AnyDATA ASP-500GA Driver Installation Manual

Modem installation
Hide thumbs Also See for ASP-500GA:

Advertisement

Quick Links

Download this manual
ASP-500GA Modem Installation Manual
AnyDATA
ASP-500GA Modem
Installation Manual
1/25

Advertisement

loading
Need help?

Need help?

Do you have a question about the ASP-500GA and is the answer not in the manual?

Questions and answers

Related Manuals for AnyDATA ASP-500GA

Summary of Contents for AnyDATA ASP-500GA

  • Page 1 ASP-500GA Modem Installation Manual AnyDATA ASP-500GA Modem Installation Manual 1/25...

  • Page 2: Usb Driver Installation

    1) Connect the and PC’s USB port with supplied USB cable. - The manual driver installation shall be required twice. 2) Installing ‘AnyDATA USB Modem Driver’ window will appear. Select ‘Install from a list or specific location (Advanced )’. 3) Press button to proceed.
  • Page 3 ASP-500GA Modem Installation Manual AnyDATA 7) Click the ‘ Continue Anyway’ button. 8) A window that searches ‘AnyDATA CDMA USB Modem’ will appear. 3/25...
  • Page 4 ASP-500GA Modem Installation Manual AnyDATA 9) Process of installing ‘AnyDATA CDMA USB Modem’. 10) If the installation of ‘AnyDATA CDMA USB Modem’ has been completed, following window will appear. 4/25...
  • Page 5 ASP-500GA Modem Installation Manual AnyDATA 11) Next, it will install ‘AnyDATA CDMA USB Serial Device’. 12) Select ‘Install from a list or specific location (Advanced)’. 13) Press button to proceed. 14) Select the proper path from the CD window will appear.
  • Page 6 ASP-500GA Modem Installation Manual AnyDATA 17) Window that searches ‘AnyDATA CDMA USB Serial Device’ will appear. 18) If the installation has done properly, this window will appear. This will complete the driver installation. 6/25...
  • Page 7 ‘Device Manager’. See the followings to the location of ‘Device Manager’ [Start and Control Panel and System and Hardware Tab and Devise Manager] As shown in below with red boxed that shows ‘AnyDATA CDMA USB Modem’ and ‘AnyDATA CDMA USB Serial Device’, the driver has been successfully installed.
  • Page 8 ASP-500GA Modem Installation Manual AnyDATA 1.2 USB Driver Installation (Windows Vista) The same will apply to Windows Vista 64bit. 1) Connect the USB Modem to the computer. - The manual driver installation shall be required twice. 2) Click ‘Locate and install driver software (recommended)’ when shown in below.
  • Page 9 ASP-500GA Modem Installation Manual AnyDATA 5) Click ‘Brower my computer for driver software (advanced)’. 6) Click ‘Browse’ and click ‘Next’ as shown below. 9/25...
  • Page 10 ASP-500GA Modem Installation Manual AnyDATA 7) ‘Installing driver software’ will be shown as below. 8) Click ‘close’ if driver will be installed successfully as shown below. After the Windows shown above, the driver installation is required one more time. 10/25...
  • Page 11 ASP-500GA Modem Installation Manual AnyDATA 9) Click ‘Locate and install driver software (recommended)’ when shown below. 10) Click ‘Continue’ when ‘User Account Control’ is shown. 11) Click ‘I don’t have the disc. Show me other options.’ 11/25...
  • Page 12 ASP-500GA Modem Installation Manual AnyDATA 12) Click ‘Brower my computer for driver software (advanced)’. 13) Click ‘Browse’ and click ‘Next’ as shown below. 12/25...
  • Page 13 ASP-500GA Modem Installation Manual AnyDATA 14) Click the ‘Install this driver software anyway’. 14) ‘Installing driver software’ will be shown as below. 15) ‘Installing driver software’ will be shown as below. 13/25...
  • Page 14 ‘Device Manager’. See the followings to the location of ‘Device Manager’ [Start and Control Panel and System and Maintenance and Devise Manager] As shown in below with red boxed that shows ‘AnyDATA CDMA USB Modem’ and ‘AnyDATA CDMA USB Serial Device’, the driver has been successfully installed.
  • Page 15 ASP-500GA Modem Installation Manual AnyDATA 1.3 Check Installed Driver 1) Start [Control Panel] 2) Select [System] icon and execute. 3) Select ‘Device Manager’ from Hardware Tab. 15/25...
  • Page 16 ASP-500GA Modem Installation Manual AnyDATA 4) ‘AnyDATA CDMA USB Modem’ will be [Modems] part. 5) ‘AnyDATA CDMA USB Serial Device’ will be [Ports (COM & LPT)] part. 16/25...
  • Page 17 ASP-500GA Modem Installation Manual AnyDATA 2. Data Connection using Windows 2.1 For Windows XP 1) From the control panel, click ‘Network Connection’ 2) Click ‘Create a new connection’ 17/25...
  • Page 18 ASP-500GA Modem Installation Manual AnyDATA 3) Click ‘Next’ 4) Select ‘Connect to the network at my workplace’ and click ‘Next’ 18/25...
  • Page 19 ASP-500GA Modem Installation Manual AnyDATA 5) Select ‘Dial-up connection’ and click ‘Next’ 6) Enter the name of Dial-up Network and click ‘Next’ 19/25...
  • Page 20 ASP-500GA Modem Installation Manual AnyDATA 7) Click ‘Finish’ 8) Double-click created Dial-up Connection 20/25...
  • Page 21 ASP-500GA Modem Installation Manual AnyDATA 9) Enter the User name, Password and Dial and click ‘Dial’ 21/25...

  • Page 22: For Windows Vista

    ASP-500GA Modem Installation Manual AnyDATA 2.2 For Windows Vista 1) Double-click ‘Network and Sharing Center’ 2) Click ‘Set up a connection or network’ 22/25...
  • Page 23 ASP-500GA Modem Installation Manual AnyDATA 3) Select ‘Set up a dial-up connection’ and click ‘Next’ 4) Enter the ‘Dial-up phone number’, ‘User name’, and ‘Password’ and click ‘Connect’ 23/25...
  • Page 24 ASP-500GA Modem Installation Manual AnyDATA 5) Connecting to Internet is being tested 6) Click ‘Close’ 24/25...
  • Page 25 ASP-500GA Modem Installation Manual AnyDATA 7) Click ‘Public location’ 8) Completed Dial-up Connection 25/25...
