- Page 1 MBA888 Level switch for bulk materials Installation, operation MBA Instruments GmbH Friedrich-List-Str. 5 D-25451 Quickborn Germany Telephone +49 (0) 4106 123 8888 – 0 Fax +49 ( 0) 4106 123 888 – 9 info@mba-instruments.de www.mba-instruments.de...
- Page 2 Observe the specifications regarding voltage and temperature on the type plate. The MBA888 is used as a level switch for all types of bulk materials. The device is only intended for fixed installation in industrial plants (large tools). The device is designed for zone 21. Furthermore, the shaft end and blade can be fed into zone 20, if a partition wall is installed over the process connection and the requisite leak-tightness is established with the installation.
- Page 3 "Quick Switch" device version: With this version, the MBA888 only checks for a blocking of the shaft rotation in one direction. Very rapid switching as a full indicator is therefore possible: 3. Shaft stops 1. Shaft 2.
- Page 4 Installation of MBA888 24V DC The MBA888 is supplied with a prefabricated cable. The strands on the cable ends are numbered 1 to 4 and must be laid in a suitable terminal compartment. The housing is integrated in the equipotential bonding.
- Page 5 Operating instructions MBA888 Operating data MBA888 – 24V DC version MBA888 – 115V - 230V AC version Operating voltage: 24V DC 115V - 230V AC Power consumption: max. 750mA + current at the signal output Signal: 24/0 V DC max. 1.2A...
- Page 6 Operating instructions MBA888 Dimensions Operating instructions MBA888 09/2015 Page 6 / MBA Instruments GmbH info@mba-instruments.de...
