Page 1: Installation And Operation
MBA888 Level Switch for Bulk Goods Installation and Operation MBA Instruments GmbH Friedrich-List-Straße 3-7 D-25451 Quickborn GERMANY Phone +49-4106 123-888-80 info@mba-instruments.de www.mba-instruments.de... - Page 2 Comply with the voltage and temperature specifications on the rating plate. The MBA888 is used as a level switch for all types of bulk goods. The device may be used only for fixed installation in industrial plant (large machine tools).
- Page 3 +3 s "Quick Switch" device design: On this version, the MBA888 checks whether shaft rotation is blocked in one direction only. This means that the very fast switching allows the device to be used as a "Full" indicator 4. Shaft stops 2.
- Page 4 With screwed cable gland and cable version The MBA888 is supplied with a ready-to-use cable. The flexible leads at the end of the cable are numbered 1 to 5 and must be connected in a suitable terminal compartment. The housing is included in the equipotential-bonding system.
- Page 5 Operating Instructions MBA888 Maintenance The MBA888 is maintenance-free. Nevertheless, you should regularly check proper functioning of the device at least once per annum. 10. Operating data MBA888 24 V DC MBA888 12 V DC 115 V… 230 V AC Operating...
- Page 6 Operating Instructions MBA888 MBA Instruments GmbH Friedrich-List-Straße 3-7 25451 Quickborn GERMANY Telefon +49-4106 123-888-80 info@mba-instruments.de www.mba-instruments.de Operating Instructions MBA888 11/2017/Item No. 8001705 Page 6/6 MBA Instruments GmbH info@mba-instruments.de...
