ANthony 101 Service & Installation

Including pass-thru door
Hide thumbs Also See for 101:
Table of Contents

Advertisement

Quick Links

Model 101 & 2100
(Including Pass-Thru Door Models 103, 105,
107, 2125, 2127, 2130)
Service & Installation
November, 2012
99-13312-S001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 101 and is the answer not in the manual?

Questions and answers

Tom Mazz
March 29, 2025

where can we purchase keys for existing locks and what information do you require

0

Related Manuals for ANthony 101

Summary of Contents for ANthony 101

  • Page 1 Model 101 & 2100 (Including Pass-Thru Door Models 103, 105, 107, 2125, 2127, 2130) Service & Installation November, 2012 99-13312-S001...

  • Page 2: Table Of Contents

    Model 101/2100 Doors Service & Installation Contents: 1. Models 101 & 2100 Door & Frame – Reversible Parts Placement (Start 10/89) ....6 2. Models 101 & 2100 Reversible Door Parts Placement (1989 to 1991) .........7 3. Models 101 & 2100 Standard (Before 7/94) Frame Net Opening Widths......8 3.1.1.
  • Page 3 41. Model 101 & 2100 Shelf Assembly Catalog Size/Shelf Size ..........40 42. Models 101 & 2100 Frame & Shelving with Standard Lighting..........42 43. Models 101 & 2100 Frame & Shelving with “ELS” Electronic Lighting ........43 44. Four-Post Stabilizer Bar Installation ..................44 45.
  • Page 4 69. Electrical Information for Model 101 Normal Temp Heated Doors, Frames & Standard Light Fixtures Heater Amperages @ 120 Volts ..............73 70. Heat Load in BTU/Hr for Model 101 Low Temp Glass, Door Rail, Frame Heaters and Standard Lighting (Per Door, with Doors Closed @ 75°F Store Ambient)......76 71.
  • Page 5 78. Electrical Information for Model 101 Normal Temp Doors, Frames & “ELS” Electronic Lighting System Heater Amperages @ 120 Volts ...............84 79. Heat Load in BTU/Hr for Model 101 Normal Temp Glass, Door Rail, Frame Heaters and “ELS” Electronic Lighting System (Per Door, with Doors Closed @ 75°F Store Ambient) ..87 80.

  • Page 6: Models 101 & 2100 Door & Frame - Reversible Parts Placement (Start 10/89)

    Model 101/2100 Doors Service & Installation 1. Models 101 & 2100 Door & Frame – Reversible Parts Placement (Start 10/89) Change s: 199 1 to Present 1. Hinge Rail is hollow. 2. Use #2 Hinge Pin; replaces #1. 3. Delete #11 Receptacle.

  • Page 7: Models 101 & 2100 Reversible Door Parts Placement (1989 To 1991)

    Model 101/2100 Doors Service & Installation Models 101 & 2100 Reversible Door Parts Placement (1989 to 1991) Changes: 1991 to Present 1. Hinge Rail is hollow. 2. Use #17 Hinge Pin; replaces #9. 3. Delete #10 Receptacle. 4. Use #18 Torque Rod; replaces #12 5.

  • Page 8: Models 101 & 2100 Standard (Before 7/94) Frame Net Opening Widths

    Model 101/2100 Doors Service & Installation Models 101 & 2100 Standard (Before 7/94) Frame Net Opening Widths TWO-DOOR FRAME THREE-DOOR FRAME FOUR-DOOR FRAME FIVE-DOOR FRAME 3.1. Frame Width Data 3.1.1. 24” Door (Catalog Size) 23-3/16” Actual Door Width ENDLESS FINISHED FRAME 48-5/8”...

  • Page 9: Models 101 & 2100 Standard Frame Net Opening Heights

    5. Check net opening for plumb and square as shown. Sill must be level left to right and front to back. a. Jambs, header and sill should be wood for a secure installation b. Anthony door frame needs a sill of at least 1-1/2” for proper installation. TITLE: REV.

