Center 360 Instruction Manual

Autoranging insulation tester
Hide thumbs Also See for 360:
Table of Contents

Advertisement

Quick Links

360
0
1000
2000
M
TEST
4000M
250V
V
OFF
Lo
600V
CAT I I
I
1000V
CAT
I I
3000
4000
V
4000M
500V
4000M
1000V
M
Hi
V
1000V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 360 and is the answer not in the manual?

Questions and answers

Related Manuals for Center 360

Summary of Contents for Center 360

  • Page 1 1000 2000 3000 4000 TEST 4000M 250V 4000M 500V 4000M 1000V 600V CAT I I 1000V 1000V...

  • Page 2: Table Of Contents

    CONTENTS TITLE PAGE I. SAFETY INFORMATION ………………………………………... 1 Environment conditions………………………………………….. 1 Maintenance & Cleaning………………………………………… 1 Safety symbols…………………………………………………..… 2 II. GENERAL SPECIFICATION ……………………….…………... 2 III. ELECTICAL SPECIFICATION ……………………………..…. 3 IV. SYMBOL DEFINITION & BUTTON LOCATION ………….… 4 V. MEASURING FUNCTION ……………………………………... 5 1.

  • Page 3: Safety Information

    AUTORANGING INSULATION TESTER  instruction manual SAFETY INFORMATION Read the following safety information carefully before attempting to operate or service the meter. The circuit under test must be de-energized and isolated before connections are made except for voltage measurement. Circuit connections must not be touched during a test. After insulation test, capacitate circuits must be allowed to discharge before disconnecting the test leads.

  • Page 4: Safety Symbols

    AUTORANGING INSULATION TESTER  instruction manual Safety symbols: Caution (Refer to this manual before using the meter) Dangerous voltages, risk of electric shock. Meter is protected throughout by double insulation. When servicing, use only specified replacement parts. Approvals: EN-61010-1 600V CAT III 1000V CATII VDE 0413 II.

  • Page 5: Electical Specification

    AUTORANGING INSULATION TESTER  instruction manual III. ELECTRICAL SPECIFICATION: AC Voltage Range Resolution Accuracy 600V 0.1V 1.5%rdg+5dgts DC Voltage Range Resolution Accuracy 600V 0.1V 1%rdg+3dgts Ω Ohms ( Autoranging ) Range Resolution Accuracy 400Ω 0.1Ω 1%rdg+5dgts 4000Ω 1Ω Continuity beeper Range Active Protection...

  • Page 6: Symbol Definition & Button Location

    AUTORANGING INSULATION TESTER  instruction manual IV. Symbol Definition and Button Location Low Battery High Voltage Output Lock Enable Data Hold Continuity Beeper Enable Analog Bar Scale 21000 42000 63000 84000 Analog Bar Display Measuring unit Digital Readout Dangerous Voltage IEC 1010 600V CAT III 1000V CAT II...

  • Page 7: Measuring Function

    AUTORANGING INSULATION TESTER  instruction manual V. MEASURING FUNCTIONS 1. ACV Function: Turn function selector to voltage range. Connect black test lead to Lo terminal and red one to the Hi terminal. Connect test lead to the test circuit in parallel. One can hold the reading by pressing the HOLD key.

  • Page 8: Auto Power Off

    AUTORANGING INSULATION TESTER  instruction manual Manual Mode: Press and hold the test key to active the test voltage source. A periodic beeping will warn the high voltage output. Release the test button to stop the test voltage output. A series of beeping with shorter period indicate the discharging in progress.

  • Page 9: Battery Changing

    AUTORANGING INSULATION TESTER  instruction manual VII. BATTERY CHANGING When appear on the LCD, the battery need to be replaced with new ones. To replace the battery the user should turn the function selector to OFF position. Then the user needs to open the battery compartment cover with a screwdriver.
  • Page 10 CENTER TECHNOLOGY CORP. 4 / F NO. 415, Jung-Jeng Rd., 238 Shu-Lin Chien, Taipei, Taiwan TEL : 886-2-26763926 E-Mail : center@centertek.com FAX : 886-2-26763925 http : / / www.centertek.com 360 -01...
