Broan Best IS102 Series Specification Sheet

IS102 SERIES
RANGE HOODS
The graceful curvature of the free-hanging flue and
canopy dramatizes the appearance of this hand-
rolled, masterpiece.

FEATURES

•
Italian design
•
Island ceiling mount
•
Finishes: 304 Stainless Steel #4 Brushed, White, Black
•
Size: 90cm x 120cm (35-7/16" x 47-1/4")
•
Telescopic flue accommodates 8' to 9' ceilings
•
8" round duct connector/backdraft damper
•
Halogen lighting (4 x 20 watt, Type JC 12V 20W G4 Base -
bulbs included) provides bright cooktop illumination
•
Slide controls: on-off, 3-speed
•
Quiet, variable speed, dual centrifugal blowers with two
high-efficiency motors produce 1000 CFM of exhaust
•
Dishwasher-safe filter features a quick-release latch and
decorative cover plate
•
Heat Sentry - automatically turns blower to high speed
TM
when excess cooking heat is detected

OPTIONS

•
Flue extension for 10' ceiling (Model FEXTIS102)
•
Replacement grease filters available
•
Replacement bulb (Part No. SB02300891)
•
External blower version available (IEX102)

SPECIFICATIONS

VOLTS AMPS CFM
120 6.26 1000
REFERENCE QTY.
SONES DUCT
12.0 8" round
BEST BY BROAN P.O. BOX 140 HARTFORD, WISCONSIN 53027
REMARKS
SPECIFICATION SHEET
Mount range hood so bottom of hood is
24" minimum above cooking surface.
HVI-2100 CERTIFIED RATINGS comply with new
testing technologies and procedures prescribed by the
Home Ventilating Institute, for off-the-shelf products,
as they are available to consumers. Product
performance is rated at 0.1 in. static pressure, based
on tests conducted in AMCA's state-of-the-art test
laboratory. Sones are a measure of humanly-perceived
loudness, based on laboratory measurements.
Project
Location
Architect
Engineer
Contractor
Submitted by
70D
Date
99042844E
