AV-GAD EasyLoader AV-2016D Installation And Operation Manual

(for led keypad) integrated alarm control/communicator
Hide thumbs Also See for EasyLoader AV-2016D:
Table of Contents

Advertisement

Quick Links

E a s y L o a d e r
AV-2016D, AV-2016DP
AV-2055D, AV-2088D
(for LED keypad)
Integrated Alarm Control/Communicator
Installation and Operation Manual
Version 3.05
Edition I
This product is subject to continuous enhancements and therefore
specifications may be changed or altered without prior notice
Item 4712_BIG
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyLoader AV-2016D and is the answer not in the manual?

Questions and answers

Related Manuals for AV-GAD EasyLoader AV-2016D

Summary of Contents for AV-GAD EasyLoader AV-2016D

  • Page 1 E a s y L o a d e r AV-2016D, AV-2016DP AV-2055D, AV-2088D (for LED keypad) Integrated Alarm Control/Communicator Installation and Operation Manual Version 3.05 Edition I This product is subject to continuous enhancements and therefore specifications may be changed or altered without prior notice Item 4712_BIG...

  • Page 2: Table Of Contents

    Table of Contents Contents Page SECTION I: FEATURES.................. 4 SYSTEM 1. INTRODUCTION...................... 4 General Description..................4 Programmable Features ................5 Alarm and Power Outputs ................5 Ordering Information..................7 AV-2016D, AV-2055D, AV-2088D Technical Specifications....8 SECTION II: INSTALLATION..................10 2. MOUNTING ......................10 Control Panel Mounting ................
  • Page 3 V: W ..................73 ECTION IRING IAGRAM ......................74 ECTION VI NDEX Av-Gad Limited Warranty ..................76 @ All Rights Reserved to Av-Gad Systems Ltd, Tel Aviv, Israel. POB 49 080 Tel-Aviv, Israel. May 2007/ VER. 3.05, /2016_2088_2055 3.05. Item 4712_BIG...

  • Page 4: System Features

    32 double-zone all of them are programmable. Series 2000 represents the state-of-the-art in user-friendly, reliable alarm control panels for security requirements of small and medium-size commercial, residential, and industrial installations. Av-Gad's EasyLoader AV-2016 and AV-2008 versatile control panels meets and surpasses •...

  • Page 5: Programmable Features

    Built-in Features Accepts Normally Closed or Normally Open alarm devices • All features are programmable via system keypad • Automatic battery test upon arming and during Disarmed or Armed mode • True low battery indication • Built-in central station communicator and dialer. Communicator is compatible with most •...
  • Page 6 Signal test to central station, signaling time and day are programmable • Programmable ‘Bell Mode’ • SPR output toggle mode via hold down key • Remote Signals: • 24H-zone Alarm On/Off (Arming/Disarming) indication Central station Signal Test. Transmitting time is programmable Panic, Tamper alarm Programmable output for each zone or event (SLO output)

  • Page 7: Ordering Information

    Ordering Information Item Code Description AV-2016D 16 + 1 double-zone Alarm Control Panel and Communicator/ Dialer. Supports AV-701, AV-702 keypad. Approved for EEC telephone system (“E” mean CTR-21 compatible) AV-816 16 zone expanding module AV-2016DP 16 + 1 zone Alarm Control Panel and Communicator / Dialer, with 8 partitioned system.

  • Page 8: Av-2016D, Av-2055D, Av-2088D Technical Specifications

    AV-2016D, AV-2055D, AV-2088D Technical Specifications Operating Temperature -10°C to 60°C Relative Humidity 80% maximum Input AC Power 16V AC step-down Transformer 1.7 Amp Dynamic Inner Memory EPROM and SRAM Auxiliary Power Output 13.8 Volts +/- 5%, Regulated Short & Overload circuit protection Siren Outputs (x2) Siren or Bell Selectable Bell Mode: 14V DC-2 x 0.7A (1.4A)
  • Page 9 Sirens: 1.5A Electronic Backup Battery Fuse: 3A Electronic Av-Gad Systems Ltd. reserves the right to modify and upgrade products without prior notice. Electronic Fuse Overview The Electronic Fuse device included as a series element in electric circuit. In response to an over current it protects the circuit by going from a low-resistance to a high-resistance state that reduces the current to a level that’s safe for the circuit elements.