  • Page 10: Frame Divider Board Installation (Prior To 1993)

    4. When adding divider boards and frame sections, always make sure frames are plumb and square. 5. Continue adding frames and divider boards to complete line-up. 6. Divider boards must be snug between sill and header. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 10 of 95...

  • Page 11: Reversible/Cordless Door & Hold-Open Installation

    1. Align door with torque rod and insert into the Torquemaster socket at base of door. 2. Engage door with hinge pin plug inserted into hinge pin plug receptacle at top of frame. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 11 of 95...

  • Page 12: Reversing Frame Hardware

    (marked SAG ADJ) with a flat-head screwdriver. 6. Do not use power tools for installation or removal. Reversing Frame Hardware 1. Remove Torquemaster by turning center screw counter-clockwise. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 12 of 95...

  • Page 13: Door Reversing Instructions Models 101 & 2100 (1989-1991)

    3. Insert back safety cover plate into opposite side hinge receptacle. 4. Do not use power tools for installation or removal. Door Reversing Instructions Models 101 & 2100 (1989-1991) 1. Release tension on Torquemaster by turning front screw clockwise. TITLE: REV.
  • Page 14 Model 101/2100 Doors Service & Installation 2. On Hold-Open (1990 to Present), remove shoulder screw from camel back hinge on back of door (Model 101 and 2100 Hold-Open Instructions). 3. Remove hinge pin plug from frame by inserting needle-nose pliers into hinge pin plug 1/8”...
  • Page 15 7. Remove torque rod by sliding it out bottom of door and insert in opposite end of door. 8. Model 101 & 2100 have only one female receptacle. When reversing door, also reverse receptacle. Pull receptacle from one end and feed back down through opposite end.

  • Page 16: Door Reversing Instructions (1991 To Present)

    Model 101/2100 Doors Service & Installation 9. Carefully replace hinge pin access covers. 10. Do not use power tools for installation or removal. 11. See Model 101 & 2100 torque rod below. 10. Door Reversing Instructions (1991 to Present) Door Quick Disconnect and Reversing 1.

  • Page 17: Models 103, 105, 107, 2125, 2127 & 2130 Pass-Thru Installation

    Installation instructions. 4. With door in closed position, adjust floor wiper seal to fit flush with door and/or slab. Turn screws clockwise to tighten and counter-clockwise to loosen. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 17 of 95...
  • Page 18 Model 101/2100 Doors Service & Installation 5. For additional bottom support, Anthony Pass-Thrus are equipped with a base plate and two special floor anchor bolts. 6. Pass-Thru Frame Wiring Diagrams a. With Threshold Heater Wire b. Without Threshold White Black...

  • Page 19: Frame Sill Plastic Protector Installation Models 101 & 2100

    2. Model 2125: 1/3 clear glass, 2/3 solid color glass. 3. Model 2127: All clear glass with colored border, and Roll-A-Way cart. 12. Frame Sill Plastic protector Installation Models 101 & 2100 1. Set metal protector on sill inside of case between clear opening of frame, with curved edge over bottom sill plastic.

  • Page 20: Contact Plate And Contact Plate Retainer Replacement

    End and Center Mullion (1987 to Present) Note: In the illustration above, Model 100R is shown. Model 100FR is the same except for the mullion and mullion contact plate. Model 101 is the same except for the mullion cover as shown in Door Quick Disconnect and Reversing.

  • Page 21: Ordering Replacement Doors

    4. Specify model: Cooler or Freezer? 5. Specify finish. 6. Specify any custom items in the original order. 7. Specify date of original order and/or Anthony confirmation/invoice number. (Original manufacture date is stamped on metal spacer bar between panes of glass, as shown above.

  • Page 22: Torquemaster Replacement

    Torquemaster and frame and gently pry up. 3. Reverse instructions to replace. 16. Door Gasket Replacement Door Gasket 1. Remove old gasket by starting in corner, gently pulling gasket away from plastic. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 22 of 95...

