Vermason 231700 Installation, Operation And Maintenance

VACUUM CLEANER AND BLOWER
Installation, Operation and Maintenance
Figure 1. 231700 Vacuum
Cleaner.
Description
Compact lightweight blower /
vacuum cleaner designed for
precise removal and collection of
dry dust particles and debris from
electrostatic static sensitive
devices (ESDS). The conductive
nozzles drain-off any static build-
up to earth.
In order to comply with EN61340-
5 recommendations for working in
an ESD protected area (EPA), the
appliance housing, nozzles, hose,
shoulder strap, cable and
accessories are fully conductive.
The vacuum cleaner can retain
dust and fine dry particles as
small as 0,3 micron, the vacuum
cleaner is fitted with a double-
layer paper filter bag and an
electro-static charged micro-
motor filter.
The appliance can also be
converted in seconds into a
powerful blower for dust removal
in area's otherwise not accessible
- the blower's air-current is cfc-
free and contains no oil or water
residue.
Phone: 0044 (0) 1462 672005, Fax: 0044 (0) 1462 670440 • e-mail: Service@Vermason.co.uk, Internet: Vermason.co.uk
TB-7510 December 2008 Page 1 of 2
TECHNICAL BULLETIN TB-7510
The appliance is constructed to
safety class II: Double insulated
design in compliance with CE
standards.
- Durable and compact design
- Motor has thermal protection
with RFI/EMC filter
- Hose assembly extends to
130cm
- Includes hard crevice and soft
rubber nozzle
- 1.2 l filter bag
- Advanced 5 stage filtration
system
- 3m long power cord
- Conductive carry strap
Inspection
Remove the vacuum cleaner from
the carton and inspect for
shipping damages.
Each unit should include the
following:
1 Vacuum Cleaner (231700 or
231710)
1 1.3m Hose
2 Nozzles
1 Carrying Strap
Optional Accessories:
- 231725: Replacement Bags,
- 231705: Carry Bag
UNIT C, 4TH DIMENSION, FOURTH AVENUE, LETCHWORTH, HERTS, SG6 2TD UK
Pack of 10
Operating instructions
1. Push hose end into
suction opening
2. Press the suction nozzle onto
the free suction hose-end
3. Place rocker switch in off
position
4. Set electronic control to
medium power ( 231700,
231710)
5. Insert the plug into the
electrical supply and start
appliance, pressing on-off
switch to "on" position.
Figure 2. 231700 Vacuum
Cleaner.
If there is substantial loss of
vacuum or blow-pressure, take
the following steps:
6. Remove appliance from
the EPA
7. Check whether nozzle or
suction-hose have become
blocked
8. Switch off appliance and
disconnect plug from
electrical supply
9. Lift metal bottom lock and
remove housing's front cover
10. Remove and replace the
spent paper filter bag
11. Replace electrostatic micro-
motor filter.
© 2008 Vermason
Made in Britain
