Summary of Contents for 3SIXT Fusion Studio
- Page 1 FUSION STUDIO TRUE WIRELESS EARBUDS 3S-1191 USER GUIDE...
-
Page 2: Important Safety Information
Studio True Wireless Earbuds, not doing so could lead to damage to property, others of yourself. • Do not use the 3SIXT Fusion Studio True Wireless Earbuds at high volume for an extended period. Use your earbuds at a comfortable, moderate volume level to avoid potential hearing damage. - Page 3 Welcome Thank you for purchasing the 3SIXT Fusion Studio True Wireless Earbuds. The 3SIXT Fusion Studio True Wireless Earbuds come full of great features, and this guide will allow you understanding around how to operate them safely. For more information and support,...
-
Page 4: Package Contents
PACKAGE CONTENTS 2 X TWS Earbuds Wireless Induction Charging Case USB-A to Micro USB cable 3 X Pairs Assorted Sized – Black Earbuds User Guide... -
Page 5: The Basics
THE BASICS Buttons, Ports & Lights 1. Charging Case 6. LED Light Indicators 2. TWS Earbud 7. LED Ring Indicator 3. Charging Port 8. Left Power On/Off/Pair /Skip/Pause/Voice Assistant 4. Wireless Induction Charging Base 9. Right Power On/Off/Pair /Skip/Voice Assistant 5. - Page 6 OPERATION INSTRUCTIONS Turning on the device 1. Remove the 3SIXT Fusion Studio True Wireless Earbuds from the charging case (1). 2. Push and hold down the on/off buttons (8 & 9) simultaneously for 2 seconds. 2 x sec 3. An audio confirmation via the...
- Page 7 OPERATION INSTRUCTIONS New Device Pairing 1. If not already paired to a device, the 3SIXT Fusion Studio True Wireless Earbuds automatically set themselves into pairing mode. 2. Within your device’s Bluetooth 3S-1191 settings, enable Bluetooth and look for the device name, ‘3S-1191‘.
- Page 8 OPERATION INSTRUCTIONS Additional Device Pairing The 3SIXT Fusion Studio True Wireless Earbuds can pair with up to 8 devices. 1. Turn on the 3SIXT Fusion Studio True Wireless Earbuds by pushing and holding down the on/off buttons (8 & 9) simultaneously for 2 x sec 2 seconds.
- Page 9 Note: Randomised device pairing, can occur when turning on the 3SIXT Fusion Studio True Wireless Earbuds in the proximity of several paired devices. The 3SIXT Fusion Studio True Wireless Earbuds will randomly try to prioritise a single device. Ensure all devices you do not wish to...
- Page 10 OPERATION INSTRUCTIONS Skipping Track Forward press twice to skip 1. While on and playing music with your 3SIXT Fusion Studio True Wireless Earbuds, double press either on/off buttons (8 or 9) to skip forward. Pausing press once to pause 1. While on and playing music with...
- Page 11 OPERATION INSTRUCTIONS Apply Selected Earbuds The 3SIXT Fusion Studio True Wireless Earbuds come with 3 pairs of silicone earbud tips in different sizes to fit depending on the size of your inner ear. Applying is easy. 1. Select the silicone earbud tips to match your inner ear best.
-
Page 12: Led Indicators
LED INDICATORS 3SIXT Fusion Studio True Wireless Earbud LED’s Each Earbud has an LED Ring LED Ring Pairing Status Blue/White LED flashing Pairing mode Connecting Status Blue LED flashing (every 7 sec) Connecting mode Turning Off Status White LED flashes once then turns off... -
Page 13: Charging Methods
CHARGING METHODS 1. The Charge Case uses wireless technology (4). All you need to do is place the charge case on any wireless charge pad for charging to commence immediately. Ensure the earbuds are inserted into the case. 2. The Charge Case has a Micro USB input (3) for standard cable charging. -
Page 14: Tech Specs
TECH SPECS Power input Micro USB 5V 1.0A | Wireless 5W Ingress Rating IPX4 Splash Proof (Earbuds only) Charge Case: Polymer Lithium 3.7v/500mAh Battery Earbuds: 50mAh Wireless Protocol BT v5.0 Distance Up to 10m Audio Output Unit 10 mm x 2 Playback Time Play: 2-3 hours | Talk: 2 hours Standby Time... -
Page 15: Liability Notice
WEEE No: 82898622 EU DECLARATION OF CONFORMITY With the CE sign, 3SIXT, an imported brand of Wentronic GmbH ensures, that the product is conformed to the basic European standards and directives. -
Page 16: Warranty
WARRANTY AUSTRALIA & NEW ZEALAND TWO YEAR WARRANTY 3SIXT will replace the faulty product at no cost to the consumer. The warranty does not extend to any consequential damages or costs that may be incurred and is valid for TWO YEARS from date of purchase. The consumer must return the faulty product to the retail store it was purchased from together with proof of purchase. - Page 17 ASSISTENZA TECNICA 3SIXT Si prega di visitare www.3sixtgear.com/support Copyright © 2018. 3SIXT and its logo are trademarks of Cellnet Group Limited in Australia & New Zealand. All Rights Reserved. CELLNET GROUP LIMITED 59-61 Qantas Drive, Eagle Farm, QLD 4009 Australia.
- Page 18 3S-1191 For more information, visit www.3sixtgear.com or visit www.3sixtgear.com/support 3SIXTgear...
