  • Page 1 Sensors & Controls DALI TOUCHPANEL 02 Manual...

  • Page 2: Table Of Contents

    Manual DALI TOUCHPANEL 02 | 04.2019 | 1.0 | en Table of Contents 1. General information 3 2. Default layout 4 3. Tunable White layout 5 4. User defined configuration 6 5. Reference list 8 2 / 8...

  • Page 3: General Information

    Tunable White Layout User defined configuration The DALI TOUCHPANEL 02 is multi-master-compatible which means that several control modules can be installed in parallel in a DALI system. The DALI TOUCHPANEL 02 is connected directly to the DALI circuit, which also powers the TOUCHPANEL 02. (current consumption = 6 mA).

  • Page 4: Default Layout

    Manual DALI TOUCHPANEL 02 | 04.2019 | 1.0 | en Default layout Button Description Calling up scenes (GO TO SCENE 0) Calling up scenes (GO TO SCENE 1) Calling up scenes (GO TO SCENE 2) Arrow up Brighten (UP) Arrow down...

  • Page 5: Tunable White Layout

    Manual DALI TOUCHPANEL 02 | 04.2019 | 1.0 | en Tunable White layout Button Beschreibung On / Off switching (DAP 100% / DAP 0%) On / Off Key (middle) Dim wheel Recall of several discrete dim values (DAP xxx%) Tunable Whilte button (orange)

  • Page 6: User Defined Configuration

    Manual DALI TOUCHPANEL 02 | 04.2019 | 1.0 | en User defined configuration NOTICE The masterCONFIGURATOR (since V2.6) software can be used to assign each of the 6 buttons on the DALI TOUCHPANEL 02. Adjustable basic reaction of the keys Effective range...
  • Page 7 Manual DALI TOUCHPANEL 02 | 04.2019 | 1.0 | en User defined configuration List of possible DALI commands: OFF, UP, DOWN, STEP UP, STEP DOWN, RECALL MAX, RECALL MIN, STEP DOWN AND OFF, ON AND STEP UP, GO TO SCENE 0 -...

  • Page 8: Reference List

    Manual DALI TOUCHPANEL 02 | 04.2019 | 1.0 | en Helpful links 5.1. Additional information Homepage TOUCHPANEL 02 Homepage masterCONFIGURATOR 8 / 8...