  • Page 10: Section Ii: Installation

    SECTION II: INSTALLATION System planning When the panel reaches you features set at “Factory Defaults”. This done for testing purposes and for installation if required without first entering to programming. This present program is referred to as ‘Factory Defaults.’ The engineer should be familiar with all the features and options before attempting to program.
  • Page 11 Double-Pole Zone wiring This feature saves on wiring and doubles the zone quantity by using two wires instead of four, for both TAMPER and ALARM indications. Use always an EOL resistor; EOL prevents EMI and RFI interference To activate Tamper Alarm, fit the zone with two EOL resistors, program ‘Enable Zone Tamper’ feature (address number 144, 145, 146, 147) and enable ‘EOL Resistor Zone’, entering the data at address (140, 141, 142, 143).

  • Page 12: Connection Of Av-816 Expander

    K.PAD 12V FUSE Colored Wire Screw +12V -12V AV-GAD AV816 AV-816 EXPANDER AV-8616 (old type): CONNECT -V TO AV-816 Figure 2: Zone Expander Wiring Mounting Place the AV-816 board on the left side of the AV-2016 board as the drawing shows.

  • Page 13: Av-2055, 2088D Wiring

    Zone Wiring Mode Via programming, select either End-Of-Line (EOL) Resistor Protection, or non-EOL mode. If EOL mode selected, install EOL Resistor (2.2K/0.25 or 0.5W) inside the detection device (e.g. PIR, Magnetic Switch). To enable EOL mode programming and resistors required. To enable the Tamper Alarm of each zone, refer to the programming table and set the required zone by programming address number 144, 145, 146, 147.

  • Page 14: Keypad Wiring

    Using an eight-zone expander in double zone mode: First zone on the expander count as zone 11. Zones are counted 11 to 18 - connected to terminals 9 to 16 on the expander (use 2K2 resistors). Zones are counted 19 to 26 - connected to terminals 9 to 16 on the expander (use 4K7 resistors).

  • Page 15: Alarm Outputs

    SIR1 AND SIR2 FUSES 1.25A 1.25A -BATTERY +BATTERY BAT. FUSE R99 R100 Keypad Power SIR1 SIR- SIR2 +12V +12V -12V R102 R101 EOL Resistor Tamper Sw (Optional) AUX 12V FUSE R3 R4 Back side of AV-701TIP keypad K.PAD 12V FUSE 1.25A 1.25A +12V...

  • Page 16: Remote Indication Terminals

    Bells or Sirens that require 12V at ideal and 0V during alarm. The Bell output voltage regulated at about 13.6V. For self-contained siren, it is recommended to use Av-Gad Bella 2 or Bella 3 siren, both with Xenon strobe light.

  • Page 17: Wiring And Connection Of Relay Module

    Warning: The remote indications are capable of driving maximum 300 mA, overloading or applying +12V to the remote indications is dangerous and not assured by warranty To drive a low current Strobe Light (Xenon) consuming up to 300 mA, connect the strobe to SLO.

  • Page 18: Back-Up Battery

    pipe using a minimum 16 AWG (or larger) wire, or according to the country grounding standard. Run the ground wire via the shortest possible route. System grounding is compulsory. For trouble free system, use a good ground. Connect the Grounding wire to main board and to the metal box. Note: Connect the Ground wire to the terminal marked .

  • Page 19: Connecting Smoke Detectors

    Reset Relay (or switch) Relay Module like AV-01 or Switch mode, should be Normaly Close (N.C.) For reset cut power for Smoke during 2 Sec's Reset Switch or Relay Module Av-Gad Systems Panels -V at alarm N.C. LAMP EOL resistor 2.2K Resistor 12V, Aux.

