K10135
Side
2 pcs
L08060
Door
1 pcs
B9169
Base frame
1 pcs
Bumper
Screw flh
7x1,5 mm
3,5x15 mm
2 pcs
2 pcs
24-03-2017 1
/
DU80,060,000
K71120
Base top
1 pcs
K61216
List back
1 pcs
B9169
B9169
B9169
Dustbin
2 pcs
BP00003-BP01905
Rail holder
Screw flh
30,5x30,5 m/ 8
3,5x45 mm
5 pcs
2 pcs
U892,060
K13185
Back panel
1 pcs
BP00417
Mounting plate
Hinge 107 degrees
2 pcs
Screw ph
4x15
Cover
4 pcs
1 pcs
Euroscrew
4,2x9,5
4 pcs
Suspension list
BP00418
BP21XXX or BP20XXX
2 pcs
K13360
1 pcs
Alu profil
1 pcs
1 /
8
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kvik U892-060
Summary of Contents for Kvik U892-060
- Page 1 U892,060 DU80,060,000 K13360 Suspension list K71120 K13185 K10135 Base top Back panel Side 1 pcs 2 pcs 1 pcs 1 pcs K61216 L08060 List back Door BP00417 BP00418 BP21XXX or BP20XXX 1 pcs Mounting plate Hinge 107 degrees Alu profil 2 pcs 2 pcs 1 pcs...
