VISTA VISTA VISTA VISTA- - - - 15PMT 15PMT 15PMT 15PMT VISTA VISTA VISTA VISTA- - - - 20PMT 20PMT 20PMT 20PMT Programming Guide AR ME RE AD Y This control is a certified SIA-compliant control that meets SIA specifications for False Alarm Reduction. K5305-1MTPRV9 3/11 Rev.
AVS QUICK PROGRAMMING COMMANDS (for AAV sessions using the AVS system) For controls with the following firmware revision levels, these commands automatically configure the control for AVS operation. VISTA-15PMT = version 6.0 or higher; VISTA-20PMT = version 7.0 or higher • installer code + [#] + 03: enable AVS operation •...
DATA FIELD PROGRAMMING FORM Entries apply to both the VISTA-15PMT and VISTA-20PMT controls, except entries shown in dashed boxes apply only to the VISTA-20PMT (partition entries) and are not applicable to the VISTA-15PMT. Entry of a number other than one specified will give unpredictable results. Values shown in brackets are factory defaults.
Page 5
∗ ∗ ∗ ∗ 42 Secondary Phone No. ∗ ∗ ∗ ∗ 35 Entry Delay #1 [30,30] 30 - 96 = 30 - 96 seconds Part. 1 Part. 2 Can be changed by corporate installer code only. Enter up to 97 = 120 secs 20 digits.
Page 6
∗ ∗ ∗ ∗ 56 ∗ ∗ ∗ ∗ 57 ∗ ∗ ∗ ∗ 58 Menu Modes ∗ ∗ ∗ ∗ 50 Burglary Dialer Delay [2,0] These are Menu Mode commands, not data fields, for Zone Programming, Function Key Programming, and Expert Mode Zone Delay Time Delay Disable Delay Time:...
Page 7
+[#] + [0] + 2 = test report sent every 28 day Each mode sets schedule 32 (VISTA-20PMT) or schedule 08 Sent after a system low-battery condition is restored to (VISTA-15PMT) to the stated repeat option; first test report normal. sent 12 hours after command † .
Page 8
∗ ∗ ∗ ∗ 86 ∗ ∗ ∗ ∗ 91 Cancel Verify Keypad Display Option Selection / Remote [8, 0] 0 = no; 1 = yes Interactive Services (RIS) Enable This feature causes a “ALARM CANCELED” display on the Entry 1: Options LCD keypad under the following conditions: 0 = None •...
Page 9
PAGER OPTIONS (✱160- ✱172) ∗ ∗ ∗ ∗ 93 Reports In Armed Period [1,0] The system can send various reports to several pagers (MTV20P = up to 4; MTV15P = up to 2). Per Zone (Swinger Suppression) Restrict Unlimited To program pager reporting, do the following: Restrict Report Pairs: Report Pairs Reports...
Page 10
∗ ∗ ∗ ∗ 163 MISCELLANEOUS SYSTEM FIELDS (*174-*181) Pager 2 Phone No. ∗ ∗ ∗ ∗ 174 Clean Me Reporting Options Enter up to 20 digits. 0–9; #+11 = 'Q'; #+12 = '#'; #+13 = 2- (for ESL smoke detectors) sec pause.
Page 11
Enter the codes sequentially (all 6 digits). When 7 = part. 3 (common; auto-stay arm disabled) entering digits, [#] moves cursor back, [∗] moves forward. VISTA-15PMT: Up to two AUI devices. Select the desired Press [∗] when done to continue. option.
Page 12
Services feature of the communication device, select an address (00-15) of device causing the fault (e.g., faults on option 5-7 (option 5 for VISTA-15PMT), depending on the device 07 display as “107”). partition the Remote Services device is associated with Select “1”...
CONFIGURABLE ZONE TYPES WORKSHEETS Configurable zone types 90 and 91 can be programmed via downloader software or from a keypad using data fields*182- *185. Configurable zone types 92 and 93 (VISTA-20PMT only) can only be programmed using the downloader software. Programming Configurable Zone Type options involves making 10 entries in data field *182 for zone type 90 and field *184 for zone type 91, where each entry represents the sum of the values of the various options shown in the tables below.
01-08 (and 09-48†) HARDWIRE TYPE wireless 09-48; RF button zones 49-64 Appears only for zones 02-08. Zone 1 is automatically set for EOL VISTA-15PMT: operation. Enter the desired hardwire type: wired 01-06 (and 07-22†) 0 = EOL 3 = zone doubling (ZD)†...
INPUT S/N ∗ ∗ ∗ ∗ 58 EXPERT ZONE PROGRAMMING MODE Enroll the transmitter’s serial number and loop number as follows: 1. a. Transmit two open/close sequences (for button-type (press ∗ ∗ ∗ ∗ 58 while in Data Programming mode) transmitters, press and release the button twice, waiting This method is designed for use by installers with previous experience about 4 seconds before pressing the button the second...
