**Important: The ProScope
Mobile only works on Apple
iOS devices including iPhone,
iPad and iPod touch. This
device DOES NOT WORK with
Mac or PC computers.
Contents
FCC Statement................................... 2
Preparation before use......................... 4
Using the ProScope Mobile................ 5~7
Image Adjustments............................ 8
Maintenance.................................... 10
FAQ and Troubleshooting................... 11
Specifications................................... 12
Wi-Fi handheld microscope for use with the Apple iPhone, iPod touch, or iPad.*
* iPhone, iPod touch, and iPad are registered trademarks of Apple, Inc.
Instruction Manual
ProScope Mobile
Model:
v1.3.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProScope Mobile and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bodelin technologies ProScope Mobile

Summary of Contents for Bodelin technologies ProScope Mobile

  • Page 1: Table Of Contents

    DOES NOT WORK with Mac or PC computers. Contents FCC Statement........2 Components Name and Function... 3 Preparation before use......4 Using the ProScope Mobile....5~7 Image Adjustments......8 Removing and Installing a Lens.... 9 Maintenance........10 FAQ and Troubleshooting....11 Specifications........12 Wi-Fi handheld microscope for use with the Apple iPhone, iPod touch, or iPad.*...

  • Page 2: Fcc Statement

    FCC Statement THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

  • Page 3: Components Name And Function

    Components Name and Function 3. Lens Release Button 1. Lens Cone 4. LED indicator 6. Camera Button 2. Light Switch 7. Battery Cover 5. Tripod Mount 8. Power Switch Name Function Lens Cone Focusing Position Light Switch For Illumination Lens Release Button Unlocks Lens for Removal LED Indicator Indicates power is ON...

  • Page 4: Preparation Before Use

    Preparation before use Slide off the battery cover and insert (3) AA batteries. Battery cover removed. Insert (3) AA batteries paying attention to the polarity. You may use alkaline or Ni-MH. Do not mix battery types or mix new batteries with old batteries. Rechargeable Ni-MH batteries are recommended for most economical use.

  • Page 5: Using The Proscope Mobile

    2. Turn Wi-Fi ON. 3. Select AirMicro from the wireless network menu. Every ProScope Mobile unit can be different, in this example the wireless network name is AirMicro119. * iPhone, iPod touch, and iPad are registered trademarks of Apple, Inc.
  • Page 6 Using the ProScope Mobile 4. Configure the AirMicro network. Click on the arrow on the AirMicro network which opens a new screen. Click on the Static tab then click on the IP Address field and input the following: 192.168.(3 digit AirMicro network number).(user selectable value between 2-254 which represents a unique IP address for this device.)
  • Page 7 AirMicroPad) app on your device. When the AirMicro app is first launched, it will try to find your ProScope Mobile camera. If it does not find your camera, the searching screen will appear until it finds the camera. Note - if the searching screen persists, check to make sure your AirMicro network is the active Wi-Fi network selected.

  • Page 8: Image Adjustments

    Changing the Camera Resolution The default resolution of the ProScope Mobile is QVGA (320X240) but can be changed to VGA (640X480). To toggle between QVGA and VGA, do the following... With the main Power Switch in the OFF position, press and hold the Camera Button while turning the Power Switch ON.

  • Page 9: Removing And Installing A Lens

    Release Button while turning the base of the lens counter clockwise. When the hash mark on the lens and the hash mark on the ProScope Mobile body line up, you can then gently pull the lens straight up and off.

  • Page 10: Maintenance

    Maintenance Cleaning the Imager To clean any dirt or debris that might collect on the imager, remove the lens and use compressed air to blow off any particles. If further cleaning is required, a cotton swab or microfiber cloth lightly dampened with a 50/50 solution of isopropyl alcohol and water can be used to wipe away any particles stuck to the glass cover of the imager.

  • Page 11: Faq And Troubleshooting

    Q. Why do I get a spinning COG in the AirMicro app? A. Make sure your device is within in the 10 meter range of your ProScope Mobile. If you are within the 10 meter range and the spinning COG persists, the batteries are probably weak and need to be changed. Replace the batteries with a fresh (or freshly charged) set for continued operation.

  • Page 12: Specifications

    Specifications for ProScope Mobile **Important: The ProScope Mobile only works on Apple iOS devices including iPhone, iPad and iPod touch. This device DOES NOT WORK with Mac or PC computers. Compatible Host Devices Apple iOS devices including iPhone, iPad, and iPod touch...