  • Page 20: Svm - Voice Module

    Dialing mode is programmable (refer to programming sheet addresses 088 and 089). Connect the telephone line to ‘TEL-LINE’ terminal, if handsets connected to same line connect them to ‘PHONES’, when system attempt to dial the ‘PHONES’ disconnected. Do not connect to ISDN or other digital telephone system.

  • Page 21: Remote Access Via Dtmf

    For Arming/Disarming via Wireless Radio Remote, connect receiver's relay to ‘KE’ and • ‘- Aux. Power’ terminals. Verify the receiver relay mode, momentary, or latch, and set system accordingly. Remote Access via DTMF General Description Remote DTMF enables remote control of the alarm panel from a DTMF phone, this unique feature provides Home Automation function and other functions as detailed below.
  • Page 22 is 50 seconds). The siren sound will stop ten (10) seconds before the end of the call and a greeting tune will be sounded, after the greeting tune enter your code followed by #. To stop the dialer enter 6#, to get panel status enter 7#, to disarm the panel enter 2#. To end the process press 9#.

  • Page 23: Section Iii: Av-701 & Av-702 Digital Keypad

    (X - The required sound). [9 #] - End call. The control panel will sound a confirmation tune and will hang up. SECTION III: AV-701 & AV-702 DIGITAL KEYPAD Standard Keypad Functions AV-GAD EASYLOADER AV-701 ZONE ARMED...
  • Page 24 Shunt Zone Bypass, by pressing key ‘0,’ followed by entering the Zone numbers 01 to 32. Shunt Zone Bypass Via Code (requires programming, see address 071). Press key ‘0’, while 4 LEDs are blinking, enter user code No. 1; When the 2 left- most LEDs are blinking, enter zone number(s) (2 digits format) to be bypassed, four LEDs stop blinking, ‘Shunt’...

  • Page 25: Hold-Down Functions

    Hold-Down Functions Holding down the key for approximately 2 seconds accesses hold-down functions • Hold down functions are confirmed by a long beep • Hold-Down Functions: Siren Key 1 SIREN TEST Shunt Display Key 2 SHUNT DISPLAY Displays shunted zone(s). Status Key 3 STATUS DISPLAY...
  • Page 26 When programming telephone numbers which require an inter-digit delay (‘Pause’) during dialing; Hold-Down key [0], a momentary ‘P’ displayed (Delay duration is 3 seconds). The ‘FOLLOW-ME’ number will be displayed, or displayed and dialed, followed by display- and-dial of up to three additional telephone numbers. Telephone Siren Address 092 enables ‘Answer Now‘...
  • Page 27 Shunt Shunt Detailed Events History (requires programming): Hold down key ‘0’ and again hold down key ‘0’ to display up to 36 events, including: System opening and closing by user number, opening or closing time, alarming zone and AC fail. By holding-down key twice, three LEDs start blinking, to indicate a special operation Shunt...
  • Page 28 Upon display of last event, if an attempt is made to move forward (key 2), a blank sign ‘-‘ is displayed, along with a warning beep indicating that this is the last event. Press key 8 may to move backward. If no key is pressed, Event History stops and system returns to Use mode. When starting History Events mode the events are displayed from the beginning to end without any break, until any browsing key is pressed.

  • Page 29: Keypad Sounder

    Reset Shunt Press (not hold-down) and press (not hold-down), will display ‘-’ to cancel all Bypassed Zones. Keypad Panic Keys PANIC BUTTON Holding down * and # keys will trigger Panic alarm. H will be displayed (zone ‘H’). To cancel Hold-Down function accessed by keys [0], [6] and [7]; Hold-Down key 9 (Reset). To quit zero hold-down functions, hold-down ‘9 Keypad Sounder The Keypad sounder enhances the use of system operation and serves as a local alarm device...

  • Page 30: Led Indicators

    LED Indicators AV-701 and AV-702 Keypads: Four LEDs provide visual indication of System status, as well as confirmation of various modes. Keypad LED’s indication Armed Led-Red AV-2016 AV-2016DP System Disarmed All partitions Disarmed Blink slowly An alarm is triggered At least one partition is armed ON steady System Armed All partitions are ARMED...

