- Page 1 INSTRUCTION MANUAL 7-foot Kids Mini Trampoline with Enclosure SKY3780 Ver. 2...
- Page 2 Thank you for choosing us! Since 2002, Best Choice Products has been bringing customers high-quality products at the absolute lowest price. With everything ranging from instruments and toys to furniture and outdoor, we’ve got your everyday living essentials covered. We’re centered around a customer-first philosophy –...
- Page 3 NOTICE Please retain these instructions for future reference. AGE RANGE: 3 to 10 years old WEIGHT CAPACITY: 185 lbs. • Adult assembly is required. Two adults are recommended. • This trampoline is for household, indoor or outdoor use only. • Only use with adult supervision.
-
Page 4: Cleaning And Storage
WARNING • Misuse and abuse of this trampoline is dangerous and can cause serious injury. • Check the screws, frame, and trampoline bed for any defects before use. • Always inspect the trampoline before each use for wear on the mat and loose/missing parts. •... -
Page 5: Tools Required
TOOLS REQUIRED PHILLIPS/FLATHEAD WRENCH SPRING PULLER (PROVIDED) SCREWDRIVER (PROVIDED) 185 LBS 2 PERSON APPROXIMATELY CAPACITY ASSEMBLY 1 HOUR ASSEMBLY HARDWARE M6 x 45mm M4 x 10mm WASHER SPRING M6 NUT BOLT SCREW WASHER 6 PCS 6 PCS 12 PCS 6 PCS 6 PCS SPRING END CAP... - Page 6 PARTS TOP FRAME JOINT ARCH FRAME STRAIGHT FRAME 6 PCS 3 PCS 6 PCS CURVED FRAME 24” LOWER FOAM MIDDLE FOAM 6 PCS 6 PCS 6 PCS UPPER FOAM 3 PCS PREPARATION • Remove all packaging and parts. Inspect parts to make sure they are in good condition. •...
-
Page 7: Product Assembly
PRODUCT ASSEMBLY Slide six part E vertical legs into three part C horizontal bases. Insert six part 7 end caps and six part D leg covers, two end caps/leg covers per horizontal base. Slide a part G frame joint onto a part F top frame, then insert the frame joint onto a vertical leg. Repeat all the way around to build the trampoline frame. - Page 8 PRODUCT ASSEMBLY Attach six part I straight frames with six part 1 bolts, twelve part 3 washers, six part 4 spring washers, and six part 5 nuts. Slide the elastic loops on the part A trampoline bed onto the straight frames. Position bed so the rings are underneath the trampoline bed pads.
- Page 9 PRODUCT ASSEMBLY Hook thirty-six part 6 springs onto the rings on the trampoline bed. Use the provided spring puller to attach the springs to the holes on the trampoline frame. Tie the trampoline bed pads to the frame. Attach springs at diagonals to spread out the bed, then fill in around the edge.
- Page 10 PRODUCT ASSEMBLY Slide six part K lower foam pieces onto the straight frames. Slide six part L middle foam pieces onto six part J curved frames, then insert them onto the straight frames. Slide three part M upper foam pieces onto three part H arch frames, then insert them onto the curved frames. To make easier, twist foam while sliding onto frame.
- Page 11 PRODUCT ASSEMBLY Align screw holes on the arch frames with the curved frames and secure with six part 2 screws. Attach the part B enclosure net to the enclosure frame by sliding the three net pockets over the arch frames and securing the adhesive strips. Pull the enclosure net down and tie the elastic straps to the trampoline frame.
-
Page 12: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
