MM2/Mini4 10/100 Ethernet Daughterboard
(P/N 201750-xxx)
User's Manual
And
Troubleshooting Guide
February 24, 2009
Revision B
Moog Components Group
Springfield Operations
750 West Sproul Road
Springfield, PA 19064
E-Mail:
mcg@moog.com
URL:
www.moog.com/components
Tel: 610-328-4000 Fax 610-605-6216
24/7 Technical Customer Support Hotline: 610-605-6101
Advertisement
Table of Contents
Related Manuals for PRIZM 201750 Series
Summary of Contents for PRIZM 201750 Series
- Page 1 MM2/Mini4 10/100 Ethernet Daughterboard (P/N 201750-xxx) User’s Manual Troubleshooting Guide February 24, 2009 Revision B Moog Components Group Springfield Operations 750 West Sproul Road Springfield, PA 19064 E-Mail: mcg@moog.com URL: www.moog.com/components Tel: 610-328-4000 Fax 610-605-6216 24/7 Technical Customer Support Hotline: 610-605-6101...
- Page 2 Moog Components Group 201750-xxx MM2/Mini4 10/100 Feb 24, 2009 Ethernet Daughterboard Manual, Rev B MANUAL REVISION HISTORY REVISION DATE REASON FOR NUMBER REVISION 5/2/07 ORIGINAL 2/24/09 Updated contact information to reflect Moog Components Group TABLE OF CONTENTS MM2/MINI4 10/100 ETHERNET DAUGHTERBOARD, P/N: 201750-XXX ....... 3 10/100 E :......................
- Page 3 Ethernet Daughterboard Manual, Rev B 1 MM2/Mini4 10/100 Ethernet Daughterboard, P/N: 201750-xxx The Prizm MM2/Mini4 10/100 Ethernet daughterboard combines the functionality of a four- port 10/100 Ethernet switch and a high speed synchronous Ethernet to serial bridge to provide an end-to-end Ethernet link over a fiber multiplexer. This board must be stacked onto a MM2 or a Mini4 motherboard set.
- Page 4 Moog Components Group 201750-xxx MM2/Mini4 10/100 Feb 24, 2009 Ethernet Daughterboard Manual, Rev B 1.2 MM2/Mini4 10/100 Ethernet Daughterboard Revision History: The MM2/Mini4 10/100 Ethernet daughterboard has gone through the following printed circuit board (PCB) and Assembly revisions: PCB Revision A Original design.
-
Page 5: Connectors And Headers
Moog Components Group 201750-xxx MM2/Mini4 10/100 Feb 24, 2009 Ethernet Daughterboard Manual, Rev B Diagnostics connector (J6). NOTE: DIAGNOSTICS NOT AVAILABLE D4 (Green) Located at the lower right edge of the board serves as an indicator that the microprocessor is receiving diagnostics requests from the diagnostics PC through the Diagnostics Header (J4) or Diagnostics connector (J6). - Page 6 Feb 24, 2009 Ethernet Daughterboard Manual, Rev B +3.3V o o 2 o o 4 o o 6 o o 8 NOTE: J1 to be used only by PRIZM. Daughterboard Header VDC Supply o o 2 VDC Supply RXD_DB o o 4...
- Page 7 Moog Components Group 201750-xxx MM2/Mini4 10/100 Feb 24, 2009 Ethernet Daughterboard Manual, Rev B Ethernet Port 4 Diagnostics Connector FUSES: There are three fuses for this board, 1.5 Amp PTC, +5VDC input fuse for “DIAG HEADER” header at J4 - DO NOT PLACE 1.5 Amp PTC, +5VDC input fuse for Daughterboard header at J2 1.5 Amp PTC, +5VDC output fuse for LED header at J12 - DO NOT PLACE...
- Page 8 Moog Components Group 201750-xxx MM2/Mini4 10/100 Feb 24, 2009 Ethernet Daughterboard Manual, Rev B 1.7 MM2/Mini4 10/100 Ethernet Daughterboard Power Requirements: The 10/100 Ethernet daughterboard uses approximately 330mA @ 5VDC. 1.8 MM2/Mini4 10/100 Ethernet Daughterboard Dimensions: PC/104 format - 95.8 mm wide x 90.17 mm long x 13 mm thick (3.775 in x 3.550 in x 0.50 in ) Page 8 of 8...
