Keep the polisher clean for best and safest performance.
Before each use check abrasive attachments for condition. If worn or damaged replace immediately.
ensure there are no flammable or combustible materials near the work area.
WARNING! Wear approved eye safety protection, ear defenders and if dust is generated, respiratory protection.
maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
remove ill fitting clothing. remove ties, watches, rings, and other loose jewellery and tie back long hair.
Keep children and unauthorised persons away from the working area.
secure non-stable work piece with a clamp, vice or other adequate holding device.
remove adjusting keys and wrenches from the machine and its vicinity before turning it on.
DO NOT use equipment for any purpose other than that for which it is designed.
DO NOT operate the polisher if any parts are damaged or missing as this may cause failure or possible personal injury.
WARNING! DO NOT sand any materials containing asbestos.
DO NOT switch the polisher on whilst the head is in contact with the work piece and avoid unintentional starting.
DO NOT get the polisher wet or use in damp or wet locations or areas where there is condensation.
DO NOT allow untrained persons to operate the polisher.
DO NOT operate the polisher when you are tired, under the influence of alcohol, drugs or intoxicating medication.
DO NOT use the polisher where there are flammable liquids, solids or gases such as paint solvents, etc.
DO NOT leave the polisher operating unattended.
DO NOT carry the polisher with your finger on the power switch.
DO NOT pull the cord to remove the plug from the power supply.
use a qualified person to lubricate and maintain the polisher.
When not in use unplug from the mains power supply and store in a safe, dry, childproof area.
LEAD PAINT WARNING! Paint once contained lead as a traditional ingredient. contact with the dust from the removal of such paint is toxic
and must therefore be avoided. the following action must be taken before using machine as a sander:
1.
user must determine potential hazard relating to age of paint to be removed. (modern paints do not have lead content).
2.
DANGER! Keep all persons and pets away from the working area. the following are particularly vulnerable to the effects of lead
paint dust: expectant women, babies and children.
3.
We recommend personal protection by using the following safety items:
A) Paint spray respirator (sealey ref. ssP1699) B) Pe coated Hooded coverall (sealey ref. ssP266). c) latex Gloves (sealey
ref. ssP24).
4.
take adequate measures to contain paint dust, flakes and scrapings. Wear safety equipment, as in (3) above and thoroughly clean
all areas when task is complete.
5.
ensure the paint waste is disposed of in sealed bags or containers according to local regulations.
2. INTRODUCTION
Powerful 1100W motor enclosed in a lightweight housing. maintains high torque levels at low speeds, ideal for polishing. Variable speed control
from 1000-3000rpm. spindle lock for fast and easy pad/foam head changes. supplied with side handle, backing pad and polishing bonnet.
3. SPECIFICATION
Model: . . . . . . . . . . . . . . . . . . . . . . ER1700P.V3
nominal Power rating: . . . . . . . . . . . .1100Watts
Power Input: . . . . . . . . . . . . . . . . . . . . . . . . 230V
no load speed: . . . . . . . . . . . . . . 600-3000rpm
Pad size: . . . . . . . . . . . . . . . . . . . . . . . . . 180mm
noise Power: . . . . . . . . . . . . . . . . . . . . . 82dB(A)
noise Pressure:. . . . . . . . . . . . . . . . . . . 71dB(A)
spindle: . . . . . . . . . . . . . . . . . . . . . . . . . m14 X 2
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4Kg
4. CONTENTS
Item
description
1
Polisher unit
2
Pad (hook and loop)
3
side Handle
4
Polishing Bonnet (lambs Wool)
5. ASSEMBLY
5.1.
Warning! ensure that the polisher unit is not plugged into the mains before attempting any assembly or disassembly.
5.2.1. screw on the side handle, either side (fig.1.).
5.2.2. to attach the hook and loop pad item 2, lock the spindle by pressing the lock button (fig.2), and screw the pad clockwise on to the
spindle until it stops. Hand tight is sufficient; the pad will tighten further in use. to remove, lock the spindle by pressing the lock button
(fig.2) and turn the pad anticlockwise.
5.2.3. Fit the polishing bonnet centrally over the secured hook and loop pad.
© Jack sealey limited
Powered direction
of rotation
Qty
1
1
1
1
m14 X 2 right hand thread
fig.1
Original Language Version
3
1
2
er1700P.V3 Issue: 3(sP) - 07/12/16
4