  • Page 23: Door Plastic (Cover) Replacement

    3. To replace, insert inside edge of plastic into inside door rail groove. Snap outside edge of plastic over outside edge of door rail. 18. Door Cut-Away & Handle Replacement Handle Replacement Door Cut-Away TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 23 of 95...

  • Page 24: Side Access Plate Replacement (1989 To 1991)

    Door Quick Disconnect and Reversing 2. To remove side access plate, insert small flat-head screwdriver under edge of cover and lift up. 3. Snap plate into door extrusion to replace. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 24 of 95...

  • Page 25: Door Female Plug Replacement (1989 To 1991)

    Model 101/2100 Doors Service & Installation 21. Door Female Plug Replacement (1989 to 1991) 1. Model 101 Only – Gently insert flat-head screwdriver under edge of top side access plate and pull up to remove ( Hinge Pin and Cover Plate/Door Cut-Away 2.

  • Page 26: Door Heater Replacement (1989 To 1991) Model 101 Only

    Model 101/2100 Doors Service & Installation 23. Door Heater Replacement (1989 to 1991) Model 101 Only 1. Remove door gasket and plastic. 2. Remove side access plate ( Door Cut-Away 3. Unsnap hinge pin from female receptacle. 4. Wiring for the door is done in the center side of hinge rail.

  • Page 27: Hinge Pin Replacement (1989 To 1991)

    3. Reverse instructions to replace. 26. Hinge Pin Replacement (1991 to Present) 1. Model 101 & 2100 - Remove center hinge side access plate ( Door Quick Disconnect and Reversing 2. Unplug Black or Red lead wire from hinge pin from Black solid heater wire lead.

  • Page 28: Torque Rod Replacement (1987 To 1991)

    Note: Torque rod has no tip. 30. Front Bumper Bar Field Installation Front Bumper Bar 1. Order door guards 1” smaller than actual door width. 2. Specify finish (Gold/Silver). TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 28 of 95...

  • Page 29: Model 101 Door Cylinder Lock Replacement Or Repair

    Model 101/2100 Doors Service & Installation 3. Anthony provides pre-drilled screw holes in bar. Customer must drill a #30 or 1/8” hole in door rail 13/16” from each side of door rail. 4. Screws for mounting bar are self-tapping. Screws are not to exceed 3/8” in length.

  • Page 30: Lock Installation

    8. Lock only side that inserts into hinge access plate. 9. Facing doors, the lock on the right side is for left-hinged doors and the lock on the left side is for right-hinged doors. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 30 of 95...

  • Page 31: P.o.m. Lock Installation

    10. The P.O.M. Lock is manufactured to install in frame on top of handle rail side of door. 11. For retrofitting the P.O.M. Lock on existing doors in the field, contact Anthony Customer Service or the local Sales Representative for information and instructions.

  • Page 32: Model 101 Glass Replacement (Reglazing)

    1. To remove torque rod from door, drive tapered shaft of torque rod from door. 2. Starting at corner of door, remove gasket and plastic from all four sides of door. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 32 of 95...

  • Page 33: Title: Rev

    5. Drive rails from glass, using mallet and block, always starting at corner of door. 6. Once rails have been removed from glass, re-insert new friction-fit glazing channel on new glass and drive rails onto glass. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 33 of 95...
  • Page 34 10. When replacing heated glass, bus bars on glass (colored bars on top and bottom of glass or up and down the sides) must go to the front of door, or customer side. This is the heated side. 11. For questions about glass replacement, call Anthony’s Customer Service or local Sales Representative. TITLE: REV.

  • Page 35: Ordering Replacement Frames

    35. Ordering Replacement Frames Replacement Frames (All Swing Doors) 1. Specify outside tip-to-tip dimensions of frame. Measure to nearest 1/16”. 2. Specify date of original manufacture and/or Anthony confirmation/invoice number. 3. Specify Cooler or Freezer. 4. Specify door size (width and height).