WIRELESS KEY PROGRAMMING TEMPLATES (press the [D] key from *58 Menu mode Summary Screen) This procedure programs the wireless keys, but a key is not active for arming/disarming until it is assigned to a user number (see System Operation section, Assigning Attributes Command in the Installation Instructions). TEMPLATE ? ENTER START ZONE Enter desired template number 1–6 (see chart below), then press...
(01-18). Use *79 Menu Mode to assign output numbers and map them to device addresses. The VISTA-15PMT supports 8 relays and 2 built-in trigger outputs (total 10 outputs). Output Functions: The system also provides installer-defined output functions, which can be assigned to any of the physical outputs.
(if zone type was selected) OUTPUT FUNCT. # ENTER ZN TYPE Enter the output function number to be defined (VISTA-20PMT: 01-48; VISTA-15PMT: 01-24). Enter the desired zone type. See list below *80 Worksheet for zone types. [∗] to continue; 00 = exit...
Enter each zone number (01-64†) to add to the zone list, followed by pressing [∗] (example, 01∗, 02∗, 03∗). Press 00 to continue. † VISTA-20PMT = 01-64; VISTA-15PMT = 01-06, 09-34, 49-56. IMPORTANT: Do not include fire zones in zone lists that are used to STOP device actions.
Program Alpha prompt. Enter 0 again to exit Descriptor mode. To Assign Partition/Custom Message Descriptors, use Adding Custom Words procedure, but: VISTA-15PMT: Use word number 11 in step 2. The custom message replaces the standard “DISARMED Ready to Arm” message.
ALPHA VOCABULARY LIST (For Entering Zone Descriptors) DOOR ∗ ∗ ∗ ∗ (Word Space) – L – – R – – V – • 057 LAUNDRY ∗ ∗ ∗ ∗ – A – RADIO VALVE • 059 DOWN • 106 •...
Some events are reserved for the installer only. NOTES: • The master code can only access schedules 01-16 (VISTA-15PMT = 01-04) and events 00-07. • System clock must be set before schedules can take effect. • Programmed schedules do not take effect until the next scheduled “start” time. (e.g., if programming a schedule time window for 8AM to 5PM, the schedule does not take effect until 8AM after the schedule has been programmed.)
When either the #03 or #04 Quick Program command is used, the following are automatically programmed and no longer available for other control panel purposes. Pre-Programmed #03 Command #04 Command Output Function No. VISTA-15PMT series VISTA-20PMT series VISTA-15PMT series VISTA-20PMT series 22 (zone type 60, relay 07) 46 (zone type 60, relay 15)
∗ ∗ ∗ ∗ 29 COMMUNICATION DEVICE MENU MODE (Pass-Through Programming) This mode is for programming an IP, GSM, or IP/GSM Communicator Module using an alpha keypad. Alternatively, these options can be programmed via the AlarmNet Direct website. After programming is complete, the module must be registered with AlarmNet before reporting via the communication device can occur.
ZONE TYPE DEFINITIONS Zone types define the way in which the system responds to faults in each zone. Type 00 Zone Not Used Type 12 Monitor Zone • Works as a dynamic monitor of a zone fault/trouble (not alarm). In Program a zone with this zone type if the zone is not used.
UL NOTICES 1. Entry Delay No. 1 and No. 2 (fields ∗ 35, ∗ 36) cannot be greater than 30 seconds for UL Residential Burglar Alarm installations, and entry delay plus dial delay should not exceed 1 minute. For UL Commercial Burglar Alarm installations, total entry delay may not exceed 45 seconds.
WORKSHEET for SCHEDULES (installer code + [#] + [6] [4]; master code can only access schedules 01-16 for VISTA-20PMT, 01-04 for VISTA-15PMT, and events 00-07 for both controls; VISTA-15PMT supports up to 8 schedules, VISTA-20PMT supports up to 32 schedules ) Event Device No.
WORKSHEET for ∗ ∗ ∗ ∗ 56 ZONE PROGRAMMING (VISTA-15PMT supports up to 32 zones: 1-6, 9-34, 49-56) [default shown in brackets] Zone Zn Type Part. Report Hardwire Rsp. Time Location Type [09] [10] [EOL] [01] [10] [EOL] [03] [10]...
WORKSHEET for ∗ ∗ ∗ ∗ 57 FUNCTION KEY PROGRAMMING Comments P1 P2 P1 P2 P1 P2 P1 P2 Option Function Paging Time Display Arm AWAY Arm STAY Arm NIGHT-STAY Step Arming Device Activation Device: Comm. Test Macro Key 1 Assign each macro key to only a single partition.
WORKSHEET for ∗ ∗ ∗ ∗ 80 OUTPUT FUNCTION PROGRAMMING Fill in the required data on the worksheet below and follow the programming procedure in the installation manual as you enter the data during the displays and prompts that appear in sequence. Notes: 1.
TABLE OF DEVICE ADDRESSES This Device Uses Address Reports as †† Enabled By… RF Receiver *56 zone programming: input device type entry AUI (touchscreen) 1 Automatic if field *189 enabled for AUI 1 AUI (touchscreen) 2 Automatic if field *189 enabled for AUI 2 AUI (touchscreen) 3 05** Automatic if field *189 enabled for AUI 3...
