  • Page 1 USER MANUAL ENGLISH...
  • Page 2 WELCOME — Phantom Reactor is unique. Based on a new and radical architecture, your system features leading-edge technologies invented by Devialet and protected by over 160 patents. Together, they fuel life into Phantom Reactor. Inside Phantom Reactor you’ll find the latest-generation ADH amplification technology ®...

  • Page 3: Table Of Contents

    USER MANUAL 1. GETTING STARTED P. 4 2. ABOUT PHANTOM REACTOR P. 7 3. PLAYING MUSIC P. 9 4. ADVANCED FEATURES P. 13 5. DEVIALET APP P. 14 6. LEGAL NOTICE P. 15 7. SAFETY INSTRUCTIONS P. 16...
  • Page 4 1. ABOUT PHANTOM REACTOR Indicator light Bluetooth / Analog/Optical Audio Input Press and release: switch between Bluetooth and analog/optical input jack Press and hold: enable Bluetooth pairing mode Volume Press to lower/increase volume Play / Pause Press and release once quickly: Play / Pause...
  • Page 5 Press and release for 2 seconds: Standby mode Press and release once quickly (system in standby mode): Power on Press and release once quickly (system switched on): Indicates status Press and release three times quickly: Enable setup mode Press and hold for 7 seconds: Reset Phantom Reactor.
  • Page 6 Flashing slowly: Bluetooth pairing mode enabled. Flashes twice: Bluetooth connection successful. Orange Flashing: Network connection lost. Solid: Thermal protection mode on. Please unplug and wait for Phantom Reactor to cool down. Violet Solid: Phantom Reactor is performing a factory reset.

  • Page 7: Getting Started

    — A stable Wi-Fi connection with access to high-speed Internet — A smartphone or tablet running on iOS 11 or later or Android 5.0 or later Please note: You can also connect Phantom Reactor to your router with an Ethernet cable instead of using a Wi-Fi network.
  • Page 8 3. Launch Devialet app and follow in-app instructions to complete your setup. Please note: — For each new Phantom Reactor you wish to add, please repeat steps 1. and 3. above in the Devialet app, select “Settings” , then “Add a new product” and follow the instructions.

  • Page 9: Playing Music

    3. PLAYING MUSIC Phantom Reactor lets you enjoy your music in a variety of ways. We recommend the following depending on your preferred sources and listening habits. Please refer to the corresponding section for detailed tutorials on each use case.
  • Page 10 ONLINE Once Phantom Reactor is up and running on your network, you can stream music via Wi-Fi. Make sure the device you want to stream from (smartphone, laptop, tablet…) is connected to the same network as Phantom Reactor. SPOTIFY CONNECT Control your music straight from the Spotify app and enjoy the full Spotify catalog using the Spotify app as a remote.
  • Page 11 1. Press and hold the Bluetooth button for 2 seconds to activate Bluetooth pairing mode. The indicator light will turn blue and blink slowly to indicate Phantom Reactor is ready to pair with nearby Bluetooth devices. 2. Enable Bluetooth on your device (smartphone, tablet or computer).
  • Page 12 Though we strongly recommend installing and running Phantom Reactor on a Wi-Fi network via the Devialet app to get the best experience, you can enjoy Phantom Reactor right out of the box via the analog/optical audio input jack audio jack input.

  • Page 13: Advanced Features

    STANDBY MODE Should you wish to manually enable standby mode, press and hold the rear button for 2 seconds. Phantom Reactor will emit a sound. You can turn your system on again by pressing the same button. ENABLE MANUAL SETUP If Phantom Reactor is fresh out of the box, setup mode will automatically begin when connected to power.

  • Page 14: Devialet App

    — Keep your Phantom Reactor up to date — Register your Phantom Reactor for a personalized care The Devialet app is available to download from the App Store and Google Play, and requires iOS 11 or later, or Android 5.0 or later.

  • Page 15: Legal Notice

    Use of the Works with Apple badge means that an accessory has been designed to work specifically with the technology identified in the badge and has been certified by the developer to meet Apple performance standards. Models: PHANTOM (PA403) / PHANTOM (HW164) WARRANTY Phantom Reactor comes with a 2-year warranty.

  • Page 16: Safety Instructions

    7. SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. — Loudspeakers are fragile, do not touch them. — Input electrical rating shall be respected: 100–240 V ~ 50/60 Hz 2.5A. — Socket-outlet shall be installed near the appliance and shall be easily accessible —...
