GF Signet 8850-2 Manual page 3

Conductivity/resistivity transmitter
Table of Contents

Advertisement

3.1 System Power/Loop Connections
Stand-alone application, no current loop used
Transmitter
Terminals
Sys. Pwr.
4
Loop -
Sys. Pwr.
3
Loop +
AUX
2
Power -
1
AUX
Power +
Connection to a PLC/Recorder, separate supply
Transmitter
Terminals
Sys. Pwr.
4
Loop -
Sys. Pwr.
3
Loop +
AUX
2
Power -
AUX
1
Power +
AUX power required for all 8850 systems
3.2 Sensor Input Connections
Wiring Tips:
Do not route sensor cable in conduit containing AC power wiring. Electrical noise may interfere with sensor signal.
Routing sensor cable in grounded metal conduit will help prevent electrical noise and mechanical damage.
Seal cable entry points to prevent moisture damage.
Only one wire should be inserted into a terminal. Splice double wires outside the terminal.
Select the sensor with a range closest to your process minimum
and maximum values.
2819-1 (0.01 cell): 0.055 to 100 µS (10 kΩ to 18 MΩ)
Use the 2819-1 for all resistivity requirements
2820-1 (0.1 cell):
2821-1 (1.0 cell):
2822-1 (10.0 cell):
2823-1 (20.0 cell):
Shield (Sensor Gnd)
14
Black (Iso Gnd)
13
White (Temp In)
12
Red (Signal In)
11
Terminals
‡ SIGNET 8850-2 Conductivity/Resistivity Transmitter
Power Supply
DC 12 - 24 V
Power
-
Supply
Power
+
Supply
DC 12 - 24 V
-
Power
Supply
Power
+
Supply
PLC or Recorder
-
Loop Input
4-20 mA in
Loop Input
+
4-20 mA in
1 to 1000 µS
10 to 10,000 µS
100 to 200,000 µS
200 to 400,000 µS
+GF+ SIGNET 28XX-1
Standard and Certified Cells
Connection to a PLC with built-in power supply
Transmitter
Terminals
Sys. Pwr.
4
Loop -
Sys. Pwr.
3
Loop +
AUX
2
Power -
1
AUX
Power +
Example: Two transmitters connected to PLC/Recorder
Transmitter 1
Sys. Pwr.
4
Loop -
Sys. Pwr.
3
Loop +
AUX
2
Power -
AUX
1
Power +
Transmitter 2
Sys. Pwr.
4
Loop -
Sys. Pwr.
3
Loop +
AUX
2
Power -
AUX
1
Power +
Ultra-
Pure
Pure
Rinse
2823-1
2822-1
2821-1
2820-1
2819-1
0.055
1
10
100 200
1,000
(10 kΩ)
(18 MΩ)
Conductivity Range (µS)
≤ 100 ft. (30 m)
Conductivity/Resistivity
62.50 uS/cm
25.0°C
ENTER
PLC
Terminals
Power Supply
-
Ground
+
Power
Supply
-
Loop Input
4-20 mA
+
Loop Input
4-20 mA
Internal PLC
Connection
with separate power supply
DC 12 - 24 V
Power
Supply
Power
Supply
PLC or Recorder
Channel 1
-
4-20 mA in
+
Channel 1
4-20 mA in
-
Channel 2
4-20 mA in
+
Channel 2
4-20 mA in
+GF+ SIGNET Sensor Ranges
10,000
200,000
400,000
page 3 of 12