  • Page 31: Keypad Digital Display (7-Segment Type)

    Three LEDs Flashing - In Disarmed mode, rapid blinking indicates AC power failure. AC power fail event is displayed in Events History as three lines ≡. Starting version 2.11 the LEDs will blink for six seconds every minute (energy saving). In Armed mode, rapid blinking indicates system restored after AC Power Failure mode.

  • Page 32: Arm And Disarm System Via Av-701/702 Series Keypad

    Tamper Indicates zone's Tamper alarm Update Confirms programming updating User ‘u’ (user) followed by user number when events log is displayed and system is in user code programming mode ≡ displayed upon Arming attempt with non-delayed Arming Denied ≡ (instant) zones in trouble. ≡...
  • Page 33 After Automatic Arming is programmed, the system time can be set only via User Programming Mode: Enter User Programming Mode (hold-down 8 and 1234), hold down '1' ('t' is displayed) and type hour and minutes. Hold down key '1' and wait for the time display. Holding down keys '0' then '1' (in use mode) to program the time is possible only if the Automatic Arming is disabled (otherwise an 'Error’...

  • Page 34: Section Iv: Programming

    SECTION IV: PROGRAMMING 1. SYSTEM CODES Up to sixteen different Arm/Disarm codes and one installer (dealer) code are available; each code consists of 1 to 6 digits. Do not use ‘0’ as the first digit in a code. Do not use ‘5’ as first digit in a code number if Instant Arming via key 5 was programmed. User code must not start with the same numbers as the installer programming code (1994).

  • Page 35: User Code Programming Via Av-701 Keypad (Not With Av-2016Dp)

    User Code Programming via AV-701 Keypad (Not with AV-2016DP) Set New USER-CODE 1. Hold down key Program 2. While the four LEDs are blinking, enter code No. 1 (default 1 2 3 4) 3. If code is valid, the four LEDs stop blinking, and ‘u’ displayed 4.

  • Page 36: Feature Programming At Installer Level

    2. FEATURE PROGRAMMING AT INSTALLER LEVEL Programming Table AV-20055D, 2088D, 2016D, 2016DP (V3.05) 1) ZONE 1 to 16 FEATURES Zone Number 10 11 12 13 14 15 16 Feature Add. Group 1 Add. Group 2 Zone In Use Entry/Exit Delay 1 Entry/Exit Delay 2 Entry / Exit Follower 24-Hour Zone...
  • Page 37 2) TELEPHONES, SIGNAL TEST TIME Tel. 1 Tel. 2 Tel. 3 Tel. 4 Test Signal Time Auto Arm Time Address Time (00:01) 00:00 Tel. 1 is ‘Follow Me’. Tel. 2 and 3 are communicator option. Tel. 4 is Dialer. Test signal to central station. Codes define at (According to programming).
  • Page 38 5) DIAL AND MODEM PARAMETERS Pre- Wait Anti- Dial Dial Tel. Inter- Re-Dial Pulse Pulse Inter Rings Instant Dial tone Mode Call Cycles Make Break Digit qut'y for mode Delay Dial Delay dete- Time Delay (max.) Delay modem Tone ction answer Sec's Sec's...
  • Page 39 9) COMMUNICATOR, REPORT SELECTION. By factory default all zones selected to be reported. Sections 9 and 10 require no programming if Contact ID selected. Group 1 Group 2 Report on Alarm, zone 1-8 Report on Alarm, zone 9-16 Address 040 Address 041 ZONE VALUE...
  • Page 40 10) Communicator Codes - For ALARM, RESTORE, BYPASSED ZONES, OPENING / CLOSING, SIGNAL TEST & FORCE OPENING. The codes appear in 1 DIGIT CODE and in 2 DIGIT CODE are programmed by factory. (Sections 9 and 10 require no programming if Contact ID selected) For communicator codes A to F, enter the following: A=10, B=11, C=12, D=13, E=14, F=15.
  • Page 41 Group 1 Group 2 Zone Bypassed - Codes Zone Bypassed - Codes Zone 1-8 Zone 9-16 ZONE 361 363 365 367 369 371 373 375 ADDRESS 377 379 381 383 385 387 389 391 CODE 1st DIGIT 362 364 366 368 370 372 374 376 ADDRESS 378 380 382 384 386 388 390 392 CODE...
  • Page 42 11) SELECT ZONES FOR PARTITION (Partition No. 01 is by default zone 1 to 32) Zone Number 10 11 12 13 14 15 16 Partition Add. Group 1 Add. Group 2 Partition 01 Partition 02 Partition 03 Partition 04 Partition 05 Partition 06 Partition 07 Partition 08...
  • Page 43 14) TEL. 2 COMMUNICATOR - SUBSCRIBER ID CODES Note: For subscriber ID that contains a ‘0’ (zero), enter 10 in place of 0. ‘0’ will be displayed as ‘A.’ Do not enter 0 0. Group 1 Group 2 Group 3 Group 4 Group 5 Users 1-9...