  • Page 36: Frame Heater Wire Replacement

    3. Remove contact plate to expose heater wires. 4. See following page for frame heater schematics. 5. Cut heater at the lead wire and pull heater out of track. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 36 of 95...

  • Page 37: Models 101 & 2100 Frame Heater Schematic/Low Temp

    6. When ordering replacement heaters, specify which heater needs replacing: top, bottom, end or center mullion heater. This varies depending upon the particular frame make-up.. Reverse instructions to re-install heater. 37. Models 101 & 2100 Frame Heater Schematic/Low Temp 3-Door Frame (Typical for 2 Thru 5 Doors) Heater Wire Layout: Bottom and End –...

  • Page 38: Humastat Installation Procedure

    6. Connect Green Ground wire from control unit to Green Ground wire at frame and to incoming Ground wire (if furnished). 7. Replace the Wiring Compartment Cover with the sheet metal removed in No. 2 above. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 38 of 95...

  • Page 39: Title: Rev

    10. Insert the sensor plug into the sensor jack on the outside end of the power junction box. 11. Set the heater control knob for the lowest value which keeps the door free of undesirable moisture. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 39 of 95...

  • Page 40: Model 101 Humastat

    1. Sensor is prewired in frame mullion. 2. For Low Temp applications, see Sensor Part #F-161. 3. For Normal Temperature applications, see Sensor Part #F-1649. 41. Model 101 & 2100 Shelf Assembly Catalog Size/Shelf Size TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation...
  • Page 41 23 5/16” x 27” size 22 9/16” x 27” 26” 26 5/16” x 27” For 3 Doors or more, use 23 5/16” x 27” 30” 29 13/16” x 27” TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 41 of 95...

  • Page 42: Models 101 & 2100 Frame & Shelving With Standard Lighting

    42. Models 101 & 21 Frame & shelving with Standard Lighting , , 1 M" < > , '/ • ._::-r •• .,..,i • 1"'1 • < • • • < • TITlE: """ 42of 95 99-13312-8001Mode 101/2100 Doors Ser..tce & hstallation Page...

  • Page 43: Models 101 & 2100 Frame & Shelving With "Els" Electronic Lighting

    Anthony· 43. Models 101 & 21 Frame & shelving with "ELS" Electronic Lighting •' 1---lf- -t-1--- - · • TITlE:...
  • Page 44 " "" Page 99-13312-8001Mode 101/2100 Doors Ser..tce & hstallation """ TITlE: 99-13312-8001Mode 101/2100 Doors Ser..tce & hstallation Page 42of 95...

  • Page 46: Four-Post Stabilizer Bar Installation

    1. Attach post to inside frame by inserting post key into frame retaining bracket. 2. Before installing shelves, adjust all front posts to equal heights with leg leveling bolts at bottom of posts. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 44 of 95...

  • Page 47: Title: Rev

    5. After installing shelves, adjust rear post leveling bolts to level. The Four-Post Shelf System is now ready for merchandising. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 45 of 95...

  • Page 48: Plastic Tag Molding Installation

    2. Snap top corner of tag molding strip onto shelf front. Apply even pressure across top of tag molding as it is fed onto top horizontal bar on shelf front. 3. For replacement tag molding, specify width of shelf when ordering. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 46 of 95...

  • Page 49: Model 2100 G.f.i. Location & Wiring Diagram

    3. To replace bulb, insert new bulb into lamp shield and snap in end caps. To replace lamp, lift bulb up into top plunger socket, then set into bottom socket. Do not install lamps without lamp shield. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 47 of 95...

  • Page 50: Lamp Socket Replacement

    “D” hole and snap socket down to install. 5. Replace lamps. 6. For safety and efficiency, lamps should never be installed without shields. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 48 of 95...

