensor activePower Active power sensor apparentPower Apparent power sensor powerFactor Power factor sensor activeEnergy Active energy sensor unbalancedCurrent Unbalanced current sensor Note: If the requested sensor type is not supported, the message "Not...
Page 157 Chapter 7: Using the Command Line Interface config:# sensor inletpole <n> <p> <sensor type> lowerWarning <option> Variables: • <n> is the number of the inlet whose pole sensors you want to configure. • <p> is the label of the inlet pole that you want to configure. Pole Label Current sensor...
Page 158 Chapter 7: Using the Command Line Interface Example The following command sets the Lower Warning threshold for the pole 3 (L3-L1) voltage of the inlet 1 to 190V. config:# sensor inletpole 1 L3 voltage lowerWarning 190 Setting the Inlet Pole's Deassertion Hysteresis This command syntax configures the deassertion hysteresis value of an inlet pole.
Page 159 Chapter 7: Using the Command Line Interface Example The following command sets the deassertion hysteresis for the pole 2 (L2-L3) voltage of the inlet 1 to 0.5A. config:# sensor inletpole 1 L2 current hysteresis 0.5 Commands for Circuit Breaker Sensors A sensor configuration command for circuit breakers begins with sensor ocp.
Page 160 Chapter 7: Using the Command Line Interface Example The following command sets the Upper Critical threshold for the 3rd circuit breaker to 16A. config:# sensor ocp 3 current upperCritical 16 Setting the Upper Warning Threshold for a Circuit Breaker This command syntax configures the Upper Warning threshold of a circuit breaker.
Page 161 Chapter 7: Using the Command Line Interface Setting the Lower Critical Threshold for a Circuit Breaker This command syntax configures the Lower Critical threshold of a circuit breaker. config:# sensor ocp <n> <sensor type> lowerCritical <option> Variables: • <n> is the number of the circuit breaker that you want to configure. •...
Page 162 Chapter 7: Using the Command Line Interface Setting the Lower Warning Threshold for a Circuit Breaker This command syntax configures the Lower Warning threshold of a circuit breaker. config:# sensor ocp <n> <sensor type> lowerWarning <option> Variables: • <n> is the number of the circuit breaker that you want to configure. •...
Page 163 Chapter 7: Using the Command Line Interface Setting the Circuit Breaker's Deassertion Hysteresis This command syntax configures the deassertion hysteresis value of a circuit breaker. config:# sensor ocp <n> <sensor type> hysteresis <value> Variables: • <n> is the number of the circuit breaker that you want to configure. •...
Page 164 Chapter 7: Using the Command Line Interface config:# sensor externalsensor <n> <sensor type> upperCritical <option> Variables: • <n> is the ID number of the environmental sensor that you want to configure. The number is assigned by Dominion PX and shown on the External Sensor page of the web interface.
Page 165 Chapter 7: Using the Command Line Interface config:# sensor externalsensor <n> <sensor type> upperWarning <option> Variables: • <n> is the ID number of the environmental sensor that you want to configure. The number is assigned by Dominion PX and shown on the External Sensor page of the web interface.
Page 166 Chapter 7: Using the Command Line Interface config:# sensor externalsensor <n> <sensor type> lowerCritical <option> Variables: • <n> is the ID number of the environmental sensor that you want to configure. The number is assigned by Dominion PX and shown on the External Sensor page of the web interface.
Page 167 Chapter 7: Using the Command Line Interface config:# sensor externalsensor <n> <sensor type> lowerWarning <option> Variables: • <n> is the ID number of the environmental sensor that you want to configure. The number is assigned by Dominion PX and shown on the External Sensor page of the web interface.
Page 168: Multi-Command Syntax
Chapter 7: Using the Command Line Interface config:# sensor externalsensor <n> <sensor type> hysteresis <value> Variables: • <n> is the ID number of the environmental sensor that you want to configure. The number is assigned by Dominion PX and shown on the External Sensor page of the web interface.
Page 169: Querying Available Parameters For A Command
Chapter 7: Using the Command Line Interface config:# network ipAddress 192.168.84.225 subnetMask 255.255.255.0 gateway 192.168.84.0 Results: • The IP address is set to 192.168.84.225. • The subnet mask is set to 255.255.255.0. • The gateway is set to 192.168.84.0. Example 2 - Combination of Upper Critical and Upper Warning Settings The following multi-command syntax simultaneously configures Upper Critical and Upper Warning thresholds for the RMS current of the 3rd circuit breaker.
Page 170: Quitting The Configuration Mode
Chapter 7: Using the Command Line Interface Quitting the Configuration Mode Both of "apply" and "cancel" commands let you quit the configuration mode. The difference is that "apply" saves all changes you made in the configuration mode while "cancel" aborts all changes. To quit the configuration mode, use either command: config:# apply...