  • Page 44: Introduction

    Introduction The program determines most of the control panel features. Programming is performed in • order to enable maximum compatibility of the control panel with the specific site. The control panel is supplied with the basic ‘Factory Default Program,’ which is in effect at •...
  • Page 45 Table 10: Addresses 201 to 350 contains the codes that are reported for the selected events. The codes programmed as default factory default; you may change them according to your central station requirements. Do not program if Contact ID format selected. Table 11: Addresses 500 to 531 provides to set the required zone for each partition.

  • Page 46: Glossary Of Programmable Features

    Glossary of Programmable Features Note! A zone not programmed as a 24H, Delayed, Fire or Follower zone, is automatically acknowledged as an Instant zone 24-Hour Zone - Zone programmed for 24-hours protection. Alarm sounded in both Armed and Disarmed modes, indicated by Armed LED blinking. If 24H zone remains troubled after disarming the system a warning buzzer will sound after 10 seconds (allows the user to repair or bypass the troubled zone) from disarming.
  • Page 47 Enable Siren Test upon Arming - Short beep sound for siren test upon arming, indicating that the system armed and siren is OK. To enable this feature (Siren Test upon Arming), enter value ‘1’ in address 070. Enable SLO 1 for Smoke Detector Reset - After the smoke alarm is triggered, reset is required. Pressing key ‘9’...
  • Page 48 time for zones programmed as ‘fast Response’ is not adjustable in AV-2016. Note: Applicable for very short open time contacts. Warning: Fast response zones increase the probability of false alarms. Addresses: 152-155. ‘Follow-Me’ Number - Telephone number programmed by user before Arming, enables user to program a telephone number that will call (follow) him at the locations he go to in case of alarm.
  • Page 49 To meet required standards, use this feature, which ensures that only the Installer (system engineer) can disarm a system in which Tamper alarm occurred while system was Armed. Example: Prevents ‘Self-Burglary’ by owner. Addresses: 071. Manual Bypass (Manual Shunt) - Any zone (1 to 32), selected as Selective Bypass, maybe bypassed (removed from the system) by pressing key ‘0’...
  • Page 50 Panic Alarm - Holding down * and # keys will trigger Keypad Panic alarm; H is displayed (zone ‘H’). To reset the alarm enter a valid code. Panic Zone included at address 196-199, the default is 0. The Panic zone provides to use remote panic buttons; in previous version, only Panic from keypad was available.

  • Page 51: Step - By - Step Programming

    The system status (Armed or Disarmed) reported also if extended, or if two-digit format selected. For example: ‘A’ in address 236 for Armed, and ‘D’ in address 254 for Disarmed. Signal Test enabled by days of the week programmed at address 077. As 1 is Sunday, 7 is Saturday.
  • Page 52 4. To enter new required value press the address number ; followed by the new Program Shunt Siren Delay required value (‘1’ and ‘4’) by pressing in uninterrupted sequence; ‘U’ confirms Siren Delete programming updating. 5. ‘P’ is displayed and the two left-most LEDs are blinking. EXAMPLE 2: 1.
  • Page 53 3. Press ; current value of the address is 2 3 4 6 8; Test Shunt Shunt 3 LEDs will blink and ‘2 3 4 6 8’ will be displayed (default program). Shunt Delay 4. Enter address 071, then enter the new value 1 2 3 4 6 8 by pressing Siren Display Status...
  • Page 54 For example: System installed with the same transmission information for Tel. 1, but single-digit format: 456 - Subscriber ‘456’ F = Low Battery, will report ‘456F’ Two-Digits Event Format Reporting: Reports 2-digit code for each event. Enter 02 or 03 in address 205, and 00 in address 207.