  • Page 51: Recessed Light Socket Replacement

    1. Insert flat-head screwdriver under back edge of light channel retainer to remove. 2. To replace, lay light channel into mullion, then snap on retainer as shown. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 49 of 95...

  • Page 52: Recessed Lamp Guard Replacement With Remote Ballast

    3. To replace bulb, insert bulb into top light socket and set into bottom socket. 4. Re-install light guard and clips. 54. “Boost & Buck” Transformer Wiring Diagram 1. Recommended wiring for 110/120 volt applications. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 50 of 95...

  • Page 53: Frame Junction Box Wiring (Standard Production)

    1-Blue/White common for lights. 1-Green/Yellow for ground. 56. Models 101 & 2100 Light Fixture Placement (Prior to 10/93) Pre-wired lighting uses only 1-light ballasts. Non pre-wired uses 1- or 2-light ballasts. Frame Breakdown – Each Frame Section with Full Flange TITLE: REV.

  • Page 54: Models 101 & 2100 Light Fixture Placement - "Continuous" Lineup (10/93 To Present)

    = Light X = No Light D = Wood Divider Example: 6-Door Lineup (2 sets of 3) of Model 101 or 2100 with Full Flange 57. Models 101 & 2100 Light Fixture Placement – “Continuous” Lineup (10/93 to Present) Pre-wired lighting using 1- or 2-light ballasts. Continuous lineup with “E.L.S.” lighting.

  • Page 55: Models 101 & 2100 Low Temp 120-Volt Remote Ballast And Lamp Wiring Diagram For 1-Light Systems

    Anthony· 58. Models 101 & 2100 Low Temp 120-Volt Remote Ballast and Lamp Wiring Diagram tor 1-Light Systems !llK '/IKf UNI\Itf$i.L t'95lS ·.TC-- HMPiallasl Kll..K\ 15:»2...

  • Page 56: Title: Rev

    Model 101/2100 Doors Service & Installation """ TITlE: 99-13312-8001Mode 101/2100 Doors Ser..tce & hstallation Page TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 54 of 95...

  • Page 57: Title: Rev

    Anthony· 59. Models 101 & 2100 Low Temp 120-Volt Remote Ballast and Lamp Wiring Diagram tor 2-Light Systems >O .t8110CIJNWO{>Iil F601 10CIINH0{6)"} (7?"} F'?Z110CNNHO 2-Lamp 83118$1 KU.KA*530-2 TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 55 of 95...
  • Page 58 " "" TITlE: Page 99-13312-8001Mode 101/2100 Doors Ser..tce & hstallation...

  • Page 59: Models 101 & 2100 Normal Temp 120-Volt Remote Ballast And Lamp Wiring Diagram For 1- & 2-Light Systems

    Model 101/2100 Doors Service & Installation 60. Models 101 & 2100 Normal Temp 120-Volt Remote Ballast and Lamp Wiring Diagram for 1- & 2-Light Systems Lighting Diagram for 1- & 2-Light Ballast 61. Models 101 & 2100 Normal Temp 120-Volt Remote Ballast and Lamp...

  • Page 60: Normal Temp & Low Temp 120-Volt Ballast And Lamp Wiring Diagram - Pre-Wired 1-Light System

    Black wire goes to hot, White wire goes to neutral. 63. Ballast Replacement 1. For replacement ballast, always use ballast number from existing ballast. 2. Remove door from frame opening. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 56 of 95...

  • Page 61: Els" Lamp Socket Replacement

    Do not gang wire. 64. “ELS” Lamp Socket Replacement WARNING: Before servicing Anthony doors make sure all power to case is off. Always use a qualified electrician. 1. Remove front contact plate retainer.

  • Page 62: Title: Rev

    10. Insert ballast lead wires into socket connections. 11. Re-install bulb, lens and front contact plate. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 58 of 95...

