The Manual Tablet Testing Instrument PTB 111E is a dual force mode hardness test
apparatus as it can be used for either linear force or linear speed increase while Tablet
Hardness is tested. It offers a multiple point validation procedure for the built-in digital load
cell.
The instrument is made in strict compliance with the EP <2.9.8> and USP <1217>
Pharmacopoeia.
Enter the nominal test information for Hardness via the PTB 111E keyboard. Select the unit
to measure, Kp, N or Sc, now place the sample onto the Sample Dish and start the test. The
driven jaw will now run forward and touch the tablet to measure the hardness (tablet breaking
force).
The result is immediately displayed and printed to a connected Dot-Matrix or suitable PCL
Type Laser- or DeskJet printer. Repeat this until your series has been tested, get a full print
including each individual result, mean value and deviations.
The flexibility and the reproducibility of the results have made this and other models, like the
PTB311E series to become one of the most sold hardness testers.
PHARMA TEST AG
Siemensstrasse 5
D-63512 Hainburg (GER)
29-02840_01-2011E
Manual Tablet Hardness Testing Instrument - Type PTB 111E
+49 6182 9532-600
+49 6182 9532-650
email@pharma-test.de
www.pharma-test.com
Page 1 of 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pharma Test PTB 111E
Summary of Contents for Pharma Test PTB 111E
- Page 1 The instrument is made in strict compliance with the EP <2.9.8> and USP <1217> Pharmacopoeia. Enter the nominal test information for Hardness via the PTB 111E keyboard. Select the unit to measure, Kp, N or Sc, now place the sample onto the Sample Dish and start the test. The driven jaw will now run forward and touch the tablet to measure the hardness (tablet breaking force).
- Page 2 Which force mode to select ? Since more than 15 years all PHARMA TEST Hardness Test instruments offer the possibility to select either linear Force or linear Speed increase. Linear force increase certainly offers the most accurate control, as the rate of increase is directly controlled by the electronically load cell used to read the force.
- Page 3 Testing Tension Strength of Oblong and Caplets The specially designed sample holder and force jaw is suitable to be used in the PTB 111E Testing Instrument. It is designed to test the tension strength at the break line of shaped and also round tablets...
- Page 4 Manual Tablet Hardness Testing Instrument - Type PTB 111E Accuracy: < 0.1% Number of tests for statistics: Up to 250 Calibration Procedure: 10 kg reference weight (certified) Validation breaking detection: PT-MT magnetic tablet Validation force setting: PT-MT3 magnetic tablet Validation linearity of the load cell: PTB-CAL15 certified weight 5, 10, 15 kg...