  • Page 55: Reset System To Default Programming

    If your central station requires programming of letters as well as numbers, refer to the HEX programming description. Use the regular programming method of entering each letter or number in each address, as explained in the programming table (HEX method). Contact ID Format (known also as Ademco Express): This is the fastest to program and easiest to use format, with communication speed achieved by the DTMF signaling.

  • Page 56: Dialer- Communicator; Explanation And Programming

    Dialer- Communicator; explanation and Programming Series 2000 Defining the Communicator and Dialer feature Communicator The Communicator is in essence, a dialer that enables communications with a central station digital receiver. The Communicator reports (upon programming) panel events such as Opening, Closing, Alarm, and Low Battery.

  • Page 57: Deleting Telephone Numbers

    3. Enter the required telephone numbers (maximum 16 digits) at address 010 to 013. For example program Tel. 1 to be 00972-36816767; Press 010, the two left LED's blink, enter the number 00972 in sequence, hold-down ‘0’ (pause), enter 36816767; wait for ‘u’ confirmation. To insert * in the telephone number;...

  • Page 58: Downloading From A Computer

    2.12 Downloading from a computer Up and downloading via Modem and Computer (EasyLoad DOS version 3.50) EasyLoad Introduction The remote up and download feature enables fast and simple programming of EasyLoad panels. Programming tables, codes and other features may be up & downloaded from an onsite PC (DOS Mode, 386 or higher) by using an AV-232 adapter cable, or via telephone using a modem and ‘EasyLoad’...
  • Page 59 To initialize the modem properly, use the Auto Detect option before trying to CONNECT, ignore errors that are reported during initialization. The integrated modem in latest (version 2 and later) EasyLoader control panels operates in Answer mode. The dial suffix from the Set-Up screen is no longer relevant! The modem will be silent until the control panel answers the call, then the Modem noise is on (the carrier detection procedure).
  • Page 60 This means you can choose not to use dealer codes. On the other hand, once a dealer code transferred to the panel, to erase or modify the code is impossible. Access to the panel is granted only with this code. To open another client account, select New and enter the account number.
  • Page 61 Address 092 enables ‘Answer Now’ (answers remote computer after 1 ring). The user attending the control panel can reduce the number of rings before answer to one ring. Answering machine bypass In case the alarm panel connected with fax or answering machine on the same telephone line (not recommended) enable the Answering Machine Bypass or Answer Now features (otherwise connection is impossible).
  • Page 62 Events logging ‘History’ events are ‘date’ stamped. The control panel time and date are synchronized to the remote computer when connection is made (as well as when the control panel status is changed by remote PC command). The control panel date can also be locally set, using the keypad by the hold-down ‘0’+’2’+ddmmyy (‘0’...

  • Page 63: Partitioned System - Type Av-2016Dp

    3. PARTITIONED SYSTEM – TYPE AV-2016DP, 8 PARTITIONS Note: The AV-2016DP panels require entering your user code before the necessary activity (hold down function, code entry, etc), this is different then panel AV-2016D. Partition Definition Partition means a group of zones that acts as an independent subsystem. The subsystem can be armed and disarmed separately.

  • Page 64: Av-2016Dp - Users Options

    User 01 is always linked to partition 01, although he Arms or Disarms all the partitions at once! A user code linked to a non-existing partition is ignored. As an exception, User 7 can activate the ‘door’ relay if feature was programming, if such, code 7 cannot do make other function.
  • Page 65 (‘XXXX’ means USER CODE) Arming: XXXX then key 1 - Arms partition (of specific user) Arms all if USER 1 code entered. Arming with open zones in partition will be denied, troubled zones displayed. Arming with Group Bypass: XXXX then key 3 - Arms partition (of specific user) and the defined Group Bypass activated.