Page 171: Resetting To Factory Defaults
Chapter 7: Using the Command Line Interface Resetting to Factory Defaults This command restores all settings of the PDU to factory defaults. To reset Dominion PX settings, use either command: reset pdu factorydefaults -- OR -- reset pdu factorydefaults /y (on page 181) for more information.
Page 172 Chapter 7: Using the Command Line Interface Example The following command checks the DNS information regarding the host 192.168.84.222. diag> nslookup 192.168.84.222 Showing the Network Connections This command syntax displays network connections and/or status of ports. diag> netstat <option> Variables: •...
Page 173 Chapter 7: Using the Command Line Interface Testing the Network Connectivity This command syntax sends the ICMP ECHO_REQUEST message to a network host for checking its network connectivity. If the output shows the host is responding properly, the network connectivity is good, or the host is not being connected to the network.
Page 174: Quitting The Diagnostic Mode
Chapter 7: Using the Command Line Interface Tracing the Route This command syntax traces the network route between your PDU and a network host. diag> traceroute <host> Variables: • <host> is the name or IP address of the host you want to trace. Example The following command displays the existing network routing for the host 192.168.84.222.
Page 175: Logging Out Of Cli
Chapter 7: Using the Command Line Interface 2. Press Tab or Ctrl+i until the complete command appears. For example, although you typed only one word for the reset command, the rest of the command appears after pressing Tab or Ctrl+i for several times. Logging out of CLI After completing your tasks using the CLI, always log out of the CLI to prevent others from accessing the CLI.
Page 176: Appendix A Specifications
Maximum Ambient Operating Temperature The maximum ambient operating temperature (TMA) for Dominion PX varies from 50 to 60 degrees Celsius, depending on the model and certification standard (CE or UL). If necessary, contact Raritan Technical Support for this information for your model. Measure...
Page 177: Appendix B Equipment Setup Worksheet
Appendix B Equipment Setup Worksheet Dominion PX Series Model ____________ Dominion PX Series Serial Number ____________ OUTLET 1 OUTLET 2 OUTLET 3 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 4 OUTLET 5 OUTLET 6 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER...
Page 178 Appendix B: Equipment Setup Worksheet OUTLET 7 OUTLET 8 OUTLET 9 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 10 OUTLET 11 OUTLET 12 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 13 OUTLET 14 OUTLET 15 MODEL MODEL MODEL...
Page 179 Appendix B: Equipment Setup Worksheet OUTLET 16 OUTLET 17 OUTLET 18 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 19 OUTLET 20 OUTLET 21 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER...
Page 180 Appendix B: Equipment Setup Worksheet OUTLET 22 OUTLET 23 OUTLET 24 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER Types of adapters _________________________________________________________ Types of cables _________________________________________________________ Name of software program _________________________________________________________...
Page 181: Appendix C Mac Addresses Of Zero U Models
Appendix C MAC Addresses of Zero U Models A label is affixed to a Zero U Dominion PX device, showing both of the serial number and MAC address of the PDU. If necessary, you can find the PDU's IP address through the MAC address by using commonly-used network tools.
Page 182: Appendix D Ldap Configuration Illustration
Appendix D LDAP Configuration Illustration This section provides an LDAP example for illustrating the configuration procedure using Microsoft Active Directory (AD). To configure LDAP ® authentication, four main steps are required: a. Determine user accounts and groups intended for Dominion PX b.
Page 183: Step B. Configure User Groups On The Ad Server
Appendix D: LDAP Configuration Illustration Step B. Configure User Groups on the AD Server You must create the groups for Dominion PX on the AD server, and then make appropriate users members of these groups. In this illustration, we assume: •...
Page 184: Step C. Configure Ldap Authentication On The Dominion Px Device
Appendix D: LDAP Configuration Illustration Step C. Configure LDAP Authentication on the Dominion PX Device You must enable and set up LDAP authentication properly on the Dominion PX device to use external authentication. In the illustration, we assume: • The DNS server settings have been configured properly. See (on page 42) and Modifying the Network Settings Role of a DNS...
