Power Unlocked by Design
Quick Start Guide
Solaria PowerXT-R-AC Module Mounting
Guidelines
Important: This guide is not intended to replace the Solaria PowerXT-R-AC Module installation instructions. This is a
brief overview of the module mounting installation process. Always refer to the Installation manual for all safety and
proper installation methodologies.
1. Plan and install the racking
Allowable rail locations with example of typical rail
configuration shown back of module view
2. Position the Q cable
A. Lay out cable to place circuits but do not secure the cable to the rail or modules before installing the modules.
B. Connect the Q Cable.
Position the Q Cable along the edge of the module
Quick Start – Solaria PowerXT-R-AC Module
© 2018 Solaria Corporation All rights reserved. Contents Subject to change.
36.61
RAIL TO
INVERTER
50.80
RAIL WIDTH
101.60
CLAMPING AREA
FRAME
152.40
CLAMPING AREA
September 12, 2018
Advertisement
Table of Contents
Related Manuals for Solaria PowerXT-R-AC
Summary of Contents for Solaria PowerXT-R-AC
- Page 1 Solaria PowerXT-R-AC Module Mounting Guidelines Important: This guide is not intended to replace the Solaria PowerXT-R-AC Module installation instructions. This is a brief overview of the module mounting installation process. Always refer to the Installation manual for all safety and proper installation methodologies.
- Page 2 There is an active “DC Resistance Low, Power Off” condition or “GFDI” fault. Solid red To reset, refer to “DC Resistance Low – Power Off Condition” below. The Microinverter LED Quick Start – Solaria PowerXT-R-AC Module © 2018 Solaria Corporation All rights reserved. Contents Subject to change. September 12, 2018...
