ProScope T1 WiFi Microscope
A. Snapshot Button
B. Power Switch /
Snapshot
A
Button
B
Power Switch
C
Indicator Light
D
Micro USB

1. Power Mode

First, please charge the device. It takes about 2 hours to completely charge. When the power is low,
indicator LED light will turn yellow. For power saving, the device will Power-Off automatically after
eight minutes. During eight minutes after auto Power-Off, press Power Switch to give feedback, then
device will keep Power-On mode without auto-Power-Off.

2. APP operation

2.1 For iOS, please go to Apple APP Store search
For Android OS, please go to Google Play Store search
2.2 Press "Power Switch" key 3~5 seconds, blue LED will light up, that is normal working state; press
"Power Switch" key 3~5 seconds, blue LED light will be off, that is Power Off state.
2.3 Go to Settings on Smartphone/Tablet to turn on WIFI and look for All-LightXXXXXX network.
Select it making sure the Tick Mark appears ; the password for ALL-Light WIFI link is "12345678"
USER GUIDE
C. Indicator Light
Short Press: Take a snapshot then save the image to
APP.
Long Press: Record Video then save the video to APP.
Long Press: Power on / Power off
Short Press: Quad View Mode
Blue Light:
Power On and working
Yellow Light: Low Power, only 10% power
Red Light:
Charging
Charging to Full Power: Red light changed to No light
Power charging port (connecting with Power Cable)
"Micro Find"
"Micro Find HD"
then download it.
then download it.
D. Micro USB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProScope T1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bodelin technologies ProScope T1

  • Page 1 ProScope T1 WiFi Microscope USER GUIDE C. Indicator Light A. Snapshot Button D. Micro USB B. Power Switch / Quad View Short Press: Take a snapshot then save the image to Snapshot APP. Button Long Press: Record Video then save the video to APP.
  • Page 2 For example: 2.4 After WiFi link is established, open APP on Smartphone/Tablet (“Micro Find”APP for iOS; “Micro Find HD”APP for Android) 3. Function Bar Description Touch screen to make Function Bar appear :Exit :Color Adjustment :Quad View / Single View :In Quad View - press to screenshot :Record Video :Snapshot...
  • Page 3 4. Quad View 4.1 Quad View is a special function to make a comparison with up to four images. 4.2 Press to make Quad View and press again, and screen goes back to single view. 4.3 When in Quad View mode, once finished taking four photos, press to make screenshot;...
  • Page 4 Trouble Shooting: 1. Unstable wireless or dim LED. Make sure the battery is charged enough. When battery power is low, wireless link will become unstable or LED light of lens will become dim. Please charge immediately. 2. No video displayed on Micro Find APP. Please check power first (Blue light is ON or not).