  • Page 66: Av-2016Dp - 'Hold Down' Keypad Functions

    XXXX 0 + ZZ - Bypass zones in partitioned system; enter user code, then ‘0’, Shunt Led blinks fast, now enter the zones to be bypass (01, 02, 03,..). User 01 can bypass zones in any disarmed partition. XXXX 0 + 00 - Group bypass in partitioned system, is the same procedure as zone bypass. If issued by User 1 it sets the group bypass for all partitions.
  • Page 67 XXXX ‘5’ - Toggled chime mode (only if all partitions are OFF) MMMM ‘6’ - Display ‘Follow Me’ phone number MMMM ‘6’+’6’ - Erase ‘Follow Me’ phone number MMMM ‘6’+’6’+PPPP - Program ‘Follow-Me’ number (PPPP = follow me number) MMMM ‘6’+’6’+’7’ - Dialer test MMMM ‘7’...

  • Page 68: Av-2016Dp Led Indicators

    AV-2016DP LED Indicators AV-701 Keypad: Four LEDs provide visual indication of System status, as well as confirmation of various modes. Keypad LEDs indication Armed Led-Red AV-2016 AV-2016DP System Disarmed All partitions Disarmed Blink slowly An alarm is triggered At least one partition is armed ON steady System Armed All partitions are ARMED...
  • Page 69 Manual Answer Now (modem setting of the AV-2016DP) Partition System See address 092, set to ‘00’ to disable or ‘01’ to enable (01 by default). Procedure 1. Address 092 set to 01. 2. Enter User 01 code (1234 by default), hold-down key 8. 3.

  • Page 70: Troubleshooting

    4. TROUBLESHOOTING Symptom Possible Cause Remedy Keypad failure Incorrect wiring Check color wire connection • • Blown fuse Check power at panel • • Keypad displays ‘8,’ but does Incorrect connection of Check Orange and Yellow wire not react to pressing of keys data wires (or terminal block) connections at keypad and system...
  • Page 71 Symptom Possible Cause Remedy Cannot disarm system Code was changed Keypad wires are too long • • before instant arming Disable instant arming • ‘Lock in tamper mode’ Verify address 071 value ‘6’ • • ‘P’ displayed after attempt to Verify the last User-Code You may proceed with ‘Default change end-user code...
  • Page 72 For additional assistance, please contact first your local distributor, in case problem not solved contact Av-Gad Systems Ltd, mention your vendor. Our telephone: +972-3-681 67 67, Fax: +972-3-683 5505, E-mail: avgad@inter.net.il Mail: POB 49 080, Tel-Aviv 61 490, Israel. Web site: www.av-gad.com...
  • Page 74 SECTION VI: INDEX Dialer, 8 Abort Report, 46 Dialer Test, 25 AC Power, 8 Dialing, Default, 8 Address, 43 Digital Display, 31 Answer Now, 26 Display Last 2 Users, 28 Answering machine bypass, 46, 61 Door Chime, 25 Arm and Disarm, 32 Double-Pole Zone, 11 Arming - Upon all Delayed Clear, Downloading, 58...
  • Page 75 Keypad Functions, 23 Shunt, 23 Keypad Keys Self Locking, 32 Shunt Display, 25 Keypad Mounting, 10 Single-Digit Format, 53 Keypad Wiring, 14 Siren Test, 25 Siren Test, upon Arming, 46 Smoke Detector Reset, 47 LEDs Flashing, 31 Sounder, 29 Sounder Response, 29 Specifications, 8 No EOL Resistor, 49 Status Display, 25...

  • Page 76: Av-Gad Limited Warranty

    Av-Gad is not an insurer of either the property or safety of the user’s employees, family, or 3rd part and limits its liability for any loss or damage including incidental or consequential damages to Av-Gad original selling price of the product regardless of the cause of such a loss or damage.