  • Page 63: Els" Electronic Ballast Replacement And Wiring Instructions

    Model 101/2100 Doors Service & Installation 65. “ELS” Electronic Ballast Replacement and Wiring Instructions WARNING: Before servicing Anthony doors make sure all power to case is off. Always use a qualified electrician. 1. Refer to drawings on following pages for ballast location and wiring.

  • Page 64: Title: Rev

    8. Lay contact plate flat on mullion. Staring at the top, insert contact plate retainer into front edge of mullion. Snap retainer on back edge of mullion. Repeat instructions for opposite side. 120V Electronic Ballast Wiring Diagrams TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 60 of 95...

  • Page 65: Title: Rev

    Model 101/2100 Doors Service & Installation 120V ELS Lighting System Component Layout 1-Door Section 2-Door Section 3-Door Section TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 61 of 95...

  • Page 66: Title: Rev

    Model 101/2100 Doors Service & Installation 4-Door Section 5-Door Section 220V Electronic Ballast Wiring Diagrams TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 62 of 95...

  • Page 67: Title: Rev

    Model 101/2100 Doors Service & Installation TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 63 of 95...
  • Page 68 Model 101/2100 Doors Service & Installation 220V ELS Lighting System Component Layout 1-Door Section 2-Door Section 3-Door Section 4-Door Section TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 64 of 95...

  • Page 69: Lamp Replacement Instructions

    (as shown in the following figure). On one side at a time, pull clip out of pre-punched holes in side of mullion. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 65 of 95...

  • Page 70: Title: Rev

    4. With the lens removed, hold lamp with fingers and twist bulb to line up with socket access holes. Remove old bulb. Remove insulator tubes from both ends of old bulb and replace on ends of new bulb. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 66 of 95...

  • Page 71: Title: Rev

    7. Starting at the top on one side of the light fixture, line up the edge of the lens with the groove in the fixture plastic. Snap lens into groove. Repeat with lens on the other side, if removed. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 67 of 95...

  • Page 72: Title: Rev

    2. Remove top and bottom spring steel clips. Insert small flat-head screwdriver under flat portion of spring steel clip to remove from side of fixture (as shown in the following figure). Swing clips to the side until re-installation. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 68 of 95...

  • Page 73: Title: Rev

    To install new bulb, place into socket and turn two clicks. There are foam end caps on the top and bottom of lamp sockets. End caps must be attached before lens is replaced. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 69 of 95...

  • Page 74: Title: Rev

    (Foam end caps are cut to fit snugly, but if they have become dislodged, or pulled out during changes, they must be replaced!) 7. Turn light power on. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 70 of 95...

  • Page 75: Dew Point Chart

    % REL HUMIDITY @ WHICH CONDENSATION FORMS ON GLASS Calculations make no allowance for air leaks or unusual air flow patterns within cases and are intended to be used as guidelines only. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 71 of 95...
  • Page 76 Model 101/2100 Doors Service & Installation 68. Electrical Information for Model 101 Low Temp Heated Doors, Frames & Standard Light Fixtures Heater Amperages @ 120 Volts NUMBER OF DOORS: STYLE: Low temp doors with heaters, 3-Pane Heated Reflective Glass (5.75 W/SQ. FT.) F, Humidity 75% or less, @ 75 F ambient.
  • Page 77 Model 101/2100 Doors Service & Installation 69. Electrical Information for Model 101 Normal Temp Heated Doors, Frames & Standard Light Fixtures Heater Amperages @ 120 Volts NUMBER OF DOORS: STYLE: Normal temp doors with heaters, 2-Pane Non-Heated Glass F, Humidity 65% or less, @ 75 F ambient.
  • Page 78 30 x 75 5.39 5.88 6.37 6.86 7.35 7.84 8.33 8.82 9.31 9.80 0.55 30 x 79 5.78 6.30 6.840 7.36 7.89 8.40 8.93 9.47 9.99 10.52 0.55 TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 74 of 95...
  • Page 79 4. Design parameters do not make allowances for factors such as air leaks or unusual air flow patterns within cases; therefore, some sweating may occur when upper limits of temperature or humidity are encountered. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 75 of 95...

