- Page 1 INFUSION PUMP Quick Start Guide 2018...
- Page 2 Removing Pole Clamp Twist knob to retract clamp Use a flat head screwdriver to loosen pole clamp until you can remove clamp from pump Use carabiner clips to secure pump on cage You can secure the pole clamp onto the pump vertically or horizontally using the groves on the pump body...
- Page 3 To silence any alarm press SILENCE key on front of pump...
- Page 4 Running Interface Tubing Infusion Mode Volume Line Pressure Battery Pause Button Being Used Bolus Volume Administered Flow Rate Volume to be Infused Duration of Infusion Volume Administered Status Time & Date...
- Page 5 Infusion Modes Input Rate & Volume To Be Input Volume To Be Infused Input Unit, Dose, VTBI & Infused & Infusion Duration Patient Weight Push ’ Load ’ key to load Push ’ Clear ’ key to clear Push ’ Switch ’ key to previous infusion settings amount infused switch infusion modes...
- Page 6 Getting to Additional Settings & Features To go from the infusion interface to the settings interface press & hold STOP button, and press the top left white key at the same time To get back to the infusion interface while in the settings interface press the same 2 keys...
- Page 7 Tube Type Keep Vein Open Drops/mL* Bolus Accuracy (Calibration) Occlusion Next Air in Line Time & Date Volume Pressure* Backlight Event Log Key Stroke Sound Next Previous Wi-Fi* No Operation Dedicated Set* Almost Done Drop Sensor* Night Mode Next Previous Pause Maintenance Key Pad Lock...
- Page 8 Tube, Accu, & Calibration Choose ‘ Tube ’ you want to calibrate in the ’Tube’ menu (A-J) Up to 10 calibrations can be stored Before each infusion, be sure the correct ’ Tube ’ appears in the top left corner so that the correct infusion settings are used When calibrating we strongly recommend using a gram scale that measure in 0.1g increments or a graduated...
- Page 9 8. Input amount infused next to ‘Real’ (This value Option 6: Accum Vol Coef Adj should be between 5 & 7) Please only make adjustments to Option 6 at the 9. Press ENTER to save this value direction of a PractiVet Product Specialist...
- Page 10 Bolus Rate Bolus Key When the BOLUS key is pressed when infusion in NOT running, the pump will run at 600 ml/hr; this can be used to prime administration set or clear an air bubble Programming an Intermittent Bolus 1. Go to settings interface 2.
- Page 11 Infusion Event Log Be sure the time and date is accurate on your infusion pump to best utilize this feature Once in ‘Log’ menu, select ‘View Log’ Up to 1500 infusion events are stored including alarms, calibration, and infusions...
- Page 12 Setting Up Pause & Idle Function Go into ‘ No Op ’ menu in the settings interface and select the amount of time you would like to allow before alarm sounds with no activity when pump is on with no activity Go into ‘...
