ISER222 SERIES
RANGE HOODS
Tubular, wrap-around utensil rail serves as both a
stunning accent and a practical addition to this
elegant angular design.

FEATURES

Italian design
Island mount
Finishes: 304 Stainless Steel #4 Brushed, White, Black,
Polished Brass, Brushed Copper
Utensil rail is chrome when ordering stainless steel finish,
brass rail with all other finishes
Size: 70cm x 122cm (27-9/16" x 48")
Telescopic flue accommodates 8' to 9' ceilings
8" round duct connector/backdraft damper
Halogen lighting (4 x 20 watt, Type JC 12V 20W G4 Base
- bulbs included) with two-level lighting provides bright
cooktop illumination and a low nighttime setting
Advanced, multispeed electronic push-button controls
with individual speed indicators
Quiet variable speed centrifugal blower with high efficiency
motor produces 1000 CFM of exhaust
Delay timer control automatically shuts off range hood after
ten minutes
Special control indicates when it's time to clean the filter
Dishwasher-safe filter features a quick-release latch and
decorative cover plate
Heat Sentry
- automatically turns blower to high speed
TM
when excess cooking heat is detected

OPTIONS

Flue extension for 10' ceiling (Model FEXTISER222)
Replacement grease filters available
Replacement bulb (Part No. SB02300891)
Exterior blower version available (IEX222)
REFERENCE
QTY.
BEST BY BROAN P.O. BOX 140 HARTFORD, WISCONSIN 53027
REMARKS
SPECIFICATION SHEET

SPECIFICATIONS

VOLTS
AMPS
CFM
120
6.26
1000
Mount range hood so bottom of hood is
24" minimum above cooking surface.
Project
Location
Architect
Engineer
Contractor
Submitted by
70D
SONES
DUCT
10.0
8" round
HVI-2100 CERTIFIED RATINGS comply
with new testing technologies and
procedures prescribed by the Home
Ventilating Institute, for off-the-shelf
products, as they are available to
consumers. Product performance is rated
at 0.1 in. static pressure, based on tests
conducted in AMCA's state-of-the-art test
laboratory.
Sones are a measure of
humanly-perceived loudness, based on
laboratory measurements.
Date
99042854E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Best ISER222 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Broan Best ISER222 Series

  • Page 1 Flue extension for 10’ ceiling (Model FEXTISER222) • Replacement grease filters available • Replacement bulb (Part No. SB02300891) • Exterior blower version available (IEX222) BEST BY BROAN P.O. BOX 140 HARTFORD, WISCONSIN 53027 REFERENCE QTY. SPECIFICATION SHEET SPECIFICATIONS VOLTS AMPS 6.26...
  • Page 2 ISER222 SERIES WIRING Air Outlet Ø 7-7/8” Wiring Box Controls Side ISER222 SERIES MOUNTING 10-7/8” 7-13/16” BEST BY BROAN P.O. BOX 140 HARTFORD, WISCONSIN 53027...