  • Page 80: Standard Lighting (Per Door, With Doors Closed @ 75°F Store Ambient)

    Model 101/2100 Doors Service & Installation 70. Heat Load in BTU/Hr for Model 101 Low Temp Glass, Door Rail, Frame Heaters and Standard Lighting (Per Door, with Doors Closed @ 75°F Store Ambient) MODEL 101 LOW TEMPERATURE (3-PANE HEATED REFLECTIVE GLASS – CASE TEMP -10°F)
  • Page 81 2919 3593 30 x 75 1671 2393 3116 3839 30 x 79 1720 2467 3214 3962 NOTE: Add 10-20% to above values depending on door opening frequency. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 77 of 95...

  • Page 82: Heat Load In Btu/Hr For Model 2100 Low Temp Glass, Door Rail, Frame Heaters And Standard Lighting (Per Door, With Doors Closed @ 75°F Store Ambient)

    30 x 75 1238 2176 3114 4052 4990 30 x 79 1269 2237 3206 4174 5143 NOTE: Add 10-20% to above values depending on door opening frequency. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 78 of 95...

  • Page 83: Electrical Information For Model 2100 Low Temp Heated Doors, Frames & Standard Light Fixtures Heater Amperages @ 120 Volts

    30 x 75 22.71 24.72 26.61 28.62 30.57 32.96 34.91 36.80 38.81 40.76 0.85 30 x 79 23.91 26.10 27.99 30.18 32.22 34.80 36.84 38.73 40.92 42.96 0.85 TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 79 of 95...

  • Page 84: Electrical Information For Model 2100 Normal Temp Doors, Frames & Standard Light Fixtures Heater Amperages @ 120 Volts

    4. Design parameters do not make allowances for factors such as air leaks or unusual air flow patterns within cases; therefore, some sweating may occur when upper limits of temperature or humidity are encountered. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 80 of 95...

  • Page 85: And Standard Lights (Per Door, With Doors Closed @ 75°F Store Ambient)

    30 x 36 1285 1638 1991 30 x 67 1123 1573 2022 2471 30 x 75 1173 1647 2121 2595 30 x 79 1198 1684 2171 2657 TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 81 of 95...

  • Page 86: Heat Load In Btu/Hr For Model 101 Low Temp Glass, Door Rail, Frame Heaters And "Els" Electronic Lighting System (Per Door, With Doors Closed @ 75°F Store Ambient)

    2483 NOTE: Add 10-20% to above values depending on door opening frequency. 76. Heat Load in BTU/Hr for Model 101 Low Temp Glass, Door Rail, Frame Heaters and “ELS” Electronic Lighting System (Per Door, with Doors Closed @ 75°F Store Ambient) MODEL 101 “ELS”...

  • Page 87: Electrical Information For Model 101 Low Temp Doors, Frames & "Els Electronic Lighting System Heater Amperages @ 120 Volts

    Model 101/2100 Doors Service & Installation 77. Electrical Information for Model 101 Low Temp Doors, Frames & “ELS Electronic Lighting System Heater Amperages @ 120 Volts NUMBER OF DOORS: STYLE: Low temp doors with heaters, 3-Pane Heated Reflective Glass (5.75 W/SQ. FT.) F, Humidity 75% or less @ 75 F ambient.