Page 185 Appendix D: LDAP Configuration Illustration Login Name Attribute - Ensure the field is set to sAMAccountName because the LDAP server is Microsoft Active Directory. User Entry Object Class - Ensure the field is set to user because the LDAP server is Microsoft Active Directory. User Search Subfilter - The field is optional.
Page 186: Step D. Configure User Groups On The Dominion Px Device
Appendix D: LDAP Configuration Illustration Note: If the Dominion PX clock and the LDAP server clock are out of sync, the certificates are considered expired and users are unable to authenticate using LDAP. To ensure proper synchronization, administrators should configure Dominion PX and the LDAP server to use the same NTP server.
Page 187 Appendix D: LDAP Configuration Illustration d. Repeat Steps a to c to add all permissions beginning with "View." 6. Click Ok to save the changes. The PX_User role is created. 7. Keep the Manage Roles dialog opened to create the PX_Admin role. To create the PX_Admin role with full permissions assigned: 1.
Page 188 Appendix D: LDAP Configuration Illustration 3. Type a description for the PX_Admin role in the Description field. In this example, we type "The role includes all privileges" to describe the role. 4. Click the Privileges tab to select the Administrator permission. The Administrator permission allows users to configure or change all Dominion PX settings.
Page 189 Appendix D: LDAP Configuration Illustration 5. Click Ok to save the changes. The PX_Admin role is created. 6. Click Close to quit the dialog.
Page 190: Appendix E Resetting To Factory Defaults
Appendix E Resetting to Factory Defaults For security reasons, the Dominion PX device can be reset to factory defaults only at the local serial console. Important: Exercise caution before resetting Dominion PX to its factory defaults. This erases any existing information and customized settings, such as user profiles and threshold values.
Page 191: Using The Cli Command
Appendix E: Resetting to Factory Defaults The diagram shows the location of the reset button on Zero U models. The diagram shows the location of the reset button on 1U models. Note: HyperTerminal is available on Windows operating systems prior to Windows Vista.
Page 192 Appendix E: Resetting to Factory Defaults...
Page 193: Appendix F Non-Zero Readings While No Loads Attached
Appendix F Non-Zero Readings While No Loads Attached When no loads are physically attached to any outlets or lines, it is likely some Dominion PX models still show non-zero current or active power readings for the inlet in the web interface and/or LED display. This section explains why a PDU shows these readings when there are no loads attached.
Page 194 Index Changing Your Password • 28 Checking Associated Circuit Breakers • 75 Checking the Branch Circuit Rating • 9 1U Products • 3 Circuit Breaker Configuration Commands • 134 Circuit Breakers • 23 Clearing Event Entries • 90 2U Products • 3 Closing a Serial Connection •...
Page 195: Index
Index Describing the Sensor Location • 93, 94 Device Management • 40 Diagnostic Commands • 161 Gathering the LDAP Information • 69 Different CLI Modes and Prompts • 111, 112, Disabling the LDAP Authentication • 73 Help Command • 113 Displaying the PDU Information •...
Page 196 Index Monitoring Circuit Breakers • 77 Resizing the Dialog • 37, 41, 90, 100 Monitoring the Inlet • 76 Restarting the PDU • 160 More Information • 35 Retrievable Data • 50 More Information about AD Configuration • 72 Retrieving Previous Commands • 164 Mounting Zero U Models Using L-Brackets and Retrieving Software Packages Information •...
Page 197 Index Setting the Preferred Host Name • 129 Specifications • 4, 166 Setting the Primary DNS Server • 131 Status Bar • 33 Setting the Secondary DNS Server • 131 Step A. Determine User Accounts and Groups • Setting the Sensor's Deassertion Hysteresis • Step B.
Page 198 For CommandCenter Secure Gateway: Press 6, then Press 2 Phone: +31-10-2844040 Fax: 732-764-8887 Email: tech.europe@raritan.com Email for CommandCenter NOC: tech-ccnoc@raritan.com Email for all other products: tech@raritan.com United Kingdom Monday - Friday 8:30 a.m. to 5 p.m. GMT China Phone +44(0)20-7090-1390...

This manual is also suitable for:

Px2-1180 Px2-1493 Px2-1724

Raritan PX-1000 Series User Manual

Chapter 1 Introduction

Chapter 2 Rack-Mounting the PDU

Chapter 3 Installation and Configuration

Chapter 4 Using the PDU

In this Chapter Logging in to the Web Interface

Chapter 5 Using the Web Interface

In this Chapter Enabling SNMP

Chapter 6 Using SNMP

In this Chapter about the Interface

Chapter 7 Using the Command Line Interface

Appendix A Specifications

Appendix B Equipment Setup Worksheet

Appendix C MAC Addresses of Zero U Models

Appendix D LDAP Configuration Illustration

Appendix E Resetting to Factory Defaults

Appendix F Non-Zero Readings While no Loads Attached

Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Raritan PX-1000 Series

Summary of Contents for Raritan PX-1000 Series

This manual is also suitable for:

Table of Contents