  • Page 88: Electrical Information For Model 101 Normal Temp Doors, Frames & "Els" Electronic Lighting System Heater Amperages @ 120 Volts

    35.60 37.68 39.60 41.84 43.92 78. Electrical Information for Model 101 Normal Temp Doors, Frames & “ELS” Electronic Lighting System Heater Amperages @ 120 Volts NUMBER OF DOORS: STYLE: Normal temp doors with heaters, 2-Pane Non-Heated Glass F, Humidity 65% or less, @ 75 F ambient.
  • Page 89 3. Design parameters do not make allowances for factors such as air leaks or unusual air flow patterns within cases; therefore, some sweating may occur when upper limits of temperature or humidity are encountered. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 85 of 95...
  • Page 90 34.16 30 x 79 19.66 21.45 23.22 25.01 26.79 28.60 30.38 32.15 33.94 35.72 4. See following chart for calculating additional Light Amperage for “ELS” Electronic Lighting: TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 86 of 95...

  • Page 91: Heat Load In Btu/Hr For Model 101 Normal Temp Glass, Door Rail, Frame Heaters And "Els" Electronic Lighting System (Per Door, With Doors Closed @ 75°F Store Ambient)

    2.07 2.62 3.38 3.93 79. Heat Load in BTU/Hr for Model 101 Normal Temp Glass, Door Rail, Frame Heaters and “ELS” Electronic Lighting System (Per Door, with Doors Closed @ 75°F Store Ambient) MODEL 101 “ELS” NORMAL TEMPERATURE (2-PANE NON-HEATED GLASS – CASE TEMP 38°F)

  • Page 92: Electrical Information For Model 2100 Low Temp Doors, Frames & "Els" Electronic Lighting System Heater Amperages @ 120 Volts

    4. See following chart for calculating additional Light Amperage for “ELS” Electronic Lighting: TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 88 of 95...

  • Page 93: Heat Load In Btu/Hr For Model 2100 Normal Temp Glass, Door Rail, Frame Heaters And "Els" Electronic Lighting System (Per Door, With Doors Closed @ 75°F Store Ambient)

    1380 1787 2193 30 x 36 1012 1240 30 x 67 1237 1603 1968 30 x 75 1386 1795 2204 30 x 79 1002 1423 1845 2266 TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 89 of 95...

  • Page 94: Heat Load In Btu/Hr For Model 2100 Low Temp Glass, Door Rail, Frame Heaters And "Els" Electronic Lighting System (Per Door, With Doors Closed @ 75°F Store Ambient)

    4.64 30 x 75 0.49 0.98 1.47 1.96 2.45 2.94 3.43 3.92 4.41 4.90 30 x 79 0.51 1.02 1.52 2.03 2.54 3.04 3.55 4.06 4.57 5.08 TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 90 of 95...
  • Page 95 9.30 30 x 75 5.39 5.88 6.37 6.86 7.35 7.84 8.33 8.82 9.31 9.80 30 x 79 5.58 6.09 6.60 7.11 7.62 8.12 8.63 9.14 9.65 10.16 TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 91 of 95...

  • Page 96: Troubleshooting

    Hinge Pin installed in female plug in door f. High velocity fans on back of frame g. Energy Management System (Sensor) 2. Low Voltage? Check: a. Supply voltage – low voltage TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 92 of 95...
  • Page 97 1. Incorrect ballast? 2. Defective bulb? 3. Incorrect voltage? 4. Bulbs without shields? C. Slow-Starting Bulb: 1. Improper wiring? 2. Poor lamp and socket connections? 3. Voltage too low? TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 93 of 95...

  • Page 98: Safety Precautions

    4. For binding gasket or plastic parts, use a food grade silicone. 5. Always replace lamp shields when lamps are replaced. 6. Preventive maintenance is the key to door and frame longevity. TITLE: REV. 99-13312-S001 Model 101/2100 Doors Service & Installation Page 94 of 95...
  • Page 99 5884361, D600529, 7603882, 7273299, 7674019, D404935, D395968, D612517, 5622414, 7731395 ,8250873 B2. Anthony products are covered by one or more of the following Foreign Patents: Canada: 2233401, Mexico:185899, 186644, 202491, 238593, 227313, 236090. Other United States and Foreign Patents Pending.

This manual is also suitable for:

2100212510321272130105 ... Show all

Table of Contents
